4.3 Navigation Bar
4.3
4.3
4.3
Navigation Bar
Navigation Bar
Navigation Bar
You need to go to the Main menu->Setting->System->General to enable navigation
bar function; otherwise you can not see the following interface.
The navigation bar is shown as below. See Figure 4-7.
4.3.1 Main Menu
Click button
4.3.2 Output Screen
Select corresponding window-split mode and output channels.
4.3.3 Favorites
Click
, system pops up the favorites schemes. Click one item, you can view saved
favorite channel split mode and channel number. See Figure 4-8.
Please note, right now the favorite scheme name after the window split mode.
Figure 4-6
Figure 4-7
to go to the main menu interface.
Figure 4-8
Standalone DVR User's Manual
135
