Page 1 HDCVI Series DVR User’s Manual Version 1.5.1...
Page 2: Table Of Contents
Table of Contents FEATURES AND SPECIFICATIONS ..............1 Overview ............................1 Features ............................1 Specifications ........................... 2 1.3.1 Economic 720P Smart 1U Series ....................2 1.3.2 Economic 720P(V2) Smart 1U Series..................5 1.3.3 1080P(V2) Smart 1U Series ....................... 6 Econimic 720P （S2） Smart 1U Series ................... 8 1.3.4 1.3.5 General 720P (S2) Smart 1U Series ..................
Page 3 1.3.33 Advanced 720P (S3) Compact 1U Series ................49 1.3.34 1080P (S3) Compact 1U Series ..................50 OVERVIEW AND CONTROLS ................. 53 Front Panel ............................. 53 Econimic 720P / Econimic 720P(V2)/ 1080P(V2) Smart 1U/ Econimic 720P （S2） Smart 2.1.1 1U/ General 720P (S2) Smart 1U/1080P (S2) Smart 1U/Entry-level 720P (S2) Smart 1U/Econimic 720P （S3）...
Page 4 2.2.23 720P (S2) Compact 1U/ Entry-level 720P (S2) Compact 1U Series ........ 84 2.2.24 Entry-level 720P (S3) Compact 1U /720P (S3) Compact 1U / Advanced 720P (S3) Compact 1U /1080P (S3) Compact 1U Series..................85 Connection Sample........................87 2.3.1 Smart Box Series ........................87 2.3.2 Smart 1U Series ........................
Page 5 3.7.2 Alarm Input Port ......................... 98 3.7.3 Alarm Output Port ........................98 RS485 ............................. 99 Other Interfaces ..........................99 OVERVIEW OF NAVIGATION AND CONTROLS .......... 100 Boot up and Shutdown ........................ 100 4.1.1 Boot up ............................. 100 4.1.2 Shutdown ..........................100 4.1.3 Auto Resume after Power Failure ..................
Page 6 4.6.2 Output Screen .......................... 118 4.6.3 Previse/Next Screen........................ 118 4.6.4 Tour ............................118 4.6.5 Favorites........................... 118 4.6.6 Channel ............................ 118 4.6.7 PTZ ............................119 4.6.8 Color ............................119 4.6.9 Search ............................119 4.6.10 Alarm Status ........................119 4.6.11 Channel Info ........................119 4.6.12 Remote Device ........................
Page 7 Network Connection........................231 Login ............................. 231 LAN Mode ............................. 232 Live ..............................233 PTZ ............................... 234 Image ............................235 5.6.1 Image............................235 WAN Login ........................... 236 Setup ............................. 237 5.8.1 Camera ............................. 237 5.8.2 Network ............................ 246 5.8.3 Event ............................261 5.8.4 Storage .............................
Page 8 5.12 Alarm ............................. 301 5.13 Log out ............................302 5.14 Un-install Web Control ......................... 303 PROFESSIONAL SURVEILLANCE SYSTEM ..........304 FAQ ......................... 305 APPENDIX A HDD CAPACITY CALCULATION ..........310 APPENDIX B COMPATIBLE BACKUP DEVICE LIST........311 APPENDIX C COMPATIBLE CD/DVD DEVICE LIST ........... 317 APPENDIX D COMPATIBLE DISPLAYER LIST ..........
Page 9 Welcome Thank you for purchasing our HDCVI DVR! This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series DVR features and functions, as well as a detailed menu tree.
Page 10: Important Safeguards And Warnings
Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The product must be grounded to reduce the risk of electric shock. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation.
Page 11: Features And Specifications
1 FEATURES AND SPECIFICATIONS 1.1 Overview This series product is an excellent digital monitor product designed for security field. It adopts embedded Linux OS to maintain reliable operation. It is easy to use and can realize surveillance function after some simple setups.
Page 12: Specifications
Support network remote real-time monitor, remote record search and remote PTZ control.  Alarm activation function Several relay alarm outputs to realize alarm activation and on-site light control. The alarm input port and output has the protection circuit to guarantee device safety. ...
Page 13 1-ch VGA output. Video 1-ch HDMI output. Output Support VGA/HDMI video output at the same time. Video Video monitor Support PAL/NTSC. Standard Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s Record per channel Speed Video 1/4 windows(Optional) Partition Monitor...
Page 14 Storage Support channel record quota setup Mode Recording 1 to 120 minutes single record duration (Default setup is 60 minutes) Length Playback Repeat When hard disk is full, system can overwrite previous video file. Record Various search engines such as time, type and channel. Search Playback Various fast play, slow play speeds, manual frame by frame playback...
Page 15: Economic 720P(V2) Smart 1U Series
2 USB 2.0 port. Interface Interface Network RJ45 10M/100M self-adaptable Ethernet port connection RS485 RS232 System Hard Disk Display HDD current status Information Information Data Data stream statistics for each channel (in wave mode) Stream Statistics Backup to 1024 log files. statistics Support various search engines such as time and type.
Page 16: 1080P(V2) Smart 1U Series
Parameters 4-Ch 8-Ch Video Frame PAL:1~25f/s；NTSC：1~30f/s Rate Video Frame 1536Kbps-4096Kbps， Rate For 720P: default setup is 2Mbps，max supports 4Mbps Bit Stream Type Video stream/composite stream Dual-Stream Support Audio Encode G.711A/G.711U/PCM Parameters Standard Audio Sampling 8KHz，16Bit Rate Audio Bit Rate 64Kbps Video Port Analog Video...
Page 17 Parameters 4-Ch System Main Processor Industrial embedded micro controller Embedded LINUX Video Video Encode H.264 Parameters Standard Encode 1080P /720P/D1/HD1/2CIF/CIF/QCIF Resolution Video Frame PAL:1~25f/s；NTSC：1~30f/s Rate Video Frame 2048Kbps-6144Kbps， Rate For 1080P: default setup is 4Mbps，max supports 6Mbps Bit Stream Type Video stream/composite stream Dual-Stream Support...
Page 18: Econimic 720P （S2） Smart 1U Series
Parameters 4-Ch Installation Desk Mode 1.3.4 Econimic 720P （S2） Smart 1U Series Parameters 4-Ch 8-Ch System Main Processor Industrial embedded micro controller Embedded LINUX Video Video Encode H.264 Parameters Standard Encode 720P/960H/D1/HD1/ 720P(1~15fps)/960H/D1/ Resolution 2CIF/CIF/QCIF HD1/2CIF/CIF/QCIF HDCVI ： 1 ～ 25f/s （ PAL ）； HDCVI ：...
Page 19: General 720P (S2) Smart 1U Series
Parameters 4-Ch 8-Ch 2 USB ports Others Power DC12V ≤15W（With power adapter, no HDD） Power Consumption Working -10℃－＋55℃ Temperature Working 10%~90% Humidity Dimensions SMART 1U case，270mm（W）×205mm（D）×41mm（H） Weight 1.25KG（No HDD） Installation Desk Mode 1.3.5 General 720P (S2) Smart 1U Series Parameters 4-Ch 8-Ch System...
Page 20: 1080P (S2) Smart 1U Series
Parameters 4-Ch 8-Ch Alarm Output HDD Port 1 SATA port，does not support eSATA port Space Communication Network 1 RJ45 port, 100Mbps Ethernet port Port Communication 2 USB ports Others Power DC12V ≤15W（With power adapter, no HDD） Power Consumption Working -10℃－＋55℃ Temperature Working 10%~90%...
Page 21: Entry-Level 720P （S2） Smart 1U Series
Parameters 4-Ch Bidirectional Reuse the audio input/output port. Talk Input Record Record Mode Schedule record/manual record/MD record/Alarm record Record Max 4-channel playback Playback Backup Mode HDD, burner, USB device, network backup Alarm Alarm Input Alarm Output HDD Port 1 SATA port，does not support eSATA port Space Communication Network...
Page 22: Econimic 720P （S3） Smart 1U Series
Parameters 8-Ch HDMI/ VGA video output at the same time. Loop Output Matrix Output Audio Port Audio Input 1-channel RCA port. Audio Output 1-channel RCA port. Bidirectional Reuse the audio input/output port. Talk Input Record Record Mode Schedule record/manual record/MD record/Alarm record Record Max 8-channel playback Playback...
Page 23: General 720P (S3) Smart 1U Series
Parameters 4-Ch 8-Ch Rate Audio Bit Rate 64Kbps Video Port Analog Video 4-ch port(HDCVI 8-ch port(HDCVI Input video/general standard definition video/general standard definition video self-adaptive) video self-adaptive)   Network Video Max add 1 IP channel Max add 2 IP channel Input connection connections...
Page 24 Parameters 4-Ch 8-Ch System Main Processor Industrial embedded micro controller Embedded LINUX Video Video Encode H.264 Parameters Standard Encode 1080P@15f/1080N/720P/960H/D1/HD1/2CIF/CIF/ Resolution Video Frame PAL:1~25f/s；NTSC：1~30f/s Rate Video Frame 32Kbps-6144Kbps， Rate For 720P: default setup is 2Mbps，max supports 4Mbps. For 1080P: default setup is 2Mbps，max supports 6Mbps. Bit Stream Type Video stream/composite stream Dual-Stream...
Page 25: 1080P (S3) Smart 1U Series
Parameters 4-Ch 8-Ch ≤7W ≤8W Power Consumption (No HDD) Working -10℃－＋55℃ Temperature Working 10%~90% Humidity Dimensions SMART 1U case, 270mm（W）×205mm（D）×41mm（H）（ No ≤0.5KG ≤0.55KG Weight HDD） Installation Desk Mode 1.3.10 1080P (S3) Smart 1U Series Parameters 4-Ch System Main Processor Industrial embedded micro controller Embedded LINUX Video...
Page 26: General 720P Mini 1U Series
Parameters 4-Ch Backup Mode HDD, burner, USB device, network backup Alarm Alarm Input Alarm Output HDD Port 1 SATA port，does not support eSATA port Space Communication Network 1 RJ45 port, 100Mbps Ethernet port Port Communication RS485 port 2 USB2.0 ports( at the rear panel) Others Power DC12V...
Page 27 Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per Record channel Speed Video 1/4 windows(Optional) 1/4/8/9 windows Partition Monitor Support monitor tour functions such as motion detection, and schedule auto Touring control. PAL/NTSC Real-time monitor： 720P 1280*720 Resolution Playback：...
Page 28 Record Various search engines such as time, type and channel. Search Playback Various fast play, slow play speeds, manual frame by frame playback and Mode reverse play mode. Various File Can switch to previous or next file or any file in current play list. Switch Can switch to file on other channel of the same time.
Page 29: General 720P(V2) Mini 1U Series
Data Data stream statistics for each channel (in wave mode) Stream Statistics Backup to 1024 log files. statistics Support various search engines such as time and type. Display version information: channel amount, system version and release Version date. On-line user Display current on-line user User Multi-lever user management;...
Page 30: Econimic 720P Mini 1U Series
Parameters 4-Ch 8-Ch 16-Ch Parameters Standard Audio Sampling 8KHz，16Bit Rate Audio Bit Rate 64Kbps 4-channel ， BNC 8-channel ， BNC 16-channel ， BNC Video Port Analog Video Input port port port Network Video Input Video Output 1-channel VGA output， 1-channel HDMI output (of the same video source)， HDMI/ VGA video output at the same time.
Page 31 Input USB mouse Devices Input Arabic number, English character, donation and extension Chinese Method (optional) Shortcut Copy/paste operation, USB mouse right-key shortcut menu, double click Function USB mouse to switch screen. Compression Video Standard Compressio H.264 Audio Compressio 4-CH composite video input: 8-CH composite video input: Video Input 75Ω)
Page 32 Bidirectional Audio 1 built-in SATA port. Support 1 HDD. Hard Disk One HDD Hard disk Space Audio：PCM 28.8MByte/h Hard Disk Occupation Video：56-900MByte/h Manual recording, motion detection recording, schedule recording and Recording alarm recording Mode Priority: Manual recording> alarm recording>motion detection Record and recording>schedule recording.
Page 33 Motion Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones. Motion Detection Various sensitivity levels. Detection and Alarm can activate record or external alarm or screen message prompt. Alarm Video Loss Alarm can activate screen message prompt. External Alarm Manual Alarm Control Alarm Input...
Page 34: Econimic 720P(V2) Mini 1U Series
Installation Desktop installation Mode 1.3.14 Econimic 720P(V2) Mini 1U Series Parameters 4-Ch 8-Ch 16-Ch System Main Processor Industrial embedded micro controller Embedded LINUX Video Video Encode H.264 Parameters Standard Encode 720P/D1/HD1/2CIF/CIF/QCIF Resolution Video Frame PAL:1~25f/s；NTSC：1~30f/s Rate Video Frame 1536Kbps-4096Kbps， Rate For 720P: default setup is 2Mbps，max supports 4Mbps Bit Stream Type Video stream/composite stream...
Page 35: Advanced 720P Mini 1U Series
Parameters 4-Ch 8-Ch 16-Ch Humidity Dimensions Mini 1U case，325mm（W）×245mm（D）×45mm（H） Weight 1.25KG（No HDD） Installation Desk Mode 1.3.15 Advanced 720P Mini 1U Series 4-Ch 8-Ch Parameter System High-performance industrial embedded micro controller Main Processor Embedded LINUX System Multiplex operations: Multiple-channel record, multiple-channel playback Resources and network operation simultaneously User-friendly graphical user interface...
Page 36 Privacy Support one privacy mask of user-defined size in full screen. mask Support max 4 zones. Image Channel information, time information and privacy mask zone. Information TV Adjust Adjust TV output zone suitable to anamorphic video. Channel Cover secret channel with black screen though system is encoding Lock normally.
Page 37 Partial When in one-window full-screen playback mode, you can select any zone Enlargemen to activate partial enlargement function. Backup HDD backup function Support peripheral USB backup device. (Flash disk, portable disk and Backup etc.) Mode Support network download and save View monitor channel remotely.
Page 38: Advanced 720P (V2) Mini 1U Series
Password modification Password Administrator can modify other user’s password. Authenticati Account lock strategy Five times login failure in thirty minutes may result in account lock. Web browser, client-end and update tool. Upgrade Password login protection to guarantee safety User-friendly interface when login. Provide the following options: Logout Login, Logout and Shutdown /shutdown/ restart.
Page 39: General 1080P(V2) Mini 1U Series
Parameters 4-Ch 8-Ch 16-Ch Matrix Output Audio Port Audio Input 4-channel RCA Audio Output 1-channel RCA Bidirectional Support (reuse the audio port) Talk Input Record Record Mode Schedule record/manual record/MD record/Alarm record Record 4-channel 8-channel 16-channel Playback playback playback playback Backup Mode HDD, burner, USB device, network backup Alarm...
Page 40: Econimic 1080P(V2) Mini 1U Series
Parameters 4-Ch 8-Ch Network Video Input Video Output 1-channel VGA output， 1-channel HDMI output (of the same video source)， HDMI/ VGA video output at the same time. Loop Output Matrix Output Audio Port Audio Input 1-channel RCA Audio Output 1-channel RCA Bidirectional Support (reuse the audio port) Talk Input...
Page 41: Advanced 1080P (V2) Mini 1U Series
Parameters 4-Ch 8-Ch Parameters Standard Audio Sampling 8KHz，16Bit Rate Audio Bit Rate 64Kbps Video Port Analog Video 4-channel，BNC port 8-channel，BNC port Input Network Video Input Video Output 1-channel VGA output， 1-channel HDMI output (of the same video source)， HDMI/ VGA video output at the same time. Loop Output Matrix Output Audio Port...
Page 42: Econimic 720P (S2) Mini 1U Series
Parameters 4-Ch 8-Ch 2 048Kbps-6144Kbps， Video Frame Rate For 1080P: default setup is 4Mbps，max supports 6Mbps Bit Stream Type Video stream/composite stream Dual-Stream Support Audio Encode G.711A/G.711U/PCM Parameters Standard Audio Sampling 8KHz，16Bit Rate Audio Bit Rate 64Kbps Video Port Analog Video 4-channel，BNC port 8-channel，BNC port...
Page 43 Parameters 4-Ch 8-Ch 16-Ch Video Video Encode H.264 Parameters Standard Encode 720P/960H/D1/ 720P(1~15fps)/960H/ Resolution HD1/2CIF/CIF/QCIF D1/HD1/2CIF/CIF/QCIF HDCVI ： 1 ～ 25f/s Video Frame HDCVI：1～15f/s（The 1 channel supports Rate （ PAL ）； 1~30f/s 25/30f）（NTSC） CVBS：1~25f/s（PAL）；1~30f/s（NTSC）： CVBS 1~25f/s （ PAL ）； 1~30f/s （NTSC）...
Page 44: General 720P (S2) Mini 1U Series
Parameters 4-Ch 8-Ch 16-Ch 2 USB ports Others Power DC12V ≤15W（With power adapter, no HDD） Power Consumption Working -10℃－＋55℃ Temperature Working 10%~90% Humidity Dimensions Mini 1U case，325mm（W）×245mm（D）×45mm（H） Weight 1.25KG（No HDD） Installation Desk Mode 1.3.21 General 720P (S2) Mini 1U Series Parameters 4-Ch 8-Ch...
Page 45: Advanced 720P (S2) Mini 1U Series
Parameters 4-Ch 8-Ch 16-Ch HDD Port 1 SATA port，does not support eSATA port Space Communication Network 1 RJ45 port, 100Mbps Ethernet port Port Communication RS485 port 2 USB ports Others Power DC12V ≤15W（With power adapter, no HDD） Power Consumption Working -10℃－＋55℃...
Page 46: General 1080P (S2) Mini 1U Series
Parameters 4-Ch 8-Ch 16-Ch Record 4-channel 8-channel 16-channel Playback playback playback playback Backup Mode HDD, burner, USB device, network backup Alarm Alarm Input 4-channel input 8-channel input 16-channel input Alarm Output 3-channel output HDD Port 1 SATA port，does not support eSATA port Space Communication Network...
Page 47: Advanced 1080P (S2) Mini 1U Series
Parameters 4-Ch 8-Ch Audio Port Audio Input 1-channel RCA port. Audio Output 1-channel RCA port. Bidirectional Reuse the audio input/output port. Talk Input Record Record Mode Schedule record/manual record/MD record/Alarm record Record Max 4-channel playback Max 8-channel playback Playback Backup Mode HDD, burner, USB device, network backup Alarm Alarm Input...
Page 48: Economic 720P (S3) Mini 1U Series
Parameters 4-Ch 8-Ch Video Output 1-channel VGA output， 1-channel HDMI output (of the same video source)， HDMI/ VGA video output at the same time. Loop Output Matrix Output Audio Port Audio Input 4-channel RCA port. Audio Output 1-channel RCA port. Bidirectional Reuse the audio input/output port.
Page 49 Parameters 4-Ch 8-Ch 16-Ch Rate Audio Bit Rate 64Kbps Video Port Analog Video 4-ch port 8-ch BNC port(HDCVI 16-ch Input (HDCVI video/general port(HDCVI video/general standard definition video/general standard definition video self-adaptive) standard definition video self-adaptive) video self-adaptive)    Network Video Max add 1 IP...
Page 50: Advanced 720P (S3) Mini 1U Series
Parameters 4-Ch 8-Ch 16-Ch Installation Desk Mode 1.3.26 Advanced 720P (S3) Mini 1U Series Parameters 4-Ch 8-Ch 16-Ch System Main Processor Industrial embedded micro controller Embedded LINUX Video Video Encode H.264 Parameters Standard Encode 1080P@12f/720P@15f/960H/D1/HD1/2CIF/CIF Resolution Video Frame PAL:1~25f/s；NTSC：1~30f/s Rate Video Frame 32Kbps-6144Kbps，...
Page 51: Advanced 1080P (S3) Mini 1U Series
Parameters 4-Ch 8-Ch 16-Ch Record 4-channel 8-channel 16-channel Playback playback playback playback Backup Mode HDD, burner, USB device, network backup Alarm Alarm Input 8-channel input 8-channel input 16-channel input Alarm Output 3-channel output HDD Port 1 SATA port，does not support eSATA port Space Communication Network...
Page 52: General 1080P (S3) Mini 1U Series
Parameters 4-Ch 8-Ch 16-Ch    Analog Analog Analog /digital channel /digital channel /digital channel switch. Max 6 IP switch. Max 12IP switch. Max 24 channel channel IP channel connections connections connections    Connection Connection Connection bandwidth:8Mbp bandwidth:16Mb bandwidth:32Mb s-24Mbps...
Page 53 Parameters 4-Ch 8-Ch 16-Ch Video Video Encode H.264 Parameters Standard Encode 1080P/720P/960H/D1/HD1/2CIF/CIF Resolution Video Frame PAL:1~25f/s；NTSC：1~30f/s Rate Video Frame 32Kbps-6144Kbps， Rate For 720P: default setup is 2Mbps，max supports 4Mbps. For 1080P: default setup is 4Mbps，max supports 6Mbps. Bit Stream Type Video stream/composite stream Dual-Stream Support...
Page 54: S2) Compact 1U Series
Parameters 4-Ch 8-Ch 16-Ch Space Communication Network 1 RJ45 port, 100Mbps Ethernet port Port Communication RS485 port 2 USB2.0 ports(One 1 USB2.0 port at the 1 USB2.0 port at the at the front panel and front panel and one front panel and one one at the rear panel) USB3.0 port at the USB3.0 port at the...
Page 55: Entry-Level 720P (S2) Compact 1U Series
Parameters 4-Ch 8-Ch 16-Ch Video Output 1-channel VGA output， 1-channel HDMI output (of the same video source)， HDMI/ VGA video output at the same time. Loop Output Matrix Output Audio Port Audio Input 1-channel RCA port. Audio Output 1-channel RCA port. Bidirectional Reuse the audio input/output port.
Page 56: Entry-Level 720P (S3) Compact 1U Series
Parameters 8-Ch 16-Ch Rate Audio Bit Rate 64Kbps Video Port Analog Video 8-channel，BNC port 16-channel，BNC port Input Video Output 1-channel VGA output， 1-channel HDMI output (of the same video source)， HDMI/ VGA video output at the same time. Loop Output Matrix Output Audio Port Audio Input...
Page 57 Parameters 4-Ch 8-Ch 16-Ch Dual-Stream Support Audio Encode G.711A/G.711U/PCM Parameters Standard Audio Sampling 8KHz，16Bit Rate Audio Bit Rate 64Kbps Video Port Analog Video 4-ch BNC port(HDCVI 8-ch BNC port(HDCVI 16-ch Input video/general video/general port(HDCVI standard definition standard definition video/general video self-adaptive) video self-adaptive) standard definition...
Page 58: S3) Compact 1U Series
1.3.32 720P (S3) Compact 1U Series Parameters 4-Ch 8-Ch 16-Ch System Main Processor Industrial embedded micro controller Embedded LINUX Video Video Encode H.264 Parameters Standard Encode 1080N/720P/960H/D1 1080N@12f/720P@15f/960H/D1/HD1/2CIF/CI Resolution /HD1/2CIF/CIF/ Video Frame PAL:1~25f/s；NTSC：1~30f/s Rate Video Frame 32Kbps-4096Kbps， Rate For 720P: default setup is 1.5Mbps，max supports 4Mbps. For 1080P: default setup is 1.5Mbps，max supports 4Mbps.
Page 59: Advanced 720P (S3) Compact 1U Series
Parameters 4-Ch 8-Ch 16-Ch Alarm Output HDD Port 1 SATA port，does not support eSATA port Space Communication Network 1 RJ45 port, 100Mbps Ethernet port Port Communication RS485 port 2 USB2.0 ports(One at the front panel and one at the rear panel) Others Power DC12V...
Page 60: 1080P (S3) Compact 1U Series
Parameters 4-Ch 8-Ch 16-Ch    Connection Connection Connection bandwidth:8Mbp bandwidth:16Mb bandwidth:32Mb s-24Mbps ps-48Mbps ps-96Mbps Video Output 1-channel VGA output， 1-channel HDMI output (of the same video source)， HDMI/ VGA video output at the same time. Loop Output Matrix Output Audio Port Audio Input 1-channel RCA port.
Page 61 Parameters 4-Ch Video Frame 32Kbps-6144Kbps， Rate For 720P: default setup is 2Mbps，max supports 4Mbps. For 1080P: default setup is 4Mbps，max supports 6Mbps. Bit Stream Type Video stream/composite stream Dual-Stream Support Audio Encode G.711A/G.711U/PCM Parameters Standard Audio Sampling 8KHz，16Bit Rate Audio Bit Rate 64Kbps Video Port Analog...
Page 63: Overview And Controls
2 Overview and Controls This section provides information about front panel and rear panel. When you install this series DVR for the first time, please refer to this part first. 2.1 Front Panel 2.1.1 Econimic 720P / Econimic 720P(V2)/ 1080P(V2) Smart 1U/ Econimic 720P （S2）...
Page 64: Economic 720P/ Economic 720P(V2)/ Economic 1080P(V2) Series
Figure 2-2 Please refer to the following sheet for front panel button information. Icon Name Function To connect USB storage device, USB mouse and USB port etc. When an alarm occurs, the light becomes red to Alarm Alarm indicator light alert you.
Page 65: Economic 720P (S2) Mini 1U / General 720P (S2) Mini 1U / Advanced 720P (S2) Mini 1U
Figure 2-3 Please refer to the following sheet for front panel button information. Icon Name Function Network abnormal Network error occurs or there is no network indicator light connection, the light becomes red to alert you. Power indicator The red light becomes on when the power light connection is OK.
Page 66: Economic 720P(V2) Smart 1U Series
Figure 2-5 Please refer to the following sheet for detailed information. Icon Name Note VIDEO IN Video input port Connect to analog camera, video input signal. USB2.0 port Connect to USB storage device, mouse, burning DVD-ROM and etc. VGA video output VGA video output port.
Page 67: 1080P(V2) Smart 1U Series
Figure 2-6 The 8-channel rear panel is shown as below. See Figure 2-7. Figure 2-7 Please refer to the following sheet for detailed information. Icon Name Note Ground end Power input port Input 12V DC. Network port 100M Ethernet port VGA video output VGA video output port.
Page 68: Econimic 720P （S2） Smart 1U/Entry-Level 720P （S2） Smart 1U Series
Figure 2-8 Please refer to the following sheet for detailed information. Icon Name Note Ground end VGA video output VGA video output port. Output port analog video signal. Can connect to the monitor to view ananlog video output. USB2.0 port Connect to USB storage device, mouse, burning DVD-ROM and etc.
Page 69 Figure 2-9 The 8-channel economic 720P (S2) smart 1U series/8-channel entry-level 720P （S2） smart 1U series rear panel is shown as below. See Figure 2-10. Figure 2-10 Please refer to the following sheet for detailed information. Icon Name Note Ground end USB2.0 port Connect to USB storage device, mouse, burning DVD-ROM and etc.
Page 70: General 720P (S2) Smart 1U Series
and multiple-channel data to the HDMI port of the display device. AUDIO OUT Audio output port Connect to video output device such as sound box. 2.2.5 General 720P (S2) Smart 1U Series The 4-channel series rear panel is shown as below. See Figure 2-11. Figure 2-11 The 8-channel series rear panel is shown as below.
Page 71: 1080P (S2) Smart 1U Series
as speaker. VIDEO IN Video input port Connect to analog camera, video input signal. Power input port Input 12V DC. Network port 100M Ethernet port HDMI High definition High definition audio and video media interface signal output port. transmits uncompressed high definition video and multiple-channel data to the HDMI port of the display device.
Page 72: Econimic 720P （S3） Smart 1U/ General 720P (S3) Smart 1U/1080P (S3) Smart 1U
Network port 100M Ethernet port AUDIO OUT Audio output port Connect to video output device such as sound box. 2.2.7 Econimic 720P （S3） Smart 1U/ General 720P (S3) Smart 1U/1080P (S3) Smart 1U Series These series rear panel is shown as below. See Figure 2-14. The following figure is based on the 4-channel economic 720P （S3）...
Page 73 The 4-channel series rear panel is shown as below. See Figure 2-15. Figure 2-15 The 8-channel series rear panel is shown as below. See Figure 2-16. Figure 2-16 Please refer to the following sheet for detailed information. Icon Name Note VIDEO IN Video input port Connect to analog camera, video...
Page 74: General 720P(V2) Mini 1U Series
Power input port Input 12V DC. Power on-off button Power on/off button. Ground end 2.2.9 General 720P(V2) Mini 1U Series The 4-channel series rear panel is shown as below. See Figure 2-17. Figure 2-17 The 8-channel series rear panel is shown as below. See Figure 2-18. Figure 2-18 The 16-channel series rear panel is shown as below.
Page 75: Econimic 720P Mini 1U Series
Figure 2-19 Please refer to the following sheet for detailed information. Icon Name Note Power on-off button Power on/off button. VGA video output VGA video output port. Output port analog video signal. Can connect to the monitor to view ananlog video output.
Page 76: Econimic 720P(V2) Mini 1U Series
Figure 2-21 Please refer to the following sheet for detailed information. Icon Name Note VIDEO IN Video input port Connect to analog camera, video input signal. VGA video output VGA video output port. Output port analog video signal. Can connect to the monitor to view ananlog video output.
Page 77: Advanced 720P Mini 1U Series
Figure 2-23 The 16-channel series rear panel is shown as below. See Figure 2-24. Figure 2-24 Please refer to the following sheet for detailed information. Icon Name Note Power input port Input 12V DC. Network port 100M Ethernet port VGA video output VGA video output port.
Page 78 Figure 2-25 The 8-channel series rear panel is shown as below. See Figure 2-28. Figure 2-26 Please refer to the following sheet for detailed information. Icon Name Note VIDEO IN Video input port Connect to analog camera, video input signal. AUDIO OUT Audio output port Connect to video output device such...
Page 79: Advanced 720P (V2) Mini 1U Series
Network port 100M Ethernet port RS485_A port. It is the cable A. You RS485（RS-485） can connect to the control devices communication port such as speed dome PTZ. RS485_B.It is the cable B. You can connect to the control devices such as speed dome PTZ.
Page 80: General 1080P(V2) Mini 1U Series
Figure 2-29 Please refer to the following sheet for detailed information. Icon Name Note Power on-off button Power on/off button. Alarm input/Alarm Input/output alarm signal. output VGA video output VGA video output port. Output port analog video signal. Can connect to the monitor to view ananlog video output.
Page 81 Figure 2-30 The 8-channel series rear panel is shown as below. See Figure 2-31. Figure 2-31 Please refer to the following sheet for detailed information. Icon Name Note Power on-off button Power on/off button. VGA video output VGA video output port. Output port analog video signal.
Page 82: Econimic 1080P(V2) Mini 1U Series
communication port can connect to the control devices such as speed dome PTZ. RS485_B.It is the cable B. You can connect to the control devices such as speed dome PTZ. Network port 100M Ethernet port AUDIO OUT Audio output port Connect to video output device such as sound box.
Page 83: Advanced 1080P (V2) Mini 1U Series
Power input port Input 12V DC. HDMI High definition High definition audio and video media interface signal output port. transmits uncompressed high definition video and multiple-channel data to the HDMI port of the display device. Network port 100M Ethernet port Power on-off button Power on/off button.
Page 84: Econimic 720P (S2) Mini 1U Series
Power on-off button Power on/off button. Network port 100M Ethernet port VGA video output VGA video output port. Output port analog video signal. Can connect to the monitor to view ananlog video output. AUDIO IN Audio input port Connect to audio input device such as speaker.
Page 85 Figure 2-37 The 16-channel series rear panel is shown as below. See Figure 2-38. Figure 2-38 Please refer to the following sheet for detailed information. Icon Name Note Power on-off button Power on/off button. Alarm input/Alarm Input/output alarm signal. output VGA video output VGA video output port.
Page 86: General 720P (S2) Mini 1U Series
communication port can connect to the control devices such as speed dome PTZ. RS485_B.It is the cable B. You can connect to the control devices such as speed dome PTZ. USB2.0 port Connect to USB storage device, mouse, burning DVD-ROM and etc. Network port 100M Ethernet port HDMI...
Page 87: Advanced 720P (S2) Mini 1U Series
Figure 2-41 Please refer to the following sheet for detailed information. Icon Name Note Power on-off button Power on/off button. VGA video output VGA video output port. Output port analog video signal. Can connect to the monitor to view ananlog video output.
Page 88 Figure 2-42 The 8-channel series rear panel is shown as below. See Figure 2-43. Figure 2-43 Figure 2-44 The HCVR5116HE-S2 series rear panel is shown as below. See Figure 2-44 Please refer to the following sheet for detailed information. Icon Name Note Power on-off button...
Page 89: General 1080P (S2) Mini 1U Series
Alarm input/Alarm Input/output alarm signal. output VGA video output VGA video output port. Output port analog video signal. Can connect to the monitor to view ananlog video output. AUDIO IN Audio input port Connect to audio input device such as speaker. AUDIO OUT Audio output port Connect to video output device such...
Page 90 Figure 2-45 The 8-channel series rear panel is shown as below. See Figure 2-46. Figure 2-46 Please refer to the following sheet for detailed information. Icon Name Note Power on-off button Power on/off button. VGA video output VGA video output port.
Page 91: Advanced 1080P (S2) Mini 1U Series
connect to the control devices such as speed dome PTZ. HDMI High definition High definition audio and video media interface signal output port. transmits uncompressed high definition video and multiple-channel data to the HDMI port of the display device. Network port 100M Ethernet port AUDIO OUT Audio output port...
Page 92: Advanced 1080P (S3) Mini 1U Series
VGA video output VGA video output port. Output port analog video signal. Can connect to the monitor to view ananlog video output. AUDIO IN Audio input port Connect to audio input device such as speaker. AUDIO OUT Audio output port Connect to video output device such as sound box.
Page 93 Figure 2-50 Please refer to the following sheet for detailed information. Icon Name Note Alarm input/Alarm Input/output alarm signal. output VIDEO IN Video input port Connect to analog camera, video input signal. AUDIO IN Audio input port Connect to audio input device such as speaker.
Page 94: S2) Compact 1U/ Entry-Level 720P (S2) Compact 1U Series
Power on-off button Power on/off button. Power cable Use clamp to secure the power cable fastener on the device in case there is any loss. 2.2.23 720P (S2) Compact 1U/ Entry-level 720P (S2) Compact 1U Series The 4-channel 720P (S2) compact 1U series rear panel is shown as below. See Figure 2-51. Figure 2-51 The 8-channel 720P (S2) compact 1U/ entry-level 720P (S2) compact 1U series rear panel is shown as below.
Page 95: Entry-Level 720P (S3) Compact 1U /720P (S3) Compact 1U / Advanced 720P (S3)
Figure 2-53 Please refer to the following sheet for detailed information. Icon Name Note Power input port Input 12V DC. RS485 （ RS-485 ） RS485_A port. It is the cable A. You can connect to the control devices communication port such as speed dome PTZ.
Page 96 Figure 2-54 The 1080P (S3) compact 1U series rear panel is shown as below. See Figure 2-55. Figure 2-55 Please refer to the following sheet for detailed information. Icon Name Note VIDEO IN Video input port Connect to analog camera, video input signal.
Page 97: Connection Sample
RS485_B.It is the cable B. You can connect to the control devices such as speed dome PTZ. Power input port Input 12V DC. Ground end When connect the Ethernet port, please use crossover cable to connect the PC and use the straight cable to connect to the switcher or router.
Page 98: Compact 1U Series
Figure 2-57 2.3.3 Compact 1U Series Please refer to Figure 2-58 for connection sample. The following figure is based on the 16-channel entry-level 720P (S3) compact 1U /720P (S3) compact 1U/advanced 720P (S3) compact 1U series product. Figure 2-58...
Page 99: Mini 1U Series
2.3.4 Mini 1U Series Please refer to Figure 2-59 for connection sample. The following figure is based on 16-channel economic 720P (S3) mini 1U/advanced 720P (S3) mini 1U/general 1080P (S3) mini 1U series. Figure 2-59 2.4 Remote Control The remote control interface is shown as in Figure 2-60. Please note remote control is not our standard accessory and it is not included in the accessory bag.
Page 100 Figure 2-60 Please refer to the following sheet for detailed information. Serial Number Name Function Power button Click it to boot up or shut down the device. Address Click it to input device number, so that you can control it. Forward Various forward speeds and normal speed playback.
Page 101: Mouse Control
Cancel Go back to previous menu or cancel current operation (close upper interface or control) Record Start or stop record manually In record interface, working with the direction buttons to select the record channel. Click this button for at least 1.5 seconds, system can go to the Manual Record interface.
Page 102 In input box, you can select input methods. Left click the corresponding button on the panel you can input numeral/English character (small/capitalized). Here ← stands for backspace button. ＿ stands for space button. In English input mode: _stands for input a backspace icon and ← stands for deleting the previous character.
Page 103: Installation And Connections
3 Installation and Connections Note: All the installation and operations here should conform to your local electric safety rules. 3.1 Check Unpacked DVR When you receive the DVR from the forwarding agent, please check whether there is any visible damage. The protective materials used for the package of the DVR can protect most accidental clashes during transportation.
Page 104: Smart 1U Series
When you remove the HDD, please refer to the following figure to pull the spring up and then remove the HDD. 3.3.2 Smart 1U Series The series DVR has one SATA HDD. ○ ○ ○ . Loosen the screws of the upper Fix four screws in the HDD Place the HDD in cover and side panel.
Page 105: Connecting Power Supply
The series DVR has one SATA HDD. ① Loosen the screws of the upper ② ③ Fix four screws in the HDD (Turn Place the HDD in accordance cover and side panel. just three rounds). with the four holes in the bottom. ④...
Page 106: Connecting Video Output
The video input interface is BNC. The input video format includes: PAL/NTSC BNC（1.0V ， P- P 75Ω.） The video signal should comply with your national standards. The input video signal shall have high SNR, low distortion; low interference, natural color and suitable lightness.
Page 107: Alarm Input And Output Connection
 Reduce the volume of the sound box.  Using more sound-absorbing materials in decoration can reduce voice echo and improve acoustics environment.  Adjust the layout to reduce happening of the squeaking. 3.7 Alarm Input and Output Connection Please read the followings before connecting. 1.
Page 108: Alarm Input Port
Figure 3-1 ALARM 1 to ALARM 16. The alarm becomes active in low voltage. 1，2，3，4，5， 6，7，8，9，10， 11，12，13，14， 15，16 Three normal open groups (on/off signal) NO1 C1，NO2 C2， NO3 C3， Earth cable. 3.7.2 Alarm Input Port Please refer to the following sheet for more information. ...
Page 109: Other Interfaces
Relay Specification JRC-27F Model: Silver Material of the touch Rating Rated switch capacity 30VDC 2A, 125VAC 1A （Resistance Maximum switch power 125VA 160W Load） Maximum switch voltage 250VAC, 220VDC Maximum switch currency Insulation Between touches with same 1000VAC 1minute polarity 1000VAC 1minute Between touches with different polarity...
Page 110: Overview Of Navigation And Controls
4 Overview of Navigation and Controls 4.1 Boot up and Shutdown 4.1.1 Boot up Before the boot up, please make sure:  The rated input voltage matches the device power on-off button. Please make sure the power wire connection is OK. Then click the power on-off button. ...
Page 111: Reset Password
After system booted up, you can see the following interface if it is your first login or you have restored default setup. See Figure 4-1. Please input old password and then input new password twice to confirm the change.  The default administrator user name is admin and the password is admin.
Page 112: Startup Wizard
Once you forgot password, you can answer the security questions you set in chapter 4.2.1 to reset the password. In login interface, click . See Figure 4-3. Figure 4-3 System pops up the following dialogue box, please answer the security questions and then input the new password twice.
Page 113 Cancel the Startup button, system goes to the login interface directly when it boots up the next time. Figure 4-5 Click Cancel button or Next Step button, system goes to login interface. See Figure 4-6. System consists of three accounts: ...
Page 114 Figure 4-7 Click Next button, you can go to network interface. See Figure 4-8. For detailed information, please refer to chapter 4.10.3. Figure 4-8...
Page 115 Click Next button, you can set P2P function. Scan the QR code, download the App to the cellphone, you can use the smart phone to add the device. See Figure 4-9. For detailed information, please refer to chapter 4.11.2.15. Figure 4-9 Now you can go to the remote device interface to add the camera to the corresponding channel.
Page 116 Figure 4-10 Click Next button, you can go to Encode interface. See Figure 4-11. For detailed information, please refer to chapter 4.11.1.3. Figure 4-11...
Page 117: Live Viewing
Click Next button, you can go to Schedule interface. See Figure 4-12. For detailed information, please refer to chapter 4.11.4.1.1. Figure 4-12 Click Finish button, system pops up a dialogue box. Click the OK button, the startup wizard is complete. See Figure 4-13.
Page 118  Preview drag: If you want to change position of channel 1 and channel 2 when you are previewing, you can left click mouse in the channel 1 and then drag to channel 2, release mouse you can switch channel 1 and channel 2 positions. ...
Page 119 Figure 4-16  Put the middle button at the centre of the zone you want to zoom in, and move the mouse, you can view an interface shown as in Figure 4-17. Figure 4-17 Right click mouse to cancel zoom and go back to the original interface. Manual record function It is to backup the video of current channel to the USB device.
Page 120: Right-Click Menu
4.5 Right-Click Menu On the preview interface, right click mouse, you can view menu interface shown as in Figure 4-18. Tips After you go to the corresponding interface, right click mouse to go back to the upper-level. Figure 4-18 4.5.1 Window Switch System supports 1/4/8/9-window (The options here depend on your product channel amount).
Page 121: Ptz Control
4.5.3 PTZ Control The PTZ setup is shown as in See Figure 4-20. Please note the commend name is grey once device does not support this function. The PTZ operation is only valid in one-window mode. Here you can control PTZ direction, speed, zoom, focus, iris, preset, tour, scan, pattern aux function, light and wiper, rotation and etc.
Page 122 Figure 4-22 Please refer to the following sheet for detailed information. Please note the above interface may vary due to different protocols. The button is grey and can not be selected once the current function is null. Right click mouse or click the ESC button at the front panel to go back to the Figure 4-20. Icon Function Icon...
Page 123 Click Set button to save current preset. Figure 4-24 Tour Setup In Figure 4-23, click tour button. Input tour value and preset No. Click Add preset button to add current preset to the tour. See Figure 4-25. Tips Repeat the above steps to add more presets to the tour. Click Del preset button to remove it from the tour.
Page 124 Figure 4-26 Scan Setup In Figure 4-23, click Scan button. Use direction buttons to set camera left limit and then click Left button. Use direction buttons to set camera right limit and then click Right button. Now the scan setup process is complete.
Page 125: Color
Call Scan In Figure 4-22, input Scan value and then click to call a tour. Click again to stop call. Rotate In Figure 4-22, click to enable the camera to rotate. System supports preset, tour, pattern, scan, rotate, light and etc function. Note: ...
Page 126 Figure 4-29 Please refer to the following sheet for detailed information. Item Note Period There are two periods in one day. You can set different sharpness, brightness, and contrast setup for different periods. Effective Time Check the box here to enable this function and then set period time.
Page 127: Display
Item Note from 0 to 100. The default value is 50. The larger the number, the strong the color is. This value has no effect on the general brightness of the whole video. The video color may become too strong if the value is too high. For the grey part of the video, the distortion may occur if the white balance is not accurate.
Page 128: Alarm Output
4.5.4 Alarm Output Please refer to chapter 0 for detailed information. 4.5.5 Remote Device Please refer to chapter 4.11.1.1 for detailed information. 4.5.6 Video Matrix Please refer to chapter 4.11.5.3 for detailed information. 4.5.7 Main menu Please refer to chapter 4.8 for detailed information. 4.6 Navigation Bar You need to go to the Main menu->Setting->System->General to enable navigation bar function;...
Page 129: Ptz
It is to pop up channel tree. You can left click to select a channel on the tree and then drag it to the preview window on the left pane. 4.6.7 PTZ Click , system goes to the PTZ control interface. Please refer to chapter 4.5.3. 4.6.8 Color Click button , system goes to the color interface.
Page 130: Usb Manager
， system goes to the HDD manager interface. It is to view and manage HDD information. Click Please refer to chapter 4.11.4.2. 4.6.15 USB Manager ， system goes to the USB Manager interface. It is to view USB information, backup and Click update.
Page 131: Operation
Figure 4-35 4.9 Operation 4.9.1 Search Click search button in the main menu, search interface is shown as below. See Figure 4-36. Usually there are three file types:  R: Regular recording file.  A: External alarm recording file.  M: Motion detection recording file.
Page 132 Figure 4-36 Please refer to the following sheet for more information. Name Function Here is to display the searched picture or file. Display Support 1/4/8-window playback. window Here you can select to search the picture or the recorded file. You can select to play from the read-write HDD, from peripheral device or from redundancy HDD.
Page 133 option. The card number search interface is shown as below. Here you can view card Card number/field setup bar. You can implement advanced search. number search Click it to go to mark file list interface. You can view all mark information of current Mark file channel by time.
Page 134 The volume of the playback Click the snapshot button in the full-screen mode, the system can snapshot 1 picture. System supports custom snap picture saved path. Please connect the peripheral device first, click snap button on the full-screen mode, you can select or create path.
Page 135 Other Functions  When system is playing, you can select a zone in the window to begin smart search. Click the motion detect button to begin play.  Once the motion detect play has begun, click button again will terminate current motion detect file play.
Page 136 Click the , you can go to the smart search playback. Click it again, system stops smart search playback. Important  System does not support motion detect zone setup during the full-screen mode.  During the multiple-channel playback, system stops playback of rest channels if you implement one-channel smart search.
Page 137 Figure 4-39  Playback Mark During 1-window playback mode, click mark file list button in Figure 4-36, you can go to mark file list interface. Double click one mark file, you can begin playback from the mark time.  Play before mark time Here you can set to begin playback from previous N seconds of the mark time.
Page 138  Delete Here you can check the mark information item you want to delete and then click Delete button, you can remove one mark item. . Note  After you go to the mark management interface, system needs to pause current playback. System resume playback after you exit mark management interface.
Page 139: Human Face Search
Select split mode, so that the record can be spliced in several sections. Select splice file.  Click Playback, system playbacks from the first of current date by default.  Click time bar, system playbacks from the time you click. ...
Page 140: Backup
Name Function Display  It is to display human face detection file list. The latest file is at the top. \  Click Export, you can export the selected file to the USB device. There are two types: image/record.  Image: Export the recognized human face image. ...
Page 141 Figure 4-45 System only backup files with a √ before channel name. You can use Fn or cancel button to delete √ after file serial number. Click Start button, system begins copy. At the same time, the backup button becomes stop button. You can view the remaining time and process bar at the left bottom.
Page 142: Shut Down
The file name format usually is: Channel number+Record type+Time. In the file name, the YDM format is Y+M+D+H+M+S. File extension name is .dav. Tips: During backup process, you can click ESC to exit current interface for other operation. The system will not terminate backup process.
Page 143 Figure 4-48 4.10.1.1 HDD Information Here is to list hard disk type, total space, free space, video start time and status. See Figure 4-49.  SATA: 1 here means system max supports 1 HDD. ○ means current HDD is normal. X means there is error.
Page 144 Figure 4-49 Double click one HDD information; you can see the HDD SMART information. See Figure 4-50. Figure 4-50 4.10.1.2 Record Info It is to view record start time and end time. See Figure 4-51.
Page 145 Figure 4-51 4.10.1.3 Record Estimate System can calculate the record time based on the HDD space, or you can input the record time you want to calculate the HDD space you need. See Figure 2-50. Figure 4-52...
Page 146 Click after the channel name, system pops up Edit dialogue box. See Figure 2-49. You can input resolution, frame rate, bit stream, record time of the corresponding channel, system can calculate the record time based on the channel setup and HDD space. Figure 4-53 ...
Page 147 Figure 4-54  Calculate the HDD space based on the record period Check the channel you want to record file. Input days(s) you want to records, system can auto calculate the HDD space needed (such as 5.109TB). See Figure 4-55. Figure 4-55 4.10.1.4 BPS Here is for you to view current video data stream (KB/s), resolution and etc.
Page 148: Event
Figure 4-56 4.10.1.5 Version Here is for you to view some version information such as version number, built date, serial number and etc. See Figure 4-57. Figure 4-57 4.10.2 Event It is to display device status and channel status. See Figure 4-58.
Page 149: Network
Figure 4-58 4.10.3 Network 4.10.3.1 Online Users Here is for you to manage online users. See Figure 4-59. You can disconnect one user or block one user if you have proper system right. Max disconnection setup is 65535 seconds. System detects there is any newly added or deleted user in each five seconds and refresh the list automatically.
Page 150 Network load is shown as in Figure 4-60. Here you can view the follow statistics of the device network adapter. Here you can view information of all connected network adapters. The connection status is shown as offline if connection is disconnected. Click one network adapter, you can view the flow statistics such as send rate and receive rate at the top panel.
Page 151: Log
Figure 4-61 4.10.4 Log Here is for you to view system log file. System lists the following information. See Figure 4-62. Log types include system operation, configuration operation, data management, alarm event, record operation, account manager, log clear, file operation and etc. It optimized reboot log. There are only three types: normal reboot, abnormal reboot and protection reboot.
Page 152: Setting
Figure 4-62 Select an item on the list and then click the Details button or double click the log item, you can view the detailed information such as log time, log type, log user, IP address and etc. See Figure 4-63. Figure 4-63 4.11 Setting It is for you to set camera, network, event, storage, system and etc.
Page 153 Note You can see this interface after you set IP channel in chapter 4.11.1.3.5. System supports ONVIF standard protocol. 4.11.1.1.1 Remote Device In the main menu, from Camera ->Remote, you can go to an interface shown as in Figure 4-64. Here you can add/delete remote device and view its corresponding information.
Page 154  This series product supports the IPC from many popular manufactures such as Sony, Hitachi, Axis, Samsung, Dynacolor, Arecont, Onvif and Dahua.  System default IP address is 192.168.0.0 if you do not input IP address. System will not add current IP address.
Page 155 Figure 4-66  You can check several devices at the same time and then click the edit button .See Figure 4-3. Please check Batch modify button and then input start IP, end IP and default gateway. Figure 4-67  IP Export System can export the Added device list to your local USB device.
Page 156 Figure 4-68 Select the directory and then click the OK button. System pops up a dialogue box to remind you successfully exported. Please click OK button to exit. Note The exported file extension name is .CVS. The file information includes IP address, port, remote channel number, manufacturer, user name and password.
Page 157 Select the import file and then click the OK button. System pops up a dialogue box to remind you successfully exported. Please click OK button to exit. Note: If the imported IP has conflicted with current added device, system pops up a dialogue box to remind you.
Page 158 Figure 4-71 4.11.1.2 Image For analog channel, the image interface is shown as in Figure 4-72. For digital channel, the image interface is shown as in Figure 4-73.  Channel: Select a channel from the dropdown list.  Saturation: It is to adjust monitor window saturation. The value ranges from 0 to 100. The default value is 50.
Page 159  BLC: The device auto exposures according to the environments situation so that the darkest area of the video is cleared  WDR: For the WDR scene, this function can lower the high bright section and enhance the brightness of the low bright section. So that you can view these two sections clearly at the same time.
Page 160 Figure 4-72 Figure 4-73 4.11.1.3 Encode It is to set video bit stream, picture bit stream, video overlay parameter and etc. 4.11.1.3.1 Video Video setting includes the following items. See Figure 4-74.  Channel: Select the channel you want.  SVC: SVC is so called scaled video coding.
Page 161  Type: Please select from the dropdown list. There are three options: regular/motion detect/alarm. You can set the various encode parameters for different record types.  Compression: System supports H.264 and MJPEG.  Smart codec: Select Start from the dropdown list to enable smart codec function. The DVR can auto reduce the video bit stream of the non-important surveillance object to save the storage space.
Page 162 Figure 4-75 4.11.1.3.3 Overlay Overlay interface is shown as in Figure 4-76.  Cover area: Here is for you to set cover area. You can drag you mouse to set proper section size. In one channel video, system max supports 4 zones in one channel. ...
Page 163 Figure 4-76 Figure 4-77 4.11.1.3.4 Channel Name It is to modify channel name. It max supports 31-character. See Figure 4-78.
Page 164 Figure 4-78 4.11.1.3.5 Channel Type It is to set channel type. It supports coaxial/UTP/IP. See Figure 4-79. Figure 4-79 Important Add/cancel IP CAM function is for some 4/8/16-channel series product only.  Add IP CAM: Click it; you can add corresponding X IP channels. Here X refers to the product channel amount such as 4/8/16.
Page 165 Figure 4-80 For example, there is a 4-channel analog device, after the A/D switch, it can max supports 4 analog channels and 4 IP channels. Once it has become the 3+1 mode (3 analog channels+1 IP channel), you click button, system becomes 3+5 mode (3 analog channels+5 IP channel). ...
Page 166: Network
4.11.1.3.6 Upgrade It is to update the camera. From main menu->setting->camera->remote upgrade, the interface is shown as below. See Figure 4-82. Click Browse button and then select the upgrade file. Then select a channel (or you can select device type filter to select several devices at the same time.) Click Start upgrade button to update.
Page 167 may pop up dialog box for you to confirm setup when you want to change MTU setup. C lick OK button to confirm current reboot, or you can click Cancel button to terminate current modification. Before the modification, you can check the MTU of the gateway; the MTU of the DVR shall be the same as or is lower than the MTU of the gateway.
Page 168 Important: System needs to reboot after you changed and saved any setup of the above four ports. Please make sure the port values here do not conflict. Figure 4-84 4.11.2.3 WIFI The WIFI interface is shown as below. See Figure 4-85. ...
Page 169 Figure 4-85  WIFI working status: Here you can view current connection status. Please note:  After successful connection, you can see WIFI connection icon at the top right corner of the preview interface.  When the hotspot verification type is WEP, system displays as AUTO since the device can not detect its encryption type.
Page 170  User name: It is the user name for you to login the 3G network.  Password: It is the password for you to login the 3G network.  Pulse interval: You can set dialup duration. Once you disable the extra stream, the connection time begins.
Page 171 Figure 4-87 4.11.2.6 DDNS Setup DDNS setup interface is shown as in Figure 4-88. You need a PC of fixed IP in the internet and there is the DDNS software running in this PC. In other words, this PC is a DNS (domain name server). In network DDNS, please select DDNS type and highlight enable item.
Page 172 Figure 4-88 Please note DDNS type includes: CN99 DDNS, NO-IP DDNS, Quick DDNS, Dyndns DDNS and sysdns DDNS. All the DDNS can be valid at the same time, you can select as you requirement. Private DDNS function shall work with special DDNS server and special Professional Surveillance Software (PSS).
Page 173  User name: It is optional. You can input your commonly used email address. Important  Do not register frequently. The interval between two registrations shall be more than 60 seconds. Too many registration requests may result in server attack. ...
Page 174 Figure 4-89 Figure 4-90 4.11.2.8 Email The email interface is shown as below. See Figure 4-91.  SMTP server: Please input your email SMTP server IP here.  Port: Please input corresponding port value here.  User name: Please input the user name to login the sender email box. ...
Page 175  Interval: Please check the above box to enable this function and then set the corresponding interval. System can send out the email regularly as you set here. Click the Test button, you can see the corresponding dialogue box to see the email connection is OK or not. Please note system will not send out the email immediately when the alarm occurs.
Page 176 Figure 4-92 You can use a PC or FTP login tool to test setup is right or not. For example, you can login user ZHY to H140H140H140HTUFTP://10.10.7.7UTH and then test it can modify or delete folder or not. See Figure 4-93. Figure 4-93 System also supports upload multiple DVRs to one FTP server.
Page 177 Figure 4-94 4.11.2.10 UPnP The UPNP protocol is to establish a mapping relationship between the LAN and the WAN. Please input the router IP address in the LAN in Figure 4-83. See Figure 4-95.  UPNP on/off ：Turn on or off the UPNP function of the device. ...
Page 178 For the TCP and UDP, please make sure the internal port and external port are the same to guarantee the proper data transmission. Figure 4-95 Figure 4-96 4.11.2.11 SNMP SNMP is an abbreviation of Simple Network Management Protocol. It provides the basic network management frame of the network management system.
Page 179 Figure 4-97 Please enable the SNMP function. Use the corresponding software tool (MIB Builder and MG-SOFT MIB Browser. You still need two MIB file: BASE-SNMP-MIB, DVR-SNMP-MIB) to connect to the device. You can get the device corresponding configuration information after successfully connection. Please follow the steps listed below to configure.
Page 180 Figure 4-98 Here you can set a multiple cast group. Please refer to the following sheet for detailed information.  IP multiple cast group address -224.0.0.0-239.255.255.255 -“D” address space  The higher four-bit of the first byte=”1110”  Reserved local multiple cast group address -224.0.0.0-224.0.0.255 -TTL=1 When sending out telegraph -For example...
Page 181 Please note multiple cast function applies to special series only. 4.11.2.13 Register This function allows the device to auto register to the proxy you specified. In this way, you can use the client-end to access the DVR and etc via the proxy. Here the proxy has a switch function. In the network service, device supports the server address of IPv4 or domain.
Page 182 Figure 4-100 4.11.2.15 P2P You can use your cell phone to scan the QR code and add it to the cell phone client. Via the SN from scanning the QR code, you can access the device in the WAN. Please refer to the P2P operation manual included in the resources CD.
Page 183: Event
Open Google Play app in your smart phone. Search gDMSS Lite or gDMSS Plus, download it and install.  iOS: Open App Store app in your smart phone. Search iDMSS Lite or iDMSS Plus, download it and install. Please follow the steps listed below. ...
Page 184 support local activation function. The front-end can get enable/disable status, sensitivity and region setup. You can get corresponding prompt if front-end can not get the above information. You can change front-end setup if it can get. 4.11.3.1.1 Motion Detect After analysis video, system can generate a video loss alarm when the detected moving signal reached the sensitivity you set here.
Page 185  Alarm upload: System can upload the alarm signal to the network (including alarm centre) if you enabled current function.  Send email: System can send out email to alert you when an alarm occurs.  Record channel: System auto activates motion detection channel(s) to record once an alarm occurs. Please make sure you have set MD record in Schedule interface(Main Menu->Setting->Schedule) and schedule record in manual record interface(Main Menu->Advanced->Manual Record) ...
Page 186 Figure 4-104 Figure 4-105 Figure 4-106...
Page 187 Figure 4-107 Motion detect here only has relationship with the sensitivity and region setup. It has no relationship with other setups. 4.11.3.1.2 Video Loss In Figure 4-103, select video loss from the type list. You can see the interface is shown as in Figure 4-108.This function allows you to be informed when video loss phenomenon occurred.
Page 188 Figure 4-108 4.11.3.1.3 Tampering When someone viciously masks the lens, or the output video is in one-color due to the environments light change, the system can alert you to guarantee video continuity. Tampering interface is shown as in Figure 4-109. You can enable “Alarm output “or “Show message” function when tampering alarm occurs.
Page 189 Figure 4-109 4.11.3.1.4 Diagnosis Note This function is for some series only. System can trigger an alarm when the stripe, noise, color cast, out of focus, over exposure event occurred. See Figure 4-110. Please refer to chapter 4.11.3.1.1 motion detection for detailed information.
Page 190 Figure 4-110 This function allows you to be informed when video is blurry, over exposure or color cast occurs. You can enable alarm output channel and then enable show message function. Click the Rule Set button, or move the cursor to Set button and then click the Enter button on the fron t panel, the interface is shown as below.
Page 191 Figure 4-111 Note Video analysis alarm can trigger PTZ preset, tour, and pattern. Please refer to chapter 4.11.3.1.1 motion detection for detailed information. 4.11.3.2 Intelligence (Optional) The intelligence function is optional. The intelligence function and the human face detection can not be valid at the same time! From main menu->Setting->Event, you can go to the intelligence interface.
Page 192 Figure 4-112 Check the Enable box to enable tripwire function. Click Rule setup to draw the tripwire. See Figure 4-113. Figure 4-113 Select SN (Line1/2/3/4) and direction, and then input customized rule name.  Line1/2/3/4: System supports four tripwires. Each SN stands for one tripwire.
Page 193  Direction ( ): System can generate an alarm once there is any object crossing in the specified direction. Now you can draw a rule. Left click mouse to draw a tripwire. The tripwire can be a direct line, curve or polygon.
Page 194  In Figure 4-106. Click button after one date or a holiday, you can see an interface shown as in Figure 4-107.  Alarm output: when an alarm occurs, system enables peripheral alarm devices.  Latch: when tripwire complete, system auto delays detecting for a specified time. The value ranges from 0-300(Unit: second).
Page 195 Figure 4-116 Figure 4-117 4.11.3.2.2 Intrusion (Cross warning zone) Note:  The intrusion function is valid once your network camera or your DVR supports this function.  If your purchased DVR supports the intrusion function, it supports one analog channel. It is not for the digital channel.
Page 196 Figure 4-118 Check the enable box to enable intrusion function. Click Rule setup to draw the zone. See Figure 4-119. Figure 4-119 Select SN (Area1/2/3/4) and direction, and then input customized rule name.  Area1/2/3/4: System supports four zones. Each SN stands for one zone. ...
Page 197 Tips Click to delete the corresponding rule. You can refer to the chapter 4.11.3.2.1 to set parameters. 4.11.3.2.3 Object protection (Optional) Note:  The object protection function is valid once your network camera or your DVR supports this function.  If your purchased DVR supports the object protection function, it supports one analog channel.
Page 198 Figure 4-121 Select SN (object1/2/3/4) and direction, and then input customized rule name.  Object1/2/3/4: System supports four zones. Each SN stands for one zone.  Direction ( ): For icon , system can generate an alarm once the object left in the one for the specified time.
Page 199  Alarm face number: Once the detected human face number reaches the threshold you set here, system can generate an alarm.  Human face RO (region of interest): Check the box, system can highlight the human face region.  Enable: Check the box here to enable face detect function. For detailed setup information, please chapter 4.11.3.2.1.
Page 200  If it is your first time to boot up the device, the disconnection status of the front-end network camera will not be regarded as offline. After one successfully connection, all the disconnection events will be regarded as IPC offline event. ...
Page 201 interface. Once there two tours are both enabled, system can enable the alarm tour as you set here when an alarm occurred. If there is no alarm, system implements the tour setup in the Display interface.  Snapshot: System can snapshot corresponding channel when an alarm occurs. Please note the activation snapshot has the higher priority than schedule snapshot.
Page 202 Figure 4-124 Figure 4-125...
Page 203 . Figure 4-126 Figure 4-127...
Page 204 Figure 4-128 Figure 4-129 Figure 4-130...
Page 205 4.11.3.5 Abnormality There are three types: HDD/Network/user.  HDD: HDD error, no disk, no space. See Figure 4-131 and Figure 4-132.  Network: Disconnection, IP conflict, MAC conflict. See Figure 4-133.  User:Illegal login. See Figure 4-134 .  Alarm output: Please select alarm activation output port (multiple choices). ...
Page 206 Figure 4-132 Figure 4-133...
Page 207 Figure 4-134 4.11.3.6 Alarm Output Here is for you to set proper alarm output such as schedule, manual. Please highlight icon to select the corresponding alarm output. After all the setups please click OK button, system goes back to the previous menu. See Figure 4-135. Figure 4-135...
Page 208: Storage
4.11.4 Storage It is to set HDD management, storage parameters, set record plan and record control. 4.11.4.1 Schedule It is for you to set record plan and snapshot plan. 4.11.4.1.1 Record Note: You need to have proper rights to implement the following operations. Please make sure the HDDs have been properly installed.
Page 209 Figure 4-137  Please draw manually to set record period. There are six periods in one day. See Figure 4-138. Figure 4-138 Please highlight icon to select the corresponding function. After completing all the setups please click save button, system goes back to the previous menu. There are color bars for your reference.
Page 210 Figure 4-139 Figure 4-140 4.11.4.1.1.1 Quick Setup Copy function allows you to copy one channel setup to another. After setting in channel 1, click Copy button, you can go to interface Figure 4-141. You can see current channel name is grey such as channel 1.
Page 211 Figure 4-141 4.11.4.1.1.2 Redundancy Current series product does not support redundancy function. Redundancy function allows you to memorize record file in several disks. When there is file damage occurred in one disk, there is a spare one in the other disk. You can use this function to maintain data reliability and safety.
Page 212  In main menu, from Setting->Camera->Encode->Schedule interface, please enable snapshot function. See Figure 4-144. Please refer to the following figures for detailed information. Figure 4-142 Figure 4-143...
Page 213 Figure 4-144 4.11.4.1.2.2 Trigger Snapshot Please follow the steps listed below to enable the activation snapshot function. After you enabled this function, system can snapshot when the corresponding alarm occurred.  In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as trigger, size, quality and frequency.
Page 214 Figure 4-146 4.11.4.1.2.3 Priority Please note the activation snapshot has the higher priority than schedule snapshot. If you have enabled these two types at the same time, system can activate the activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot. 4.11.4.1.2.4 Image FTP In the main menu, from Setting->Network->FTP, you can set FTP server information.
Page 215 4.11.4.2 HDD Manager Here is for you to view and implement hard disk management. See Figure 4-148. You can see current HDD type, status, capacity and etc. The operation includes format HDD, and change HDD property (read and write/read-only/redundancy). Figure 4-148 4.11.4.3 Record 4.11.4.3.1 Record Control Caution:...
Page 216 Figure 4-149 4.11.4.3.2 Snapshot Operation Check the corresponding box to enable/disable schedule snapshot function. See Figure 4-150. Figure 4-150 Tips You can check All button after the corresponding status to enable/disable all-channel snapshot function. 4.11.4.4 HDD Detect The HDD detect function is to detect HDD current status so that you can clearly understand the HDD performance and replace the malfunction HDD.
Page 217 There are two detect types:  Quick detect is to detect via the universal system files. System can quickly complete the HDD scan. If you want to use this function, please make sure the HDD is in use now. If the HDD is removed from other device, please make sure the write-data once was full after it installed on current device.
Page 218 Figure 4-152 4.11.4.4.2 Detect Report After the detect operation, you can go to the detect report to view corresponding information. The detect report interface is shown as below. See Figure 4-153. Figure 4-153 Click the item you can see the detailed information such as detect result. See Figure 4-154.
Page 219: System
Figure 4-154 4.11.5 System 4.11.5.1 General 4.11.5.1.1 Device General setting includes the following items. See Figure 4-155.  Device ID: Please input a corresponding device name here.  Device No: Here you can set device number.  Language: System supports various languages: Chinese (simplified), Chinese (Traditional), English, Italian, Japanese, French, Spanish (All languages listed here are optional.
Page 220  Startup wizard: Once you check the box here, system will go to the startup wizard directly when the system restarts the next time. Otherwise, it will go to the login interface.  Mouse property: You can set double click speed via dragging the slide bard. You can Click Default button to restore default setup.
Page 221 Figure 4-156 4.11.5.1.3 Holiday Holiday setup interface is shown as in Figure 4-157. Click Add new holiday button, you can input new holiday information. See Figure 4-158. Here you can set holiday name, repeat mode and start/end time. Note  When you enable Holiday settings and schedule setup at the same time, holiday setting has the priority.
Page 222 Figure 4-157 Figure 4-158 4.11.5.2 Display It is to set display, TV adjust, tour, zero-channel encode, and preview favorites information. 4.11.5.2.1 Display Display setup interface is shown as below. See Figure 4-159.
Page 223  Time display: You can select to display time or not when system is playback.  Channel display: You can select to channel name or not when system is playback.  Image original rate: Check the box here, the video can be displayed at its actual size. ...
Page 224  Delete: Click it to remove selected channel group.  Move up: Click it to move current selected channel up.  Move down: Click it to move current selected channel down.  Default: Click it to restore default setup. Tips: ...
Page 225  Bit Rate: The bit rate value may vary due to different device capabilities and frame rate setups. Please select from the dropdown list.  Save: Click the Save button to save current setup. If this function is disabled, you can not operate zero-channel encoding function at the WEB, the video is black or null even you operate when the function is disabled.
Page 226 Figure 4-162 Figure 4-163 Figure 4-164...
Page 227 4.11.5.4 PTZ The pan/tilt/zoom setup includes the following items. Please select channel first. See Figure 4-165.  PTZ type: There are two options: local/remote. Please select remote if you are connecting to the network PTZ. See Figure 4-166.  Control mode: You can select control mode from the dropdown list. There are two options: Serial/HDCVI.
Page 228 Figure 4-166 4.11.5.5 ATM/POS The ATM/POS function is for financial areas. It includes Sniffer, information analysis and title overlay function. The Sniffer mode is network. The network type interface is shown as below. See Figure 4-167. Here we take the ATM/POS protocol to continue. There are two types: with or without the protocol according to client’s requirements.
Page 229 Figure 4-167 Without the protocol For the ATM/POS without the protocol, the interface is shown as in Figure 4-168. Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. Usually you do not need to set source port and target port.
Page 230 4.11.5.6 Voice The audio function is to manage audio files and set schedule play function. It is to realize audio broadcast activation function. 4.11.5.6.1 File List Here you can add audio file, listen to the audio file, or rename/delete audio file. Here you can also set audio volume.
Page 231  In Figure 4-169, when it is USB mode, after you imported, you need to connect the USB device all the time; otherwise, the audio link function may fail. So, if you want to use the audio trigger function, please make sure the audio file is on the UBS device and the USB device has connected to the DVR before the DVR boots up.
Page 232 Figure 4-171 4.11.5.7.1 Add User Click modify user button in Figure 4-171 , the interface is shown as in Figure 4-172. Please input the user name, password, select the group it belongs to from the dropdown list. Then you can check the corresponding rights for current user. For convenient user management, usually we recommend the general user right is lower than the admin account.
Page 233 Figure 4-172 When you create a new user, you can input the corresponding MAC address of current user. If you leave this item in blank, any MAC address user can share this user account to login. Please note system needs to check the validity of MAC. Only the 12-digit 0-f format address can pass the validity verification. System only saves small character even you input capitalized one.
Page 234 Click Set button, you can set six periods in one day. See Figure 4-174. Check the box after the period, you can enable current setup. Figure 4-174 4.11.5.7.2 Modify user Click , you can go to the following interface to change user information. See Figure 4-175. For admin, 888888, and default (hidden user), you can not change period setup.
Page 235 4.11.5.7.3 Change Password In Figure 4-175, check the Modify password box, you can change password. Please input old password, and then input new password twice to confirm. The password can contain 32-byte and the space at the begin or at the end of the password are null. It can contain in the middle of the password.
Page 236 Figure 4-177 4.11.5.7.5 Security Question The security question is shown as below. See Figure 4-178. Here you can change security questions. Figure 4-178...
Page 237 4.11.5.8 Auto Maintain Here you can set auto-reboot time and auto-delete old files setup. You can set to delete the files for the specified days. See Figure 4-179. You can select proper setup from dropdown list. After all the setups please click save button, system goes back to the previous menu. Figure 4-179 4.11.5.9 Config Backup The configuration file backup interface is shown as below.
Page 238  If you go to the configuration backup interface first and then insert the peripheral device, please click Refresh button to view the newly added device. Figure 4-180 4.11.5.10 Default Click default icon, system pops up a dialogue box. You can highlight to restore default factory setup.
Page 239 Figure 4-181 4.11.5.11 Update Here is for you to view hardware features, software version, built date, release SN information and etc. You can also update system here. See Figure 4-182.  Start: Please insert the USB device that have the update file to the device and then click the Start button to begin the update.
Page 240 Figure 4-182...
Page 241: Login
5 WEB OPERATION Slightly difference may be found in the interface due to different series. 5.1 Network Connection Before web client operation, please check the following items:  Network connection is right  DVR and PC network setup is right. Please refer to network setup(main menu->Setting->Network) ...
Page 242: Lan Mode
5.3 LAN Mode For the LAN mode, after you logged in, you can see the main window. See Figure 5-3. Figure 5-3 This main window can be divided into the following sections.  Section 1: there are six function buttons: Live（chapter 5.4）, playback (chapter 5.10) setup (chapter 5.8), info (chapter 5.9), alarm (chapter 5.12), face search (5.11)and logout (chapter 0).
Page 243: Live
Please note, if audio input port from the device to the client-end is using the first channel audio input port. During the bidirectional talk process, system will not encode the audio data from the 1-channel. Figure 5-6  Section 4: Instant record button. Click it, the button becomes yellow and system begins manual record.
Page 244: Ptz
In section 2, left click the channel name you want to view, you can see the corresponding video in current window. On the top left corner, you can view device IP (10.15.6.144), channel number (1), network monitor bit stream (61Kbps) and stream type: M (Main stream)/S (Sub stream). See Figure 5-9. Figure 5-9 On the top right corner, there are six unction buttons.
Page 245: Image
Parameter Function  Select Tour from the dropdown list. Tour  Input preset value in the column. Click Add preset button, you have added one preset in the tour.  Repeat the above procedures you can add more presets in one tour.
Page 246: Wan Login
Figure 5-12 5.7 WAN Login In WAN mode, after you logged in, the interface is shown as below. See Figure 5-13. Figure 5-13 Please refer to the following contents for LAN and WAN login difference. 1) In the WAN mode, system opens the main stream of the first channel to monitor by default. The open/close button on the left pane is null.
Page 247: Setup
Figure 5-14 Important The window display mode and the channel number are by default. For example, for the 16- channel, the max window split mode is 16. 3) Multiple-channel monitor, system adopts extra stream to monitor by default. Double click one channel, system switches to single channel and system uses main stream to monitor.
Page 248 Figure 5-15 Figure 5-16 Please refer to the following sheet for log parameter information. Parameter Function Click Device search button, you can view the searched device Device information on the list. It includes device IP address, port, device search name, manufacturer and type. Select a device in the list and then click Add button, system can connect the device automatically and add it to the Added device list.
Page 249 Note:  System supports manufactures such as Panasonic, Sony, Dynacolor, Samsung, AXIS, Arecont, Dahua and Onvif standard protocol.  If you do not input IP address here. System uses default IP 192.168.0.0 and system does not connect to this IP.
Page 250 Figure 5-18 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Period It divides one day (24 hours) to two periods. You can set different hue, brightness, and contrast for different periods. It is to adjust monitor video brightness and darkness level.
Page 251 ranges from 40 to 60. Gain The gain adjust is to set the gain value. The smaller the value is, the low the noise is. But the brightness is also too low in the dark environments. It can enhance the video brightness if the value is high.
Page 252 video according to the device feature (The general bright of the video or there is IR light or not.)  B/W: The device outputs the black and white video.  Sensor: It is to set when there is peripheral connected IR light.
Page 253 Compression The main bit stream supports H.264. The extra stream supports H.264, MJPG. Select Start from the dropdown list to enable smart codec Smart Codec function. The DVR can auto reduce the video bit stream of the non-important surveillance object to save the storage space. System supports various resolutions, you can select from the Resolution dropdown list.
Page 254 set.  Trigger snapshot only is valid when motion detect alarm, tampering alarm or local activation alarm occurs. Image size It is the same with the resolution of the main stream. It is to set the image quality. There are six levels. Quality It is to set snapshot frequency.
Page 255 The storage path interface is shown as in Figure 5-22. Here you can set snap image saved path ( in the preview interface) and the record storage path in the preview interface).The default setup is C:\PictureDownload and C:\RecordDownload. Please click the Save button to save current setup. Figure 5-22 5.8.1.4 Channel Name Here you can set channel name.
Page 256: Network
Figure 5-24 5.8.2 Network 5.8.2.1 TCP/IP The TCP/IP interface is shown as in Figure 5-25. Figure 5-25 Please refer to the following sheet for detailed information. Parameter Function Mode There are two modes: static mode and the DHCP mode.  The IP/submask/gateway are null when you select the DHCP mode to auto search the IP.
Page 257 IP/submask/gateway from the DHCP.  If you switch from the DHCP mode to the static mode, you need to reset the IP parameters.  Besides, IP/submask/gateway and DHCP are read-only when the PPPoE dial is OK. Mac Address It is to display host Mac address. IP Version It is to select IP version.
Page 258 RTSP port The default value is 554. 5.8.2.3 WIFI Please note this function is for the device of WIFI module. The WIFI interface is shown as in Figure 5-27. Figure 5-27 Please check the box to enable WIFI function and then click the Search SSID button. Now you can view all the wireless network information in the following list.
Page 259 APN/Dial No. Here is the important parameter of PPP. Authorization It includes PAP,CHAP,NO_AUTH. Pulse interval It is to set time to end 3G connection after you close extra stream monitor. For example, if you input 60 here, system ends 3G connection after you close extra stream monitor 60 seconds.
Page 260 Figure 5-30 5.8.2.6 DDNS The DDNS interface is shown as in Figure 5-31. The DDNS is to set to connect the various servers so that you can access the system via the server. Please go to the corresponding service website to apply a domain name and then access the system via the domain.
Page 261 need to refresh the bonding relationship of the domain and the IP regularly. There is no user name, password or the ID registration on the server. At the same time, each device has a default domain name (Generated by MAC address) for your option. You can also use customized valid domain name (has not registered.).
Page 262 Figure 5-33 Please refer to the following sheet for detailed information. Parameter Function Please check the box here to enable email function. Enable Input server address and then enable this function. SMTP Server Port Default value is 25. You can modify it if necessary. Anonymity For the server supports the anonymity function.
Page 263 Parameter Function Please check the box here to enable this function. Health mail enable This function allows the system to send out the test email to Update period check the connection is OK or not. (interval) Please check the box to enable this function and then set the corresponding interval.
Page 264 Figure 5-35 Please refer to the following sheet for detailed information. Parameter Function Check the corresponding box to enable PAT function. Status Display UPnP function status. It is corresponding to the UPnP mapping information on the router. Check the box before the service name to enable current PAT service. Otherwise, the service is null.
Page 265 Figure 5-36 Please refer to the following sheet for detailed information. Parameter Function SNMP Port The listening port of the proxy program of the device. It is a UDP port not a TCP port. The value ranges from 1 to 65535. The default value is 161 It is a string.
Page 266 Figure 5-37 5.8.2.13 Auto Register The auto register interface is shown as below. See Figure 5-38. This function allows the device to auto register to the proxy you specified. In this way, you can use the client-end to access the DVR and etc via the proxy. Here the proxy has a switch function. In the network service, device supports the server address of IPv4 or domain.
Page 267 The P2P interface is shown as in Figure 5-40. Check the Enable box to enable P2P function and then click the Save button. Now you can view the device status and SN. Figure 5-40 5.8.2.16 HTTPS In this interface, you can set to make sure the PC can successfully login via the HTTPS. It is to guarantee communication data security.
Page 268 Figure 5-42 You can see the corresponding prompt. See Figure 5-43. Now the server certificate is successfully created. Figure 5-43 5.8.2.16.2 Download root certificate In Figure 5-41, click button, system pops up a dialogue box. See Figure 5-44. Figure 5-44 Click Open button, you can go to the following interface.
Page 269 Figure 5-45 Click Install certificate button, you can go to certificate wizard. See Figure 5-46. Figure 5-46 Click Next button to continue. Now you can select a location for the certificate. See Figure 5-47.
Page 270 Figure 5-47 Click Next button, you can see the certificate import process is complete. See Figure 5-48. Figure 5-48 Click Finish button, you can see system pops up a security warning dialogue box. See Figure 5-49. Figure 5-49...
Page 271: Event
Click Yes button, system pops up the following dialogue box, you can see the certificate download is complete. See Figure 5-50. Figure 5-50 5.8.2.16.3 View and set HTTPS port From Setup->Network->Connection, you can see the following interface. See Figure 5-51. You can see HTTPS default value is 443.
Page 272 Figure 5-52 Figure 5-53...
Page 273 Figure 5-54 Figure 5-55 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable motion detection function. Please select a channel from the dropdown list. Period Motion detection function becomes activated in the specified periods.
Page 274 Parameter Function to select a zone. The corresponding color zone displays different detection zone. You can click Fn button to switch between the arm mode and disarm mode. In arm mode, you can click the direction buttons to move the green rectangle to set the motion detection zone.
Page 275 Figure 5-56 5.8.3.1.3 Tampering The tampering interface is shown as in Figure 5-57. After analysis video, system can generate a tampering alarm when the detected moving signal reached the sensitivity you set here. For detailed setups, please refer to chapter 5.8.3.1.1 motion detect for detailed information. Figure 5-57 5.8.3.1.4 Diagnosis...
Page 276 System can trigger an alarm when the stripe, noise, color cast, out of focus, over exposure event occurred. See Figure 5-58. Figure 5-58 Click Set button, you can check the corresponding box to select diagnosis type. See Figure 5-59. Figure 5-59 Note Video diagnosis alarm can trigger PTZ preset, tour, and pattern.
Page 277 System generates an alarm once there is any object crossing the tripwire in the specified direction. Figure 5-60 Check the Tripwire box to enable tripwire function. Select SN (Line1/2/3/4) and direction, and then input customized rule name.  No. and Line1/2/3/4: System supports four tripwires. Each SN stands for one tripwire. ...
Page 278 Click to draw filter object. See Figure 5-62. Figure 5-62 Select the blue line and then use mouse to adjust zone size. Note Each rule can set two sizes (min size/max size). Once the object is smaller than the min size or larger than the max size, there is no alarm.
Page 279 Figure 5-63 Check the Intrusion box to enable intrusion function. Select SN (Area1/2/3/4) and direction, and then input customized rule name.  No. and Area1/2/3/4: System supports four zones. Each SN stands for one zone.  Direction: There are three options: A->B, B->A, both. System can generate an alarm once there is any object enter/exit (Or both) the zone.
Page 280 Figure 5-64 For detailed setups, please refer to chapter 5.8.3.1.1 motion detect for detailed information. 5.8.3.2.3 Object Detect Note:  The object detection function is valid once your network camera or your DVR supports this function.  If your purchased DVR supports the object detection function, it supports one analog channel. It is not for the digital channel.
Page 281 Figure 5-65 Check the Object box to enable object detect function. Select SN (object1/2/3/4) and rule type, and then input customized rule name.  No. and Object1/2/3/4: System supports four zones. Each SN stands for one zone.  Rule type: Please select from the dropdown list. There are two types: Missing object detect/abandoned object detect.
Page 282 Figure 5-66 Now you can draw a rule. Left click mouse to draw a line, until you draw a rectangle, you can right click mouse. Click Ok to complete the rule setup. For detailed setups, please refer to chapter 5.8.3.1.1 motion detect for detailed information. 5.8.3.3 Face Detect (Optional) The face detection function is optional.
Page 283 For detailed setups, please refer to chapter 5.8.3.1.1. Figure 5-67 5.8.3.4 Alarm Before operation, please make sure you have properly connected alarm devices such as buzz er. The input mode includes local alarm and network alarm. 5.8.3.4.1 Local Alarm The local alarm interface is shown as in Figure 5-68. It refers to alarm from the local device. Figure 5-68...
Page 284 Figure 5-69 Figure 5-70 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable this function. Please select a channel from the dropdown list. Period This function becomes activated in the specified periods. There are six periods in one day.
Page 285 Parameter Function System can delay the record for specified time after alarm Record Delay ended. The value ranges from 10s to 300s. Alarm out Enable alarm activation function. You need to select alarm output port so that system can activate corresponding alarm device when an alarm occurs.
Page 286  HDD includes: No disk, disk error, disk no space.  Network includes net disconnection, IP conflict, and MAC conflict.  User: It includes illegal login. Figure 5-72 Figure 5-73...
Page 287 Figure 5-74 Please refer to the following sheet for detailed information. Parameter Function Event The abnormal events include: No disk, disk error, disk no space, net Type disconnection, IP conflict and MAC conflict. You can set one or more items here. Less than: You can set the minimum percentage value here (For disk not space only).
Page 288: Storage
Parameter Function Buzzer Check the box here to enable this function. The buzzer beeps when an alarm occurs. Check the box here, system can record the network event alarm log. 5.8.4 Storage 5.8.4.1 Schedule In this interfaces, you can add or remove the schedule record/snapshot setup. See Figure 5-75. There are three record modes: general (auto), motion detect and alarm.
Page 289 Figure 5-77 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Pre-record Please input pre-record time here. The value ranges from 0 to 30. Redundancy Check the box here to enable redundancy function. Please note this function is null if there is only one HDD.
Page 290 Figure 5-78 5.8.4.3 Record The interface is shown as in Figure 5-79. Figure 5-79 Please refer to the following sheet for detailed information. Parameter Function Here you can view channel number. Channel The number displayed here is the max channel amount of your device.
Page 291: Setting
Check the corresponding All button, you can enable or disable all Start all/ channels record. stop all 5.8.5 Setting 5.8.5.1 General The general interface includes general, date/time and holiday setup. 5.8.5.1.1 General The general interface is shown as in Figure 5-80. Figure 5-80 Please refer to the following sheet for detailed information.
Page 292 Figure 5-81 Please refer to the following sheet for detailed information. Parameter Function Here you can select date format from the dropdown list. Date format There are two options: 24-H and 12-H. Time Format The time zone of the device. Time zone It is to set system time.
Page 293 Figure 5-82 5.8.5.2 Display Display interface includes GUI, TV adjust, Tour and zero-channel encoding. 5.8.5.2.1 Display Here you can set background color and transparency level. See Figure 5-83. Figure 5-83 Please refer to the following sheet for detailed information. Parameter Function There are four options: Resolution...
Page 294 Figure 5-84 Please refer to the following sheet for detailed information. Parameter Function Check the box here to enable tour function. Enable tour Here is for you to adjust transparency. The value ranges from 5 to Interval 120s. The default setup is 5s. Here you can set window mode and channel group.
Page 295 Please select from the dropdown list. The value ranges from 1- Frame rate 25(PAL) or 1-30(NTSC). Please select from the dropdown list. Bit rate 5.8.5.3 Video Matrix The interface is shown as in Figure 5-86. Here you can set video output channel and interval. Figure 5-86 Parameter Function...
Page 296 Delete channel group Select a channel group and then click ,you can delete it. Modify channel group Select a channel group and then double click, you can see the following interface. See Figure 5-88. You can change the setup and then click OK button. Figure 5-88 5.8.5.4 PTZ The PTZ interface is shown as in Figure 5-89.
Page 297 Parameter Function HDCVI. The control signal is sent to the PTZ via the coaxial cable. For the serial mode, the control signal is sent to the PTZ via the RS485 port. Please select corresponding protocol from the dropdown list. Protocol Set corresponding dome address.
Page 298 Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. Usually you do not need to set source port and target port. There are total four groups IP. The record channel applies to one group (optional) only. Six frame ID groups verification can guarantee information validity and legal.
Page 299 Add user: It is to add a name to group and set the user rights. See Figure 5-93. There are three default users: admin/888888 and hidden user “default”. Hidden user “default” is for system interior use only and can not be deleted. When there is no login user, hidden user “default”...
Page 300 Figure 5-94 5.8.5.6.2 Group The group management interface can add/remove group, modify group password and etc. The interface is shown as in Figure 5-95. Figure 5-95 Add group: It is to add group and set its corresponding rights. See Figure 5-96. Please input the group name and then check the box to select the corresponding rights.
Page 301 Figure 5-96 Modify group Click the modify group button, you can see an interface is shown as in Figure 5-97. Here you can modify group information such as remarks and rights. Figure 5-97 5.8.5.7 Auto maintain The auto maintain interface is shown as in Figure 5-98.
Page 302 Here you can select auto reboot and auto delete old files interval from the dropdown list. If you want to use the auto delete old files function, you need to set the file period. Click Manual reboot button, you can restart device manually. Figure 5-98 5.8.5.8 Import/Export The interface is shown as in Figure 5-99.
Page 303: Information
Please select the upgrade file and then click the update button to begin update. Please note the file name shall be as *.bin. During the upgrade process, do not unplug the power cable, network cable, or shutdown the device. Important Improper upgrade program may result in device malfunction! Figure 5-101 5.9 Information...
Page 304: Online User
Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type operation, event operation, record operation, user management, log clear. Set the start time of the requested log. Start time Set the end time of the requested log.
Page 305: Playback
5.10 Playback Click Playback button, you can see an interface is shown as in Figure 5-106. Figure 5-106 5.10.1 Search Record Please set record type, record date, window display mode and channel name.  Select Date You can click the date on the right pane to select the date. The green highlighted date is system current date and the blue highlighted date means it has record files.
Page 306: File List
Figure 5-108 Now you can select one or more channel(s) and then click to search record(s). System supports one or more channels. The window split mode can auto adjust according to the channel amount. System max supports 16-split. Click button to select all channels at the same time. Click , system begins playback.
Page 307: Playback
Figure 5-110 5.10.3 Playback Select a file you want to play and then click Play button, system can begin playback. You can select to playback in full-screen. Please note for one channel, system can not playback and download at the same time.
Page 308: Load More
Figure 5-111 5.10.5 Load more It is for you to search record or picture. You can select record channel, record type and record time to download. Or you can use watermark function to verify file. 5.10.5.1 Download By File Select channel, record type, bit stream type and then input start time and end time. Click Search button, the download by file interface is shown as in Figure 5-112.
Page 309 Click Download to local, system pops up the following interface for you to set record format and saved path.See Figure 5-113. Figure 5-113 You can click OK to download and view the download process. After the download operation, you can see corresponding dialog box.
Page 310: Face Search
Figure 5-115 Set record format and saved path, you can click OK to download and view the download process. After the download operation, you can see corresponding dialog box. 5.10.5.3 Watermark Watermark interface is shown as In Figure 5-116. Please select a file and then click Verify button to see the file has been tampered with or not Figure 5-116 5.11 Face Search...
Page 311: Alarm
Figure 5-117 Please refer to the following sheet for detailed information. Name Function Display It is to display human face detection file list. The latest file is at the  top. \  Click Export, you can export the selected file to the USB device. There are two types: image/record.
Page 312: Log Out
Figure 5-118 Please refer to the following sheet for detailed information. Type Parameter Function Alarm Video loss System alarms when video loss occurs. Type Motion detection System alarms when motion detection alarm occurs. Tampering System alarms when camera is viciously masking. Disk full System alarms when disk is full.
Page 313: Un-Install Web Control
Figure 5-119 5.14 Un-install Web Control You can use web un-install tool “uninstall web.bat” to un-install web control. Please note, before you un-installation, please close all web pages, otherwise the un-installation might result in error.
Page 314: Professional Surveillance System
6 Professional Surveillance System Besides Web, you can use our Smart PSS to login the device. For detailed information, please refer to Smart PSS user’s manual.
Page 315: Faq
7 FAQ 1. DVR can not boot up properly. There are following possibilities:  Input power is not correct.  Power connection is not correct.  Power switch button is damaged.  Program upgrade is wrong.  HDD malfunction or something wrong with HDD ribbon. ...
Page 316 6. Can not search local records. There are following possibilities:  HDD ribbon is damaged.  HDD is broken.  Upgraded program is not compatible.  The recorded file has been overwritten.  Record function has been disabled. 7. Video is distorted when searching local records. There are following possibilities: ...
Page 317  When there are several decoders, please add 120 Ohm between the PTZ decoder A/B cables furthest end to delete the reverberation or impedance matching. Otherwise the PTZ control is not stable.  The distance is too far. 12. Motion detection function does not work. There are following possibilities: ...
Page 318  Data amount exceeds backup device capacity. It may result in burner error.  Backup device is not compatible.  Backup device is damaged. 17. Keyboard can not control DVR. There are following possibilities:  DVR serial port setup is not correct ...
Page 319 24. When I login via HTTPS, a dialogue says the certificate for this website is for other address. Please follow chapter 5.8.2.16.1 to create server certificate. 25. When I login via HTTPS, a dialogue says the certificate is not trusted. Please follow chapter 5.8.2.16.2 to download root certificate.
Page 320: Appendix A Hdd Capacity Calculation
Appendix A HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte.
Page 321: Appendix B Compatible Backup Device List
Appendix B Compatible Backup Device List Compatible USB drive list NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. If you use the USB drive, please confirm the format FAT or FAT32. Manufacturer Model Capacity...
Page 322 Netac U228 Compatible SD Card List Please refer to the following sheet for compatible SD card brand. Brand Standard Capacity Card type Transcend SDHC6 16GB Kingston SDHC4 Kingston Kingston Sandisk SDHC2 Micro-SD Sandisk Micro-SD Compatible Portable HDD List Please refer to the following sheet for compatible portable HDD brand. Brand Model Capacity...
Page 323 Seagate Seagate SV35.1 ST3250824SV 250G SATA Seagate Seagate SV35.1 ST3500641SV 500G SATA Seagate Seagate SV35.2 ST3250820SV 250G SATA Seagate Seagate SV35.2 ST3320620SV 320G SATA Seagate Seagate SV35.2 ST3500630SV 500G SATA Seagate Seagate SV35.2 ST3750640SV 750G SATA Seagate Seagate SV35.3 ST3250310SV 250G SATA Seagate...
Page 324 Seagate Seagate ST2000NM0031 SATA Constellation ES Seagate Seagate ST1000NM0031 SATA Constellation ES Seagate Seagate ST500NM0031 500G SATA Constellation ES Seagate Seagate ST2000NM0051 SATA Constellation ES Seagate Seagate ST1000NM0051 SATA Constellation ES Seagate Seagate ST500NM0051 500G SATA Constellation ES Seagate Seagate ST33000650NS SATA Constellation ES.2...
Page 325 Westem WDAV-GP—AVCS WD2500AVCS 250G SATA Digital Westem WDAV-GP—EVCS WD10EVCS-63ZLB0 SATA Digital Westem WDAV-GP—EVCS WD20EVCS-63ZLB0 SATA Digital Westem WDAV-GP—AVVS WD3200AVVS-63L2B0 320G SATA Digital Westem WDAV-GP—AVVS WD5000AVVS-63ZWB0 500G SATA Digital Westem WDAV-GP—AVVS WD7500AVVS-63E1B1 750G SATA Digital Westem WDAV-GP—AVVS WD7500AVVS-63E1B1 750G SATA Digital Westem WDAV-GP—EVVS WD10EVVS-63E1B1...
Page 326 Maxtor DiamondMax 20 STM3320820AS 320G SATA Maxtor DiamondMax 20 STM3250820AS 250G SATA...
Page 327: Appendix C Compatible Cd/Dvd Device List
APPENDIX C Compatible CD/DVD Device List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. And you can use the USB cable with the model recommended to set USB burner. Manufacturer Model Port Type Type Sony...
Page 328: Appendix D Compatible Displayer List
Appendix D Compatible Displayer List Please refer to the following sheet for the compatible device brand. Brand Model Dimension (Unit: inch) BENQ（LCD） ET-0007-TA 19-inch (wide screen) DELL（LCD） E178FPc 17-inch BENQ（LCD） Q7T4 17-inch BENQ（LCD） Q7T3 17-inch LENOVO（LCD） LXB-L17C 17-inch SANGSUNG（LCD） 225BW 22-inch (wide screen) HFNOVO (CRT) LXB-FD17069HB...
Page 329: Appendix E Compatible Switcher List
Appendix E Compatible Switcher List Please refer to the following sheet form compatible switcher list. Brand Model Network Working Mode D-LinK DES-1016D 10/100M self-adaptive D-LinK DES-1008D 10/100M self-adaptive There are five network modes： 1、AUTO 2、HALF-10M Ruijie RG-S1926S 3、FULL-10M 4、HALF-100M 5、FULL-100M H3C-S1024 10/100M self-adaptive TP-LINK...
Page 330: Appendix Fcompatible Wireless Mouse List
Appendix F Compatible Wireless Mouse List Please refer to the following sheet for compatible SD card brand. Brand Model Rapoo 3500 Logitech M215 Shuangfeiyan Tianyao G7-630 Note:  This manual for reference only. Slight difference may be found in the user interface. ...

Dahua HCVR7416L User Manual

Quick Links

Related Manuals for Dahua HCVR7416L

Summary of Contents for Dahua HCVR7416L

Table of Contents
