Video Input
Video monitor
Video
Output
Video
Standard
Record
Speed
Video
Partition
Monitor
Touring
Resolution
(PAL/NTSC
)
Quality
Privacy
mask
Information
TV Adjust
Channel
Lock
Channel
Information
Color
Configuratio
n
Audio
Hard Disk
4-CH composite video
input:
(NTSC/PAL)
BNC (1.0V
75Ω)
P- P,
B
B
1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output.
1-ch VGA output.
1-ch HDMI output
Support TV/VGA /HDMI video output at the same time.
Support PAL/NTSC.
Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per
channel
1/4 windows(Optional)
Support monitor tour functions such as alarm, motion detection, and
schedule auto control.
PAL(700 TVL 50f/s)/NTSC(700 TVL 60f/s)
Real-time monitor
:
960H 960 ×576/960×480
Playback
:
All-channel: 960H
960 ×576/960×480
352×576/352×480, 2CIF 704×288/704×240, CIF 352×288/ 352×240 ,
QCIF 176×144/176×120
Support dual streams: extra stream resolution CIF 352×288/ 352×240,
QCIF 176×144/176×120.
6-level image quality (Adjustable)
Support one privacy mask of user-defined size in full screen.
Support max 4 zones.
Channel information, time information and privacy mask zone.
Adjust TV output zone suitable to anamorphic video.
Cover secret channel with black screen though system is encoding
normally.
Screen-lock function to prevent unauthorized user seeing secret video.
Channel name, recording status, screen lock status, video loss status and
motion detection status are shown on the bottom left of display screen.
Hue, brightness, contrast, saturation and gain setup for each channel.
N/A
1 built-in SATA port. Support 1 HDD.
Standalone DVR User's Manual
8-CH composite video
input:
(NTSC/PAL)
BNC (1.0V
75Ω)
P- P,
B
B
1/4/8/9 windows
D1 704×576/704×480, HD1
16-CH
composite
video
input:
(NTSC/PAL)
BNC
(1.0V
75Ω)
P- P,
B
B
1/4/8/9 /16 windows
15
