Please refer to the following sheet for detailed information.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
The 16-channel series rear panel is shown as below. See Figure 2-52.
Figure 2-51
Video input
Video output
Audio input
Audio Output
Video VGA output
Alarm input/alarm output
Power on-off button
GND port
Power socket
RS-485 port
Network port
USB port
HDMI port
Video SPOT output
