S P E C I F I C A T I O N S; Smart Box Series; Specifications - Dahua Smart Box Series User Manual

Record & playback function
Support each channel real-time record independently, and at the same time it can support
search, forward play, network monitor, record search, download and etc.
Support various playback modes: slow play, fast play, backward play and frame by frame
play.
Support time title overlay so that you can view event accurate occurred time
Support customized zoom function during the preview.
Network operation
Support network remote real-time monitor, remote record search and remote PTZ control.
Alarm activation function
Several relay alarm outputs to realize alarm activation and on-site light control.
The alarm input port and output has the protection circuit to guarantee device safety.
Communication port
RS485 port can realize alarm input and PTZ control.
RS232 port can connect to keyboard to realize central control, and can also connect to PC
COM to upgrade system and realize maintenance, and matrix control.
Standard Ethernet port can realize network access function.
PTZ control
Support PTZ decoder via coaxial cable.
Intelligent operation
Mouse operation function
In the menu, support copy and paste setup function
UPNP (Universal Plug and Play)
Establish mapping connection between LAN and WAN via UPNP protocol.
Slight function differences may be found due to different series.
1.3 1.3 Specification 1.3 1.3 Specification Specifications s s s Specification

1.3.1 Smart Box Series

Parameter
Main
System
Processor
OS
System
Resources
Interface
2CIF Real-time Smart Box Series
High-performance industrial embedded micro controller
Embedded LINUX
Multiplex operations: Multiple-channel record, multiple-channel playback
and network operation simultaneously
User-friendly graphical user interface
Standalone DVR User's Manual
960H Smart Box Series
2
