2Hdd 2Cif 1U Series - Dahua Smart Box Series User Manual

Please refer to the following sheet for detailed information.
1
2
3
4
5
6
7
8
9
10
11

2.2.19 2HDD 2CIF 1U Series

The 4/8-channel series rear panel is shown as below. See Figure 2-53.
Please refer to the following sheet for detailed information.
1
2
3
4
5
6
7
8
Figure 2-52
Video input
Video/audio SPOT output
Video VGA output
Alarm input/alarm output
GND port
Power on-off button
Power socket
RS-485 port
Network port
HDMI port
USB port
Figure 2-53
Video input
Video output
Audio input
Audio Output
Video VGA output
RS232 port
Alarm input/alarm output
Power on-off button
Standalone DVR User's Manual
109
