2.2.7 960H Smart 1U /2CIF Smart 1U Series
Here we take 960H smart 1U series as an example. See Figure 2-27 through Figure 2-29.
Figure 2-25
Figure 2-26
Video input
USB port
HDMI Port
Network port
Power socket
Video VGA output port
GND port
On/off button
