Table of Contents

Advertisement

Goods Checking ............................................................................................................................................... 4
Device and accessory checking ........................................................................................... 4
Power supply .................................................................................................................................. 4
1.
Quick guide ..................................................................................................................................... 4
1.1.
How to add and change the setting of the camera ........................................................................ 5
1.2.
How to install HDD ...................................................................................................................... 5
1.3.
Cable connection .......................................................................................................................... 6
2.
Connect to the ground ............................................................................................................... 7
2.1.
How to Change the password ............................................................................................... 8
2.2.
How to Close the HDD buzzer .............................................................................................. 9
2.3.
Startup Wizard ............................................................................................................................ 10
2.4.
How to use Navigation Bar ................................................................................................... 14
2.5.
Main Menu .................................................................................................................................... 14
2.6.
Dual-screen operation ................................................................................................... 15
2.7.
Output Screen ................................................................................................................... 15
2.8.
Tour ........................................................................................................................................ 15
2.8.1
PTZ ......................................................................................................................................... 15
2.8.2
Color ....................................................................................................................................... 15
2.8.3
Search ................................................................................................................................... 15
2.8.4
Alarm Status ....................................................................................................................... 15
2.8.5
Remote Device ................................................................................................................. 16
2.8.6
Network ................................................................................................................................. 16
2.8.7
2.8.10 HDD Manager ................................................................................................................... 16
2.8.8
2.8.11 USB Manager .................................................................................................................... 16
2.8.9
How to Add the account and set the right .................................................................... 16
How to Add/Modify Group ........................................................................................... 18
Add/Modify User .............................................................................................................. 19
2.9
How to Change the date, time and time zone .................................................. 20
2.9.1
How to Use the Remote Controller .................................................................................. 21
2.9.2
How to add and change the setting of the camera? ................................................................... 23
2.9.3
NVR/HCVR IP address setting........................................................................................... 23
2.10
How to add the camera .......................................................................................................... 23
3.
How to add camera(s) in a quick way(Smart add) ................................................... 25
3.1.
How to set the Resolution of camera .............................................................................. 28
3.2.
How to set the bit rate of camera ...................................................................................... 28
3.3.
How to set the audio of camera ......................................................................................... 29
3.4.
How to set the image parameters of camera .............................................................. 30
3.5.
How to set the motion detect of camera ........................................................................ 31
3.6.
How to set the Tripwire of camera ................................................................................... 32
3.7.
How to set the intrusion of camera .................................................................................. 34
3.8.
3.9.
How to set the scene change of camera ...................................................................... 38
3.10.
How to set the face detect of camera ............................................................................. 39
3.11.
How to set the audio detect of camera .......................................................................... 40
3.12.
How to change the camera name..................................................................................... 41
3.13.
Preview .............................................................................................................................................................. 43
3.14.
3.15.
4.
1
DAHUA NVR FULL MANUAL
Contents

Advertisement

Table of Contents
loading

Summary of Contents for Dahua NVR4216-16P-4

  • Page 1: Table Of Contents

    DAHUA NVR FULL MANUAL Goods Checking ............................... 4 Contents Device and accessory checking ................... 4 Power supply ..........................4 Quick guide ............................. 4 1.1. How to add and change the setting of the camera ................ 5 1.2. How to install HDD ........................5 1.3.
  • Page 2 How to change the display resolution and adjust the image value ....43 How to adjust the order of the splits ................44 How to switch from different splits ..................45 How to set tour ........................... 45 How to set the Favorite Cameras ..................45 How to set mask ........................
  • Page 3 How to set Idle Function and call ..................93 How to set Privacy Masking and call ................94 How to use Keyboard to control PTZ ................95 Event and Activation..........................100 How to set video recording activation ................103 Explain IPC ext, IPC offline, Net alarm, HDCVI alarm, IVS alarm, Video loss, Tampering How to set Snapshot activation ..................
  • Page 4: Goods Checking

    1. Goods Checking 1.1. Device and accessory checking Be sure to use all the accessories recommended by manufacturer. Before installation, please open the package and check all the components are included. Normally accessories include user manual, mouse, Power cable, Power adapter, CD, Network cable, Screw package.
  • Page 5: How To Add And Change The Setting Of The Camera

    2. How to add and change the setting of the camera 2.1. How to install HDD Important: Please turn off the power before you replace the HDD. The pictures listed below for reference only. For the first time install, please be aware that whether the HDDs have been installed. Please use HDD of 7200rpm or higher.
  • Page 6: Cable Connection

    back. panel. 2.2. Cable connection The NVR42-8P series rear panel is shown as below. See Figure 2-1. Figure 2-1 Please refer to the following sheet for detailed information. Name Function Input DC 12V/5A. For NVR42 series product only. Switch power port. Input DC 48//1.04A. Power input For NVR42-P series product only.
  • Page 7: Connect To The Ground

    Name Function  There are two types; NO (normal open)/NC (normal close). Alarm input port  When your alarm input device is using 1~4 1~4 external power, please make sure the device and the NVR have the same ground. Alarm input ground port. ...
  • Page 8: How To Change The Password

    ○ Ground Connect device to the ground via metal cable to prevent device damaged by static electricity. 2.4. How to Change the password In modify interface, check the modify password box and then input old password and new password. Input new password again to confirm the modification.The default administrator user name is admin and the password is admin.
  • Page 9: How To Close The Hdd Buzzer

    1) Input old password and new password and confirm the modification. 2) Click the OK button to save the settings. Figure 2-2 ① ② 1) Enable “Modify Password”. peration Steps are as below: 2) Input old password and new password and confirm the modification. 3) Click the save button to save the setttings ③...
  • Page 10: Startup Wizard

    ① ② ③ ④ peration Steps are as below: 1) Choose No HDD 2) Unable the function 3) Unable the buzzer 4) Click the save button, Figure 2-4 2.6. Startup Wizard After device successfully booted up, it goes to startup wizard. Click Cancel/Next button, you can see system goes to login interface.
  • Page 11 ① Figure 2-5 Click Smart add, Cancel button or Next button, system goes to login interface. See Figure 2-6. System consists of four accounts:  Username: admin. Password: admin. (administrator, local and network)  Username: 888888. Password: 888888. (administrator, local only) ...
  • Page 12 Figure 2-7 Click Next button, you can go to network interface. See Figure 2-8. Figure 2-8 Click Next button, you can go to remote device interface. See Figure 2-9.
  • Page 13 Figure 2-9 Click Next button, you can go to Schedule interface. See Figure 2-10. Figure 2-10 Click Finish button, system pops up a dialogue box. Click the OK button, the startup wizard is complete. See Figure 2-11.
  • Page 14: How To Use Navigation Bar

    Figure 2-11 2.7. How to use Navigation Bar You need to go to the Main menu->Setting->System->General to enable navigation bar function; otherwise you can’t see the following interface. ① Figure 2-12 Click and enable the Navigation Bar The navigation bar is shown as below. See Figure 2-13. Figure 2-13 2.8.
  • Page 15: Dual-Screen Operation

    Click button to go to the main menu interface. 2.8.1 Dual-screen operation Important This function is for some series only. Click to select screen 2, you can view an interface shown as below. See Figure 2-14. It is a navigation bar for screen 2. Figure 2-14 Click any screen split mode;...
  • Page 16: Remote Device

    Figure 2-2 2.8.8 Remote Device Click , system goes to the remote device interface. 2.8.9 Network Click , system goes to the network interface. It is to set network IP address, default gateway and etc. 2.8.10 HDD Manager , system goes to the HDD manager interface. It is to view and manage HDD Click information.
  • Page 17 For account management please note:  For the user account name and the user group, the string max length is 6-byte. The backspace in front of or at the back of the string is invalid. There can be backspace in the middle.
  • Page 18: How To Add/Modify Group

    ① ② 1) Here you can modify the group created. Figure 2-18 2) Here you can add the group. 2.9.1 How to Add/Modify Group Click add group button, the interface is shown as below. See Figure 4-152. Here you can input group name and then input some memo information if necessary. There are many rights such as control panel, shut down, real-time monitor, playback, record, record file backup, PTZ, user account, system information view, alarm input/output setup, system setup, log view, clear log, upgrade system, control device and etc.
  • Page 19: Add/Modify User

    ① ② ③ Figure 2-4 peration Steps are as below: 1) Input group name and then input some memo information if necessary 2) Check the corresponding rights for current group. 3) Click the Save Button to save the settings. 2.9.2 Add/Modify User Click add user button, the interface is shown as in Figure 2-20.
  • Page 20: How To Change The Date, Time And Time Zone

    ① ② ③ Figure 2-20 peration Steps are as below: 1) Input the user name, pass word, select the group it belongs to from the dropdown list. 2) Check the corresponding rights for current user. 3) Click the Save Button to save the settings. 2.9.3 How to Change the date, time and time zone From Main menu->Setting->System->General, you can go to the general interface.
  • Page 21: How To Use The Remote Controller

    ② ① ③ ⑤ ④ ⑥ Figure 2-21 peration Steps are as below: 1) Select the date format. 2) Choose the time format. 3) Select the denotations. 4) Set the time zone 5) Set system time 6) Click the Save Button to save the settings. 2.10 How to Use the Remote Controller The remote controller is the optional device, the specific operation can refer to the table below:...
  • Page 22 Power ○ ○ Speed play ○ Slow play ○ Next button ○ Previous button ○ Play /Suspend ○ Playback/Suspend ○ Cancel ○ Record ○ Direction key ○ Enter /Menu ○ Multi-screen ○ Auxiliary button ○ Numeric button ○ ○ ○...
  • Page 23: How To Add And Change The Setting Of The Camera

    3. How to add and change the setting of the camera? 3.1. NVR/HCVR IP address setting From main menu->Setting->Network->TCP/IP, the interface is shown as below. Figure 3-1 Operation Steps: Choose IP version. There are two options: IPv4 and IPv6. Input IP address, subnet mask, default gateway. If there is a DHCP client in the LAN, you can enable DHCP.
  • Page 24  Manual add Operation Steps: 1) Click Manual Add button; 2) Select the manufacturer. Please choose Private if the NVR connect camera of Dahua. 3) Set IP address, Port, User name, Password. 4) Click Connect to test whether linked or not.
  • Page 25: How To Add Camera(S) In A Quick Way(Smart Add)

    Figure 3-3 3.3. How to add camera(s) in a quick way(Smart add) When the network camera(s) and the NVR are in the same router or switch, smart add function can be used to add all network cameras to the NVR at the same time. Operation Steps: 1) On the preview interface, right click mouse and then select Smart add.
  • Page 26 2) Click smart add button, device enables DHCP function. Figure 3-5 3) Confirm IP information if there are several IP segments in the following interface.
  • Page 27 Figure 3-6 4) System will auto adding IPC to the corresponding channels. Figure 3-7 5) After system successfully added network cameras, the following dialog box can be seen. Figure 3-8...
  • Page 28: How To Set The Resolution Of Camera

    3.4. How to set the Resolution of camera From Main menu->Setting->Encode->Encode, you can see the following interface. You can set the parameter of camera in this page. Figure 3-9 Operation Steps: 1) Enter Encode page. 2) Select the resolution. The mainstream resolution type is IPC’s encoding config. Generally there is D1/720P/1080P.
  • Page 29: How To Set The Audio Of Camera

    Figure 3-10 Operation Steps: 1) Select a channel from the dropdown list. 2) Select suitable bit rate (Kb/s). System supports two types: CBR and VBR. In VBR mode, video quality can be set up. 3) Click “OK” to save settings. 3.6.
  • Page 30: How To Set The Image Parameters Of Camera

    Figure 3-11 Operation Steps: 1) Select a channel from the dropdown list. 2) You can enable or disable the video/audio. Please note, once you enable audio function for one channel, system may enable audio function of the rest channels by default. 3) Click “OK”...
  • Page 31: How To Set The Motion Detect Of Camera

    Figure 3-12 Operation Steps: 1) Select a channel from the dropdown list. 2) Select a config file. The options includes: day/night/general/switch by period. Once the mode is switch by period, sunset and sunrise time can be set up. 3) Monitor window bright, contrast, saturation, sharpness can be set up by Changing values.
  • Page 32: How To Set The Tripwire Of Camera

    Figure 3-13 Operation Steps: 1) Select a channel from the dropdown list, then click “Enable” button. 2) Working period setting, default it all day. 3) Click “Set” of Region. Select the area to enable or disable motion detect. 4) If alarm Out is enabled, it will trigger alarm out when it occurs. It is the same with the setting of MD.
  • Page 33 The interface is as below. Figure 3-14 Operation Steps: 1) Click “Enable” button, the default rule name is line 1, line 2, line 3, line 4 when adding rule, it is ok to modify the rule name. 2) Working period setting, default it all day. 3) Click “Rule Setup”...
  • Page 34: How To Set The Intrusion Of Camera

    Figure 3-15 4) Select one of the following directions: A->B , A<-B , A<->B and it is to judge if it will trigger intelligent alarm when tripwire happens according to the selected direction. 5) Support alarm activation setup: record, alarm out, send email , PTZ activation, tour and snapshot.
  • Page 35 Figure 3-16 Operation Steps: 1) Click “Enable” button, the default rule name is area 1, area 2, area 3 and area 4 when adding rule. 2) Working period setup, default is all day. 3) Click “Rule Setup” and draw a warning area in the image according to the actual needs, it will trigger alarm when the target is crossing the warning area perimeter according to the set movement direction.
  • Page 36: How To Set The Object Abandoned/ Object Missing Of Camera

    Figure 3-17 4) Select detection action list, the direction can be set as: enter , leave bidirectional 5) Working period setting, default is all day. 6) Support alarm activation setup: record, alarm out, send email , PTZ activation, tour and snapshot.
  • Page 37 Figure 3-18 Operation Steps: 1) Click “Enable”, the default rule name is object1, objet 2, object 3 and object 4 when adding rules, users can modify the rule name. 2) Working period setup, default is all day. 3) Click “Rule Setup” and select “Object Abandoned” or “Object missing”...
  • Page 38: How To Set The Scene Change Of Camera

    Figure 3-19 4) Set min last time(Period), which means the stay time or disappear time of target when triggering alarm. 5) Draw a detection area. As for object abandoned, it will trigger alarm when the abandoned object surpasses the time set by users in the monitoring scene; As for object missing, it will trigger alarm when the moved object surpasses the time set by users in the monitoring scene.
  • Page 39: How To Set The Face Detect Of Camera

    Figure 3-20 Operation Steps: 1) Select a channel from the dropdown list. 2) Click “Enable”. 3) Working period setup, default is all day. 4) Support alarm activation setup: record, relay-out, send email and snapshot. 3.13. How to set the face detect of camera From main menu->Setting->Event->Face detect, the interface is shown as below.
  • Page 40: How To Set The Audio Detect Of Camera

    Figure 3-21 Function Description: Face detection is to detect if there is any human face appearing in the video, and capture the face then send it to the rear-end for analysis and processing, it can activate snapshot, record and alarm. Operation Steps: 1) Select a channel from the dropdown list, then click “Enable”.
  • Page 41: How To Change The Camera Name

    Figure 3-22 Function Description: Audio Input Abnormity is to judge if audio input is abnormal, such as clipping audio cable by people. It can activate record, snapshot and alarm according to the results. Operation Steps: 1) Click “Input Abnormity Enable” or “ Intensity Change Enable”.
  • Page 42 Figure 3-23 It is to modify channel name. The maximum amount of channels depends on NVR model. Please note you can only modify the channel name of the connected network camera.
  • Page 43: Preview

    4. Preview 4.1 How to change the display resolution and adjust the image value Figure 4-1 Figure 4-2 Right click the GUI, and then menu->image, you can change the saturation, brightness, contrast, sharpness etc of a specific channel. You also can change the Day&Night settings, ...
  • Page 44: How To Adjust The Order Of The Splits

    Figure 4-3 Figure 4-4 Main Menu->Setting->System->Display, you can go to the following interface, Figure 4-3. Here you can set display resolution. Please note the system needs to reboot to activate  current setup. On the web service, click the SETTING ->SYSTEM ->DISPLAY to change the resolution, see Figure 4-4.
  • Page 45: How To Switch From Different Splits

    4.3 How to switch from different splits Figure 4-5 Right click on the preview GUI, and then you can click the Menu to choose the view model and split you want as follow. See Figure 4-5. 4.4 How to set tour Figure 4-6 Login the device with username and password, and then click the button SETTING ->SYSTEM ->DISPLAY->TOUR.
  • Page 46: How To Set Mask

    Note: Favorites is only available on HCVR74XXL, HCVR78XXS, HCVR5424/32L (-S2), HCVR5824/32S (-S2), DVR7X series and used to save the current layout of the splits. You need to go to the Main menu->Setting->System->General to enable navigation bar function first and then set the favorites. The navigation bar is shown as below.
  • Page 47: How To Open Audio

    Figure 4-10 It is to zoom in specified zone of current channel. It supports zoom in function of multiple- channel. Click button , the button is shown as , see Figure 4-10. Right click mouse system restores original status. There are two ways for you to zoom in. 1) Drag the mouse to select a zone 2) Put the middle button at the centre of the zone you want to zoom in, and move the mouse...
  • Page 48: How To Enable The Zero-Channel

    Figure 4-12 Note: Please insert the USB memory first. In preview GUI, click the snapshot button to save it in the external USB memory, which is shown in the following figure. 4.10 How to enable the zero-channel Figure 4-13 For HCVR/DVR, click System -> Display -> Zero Channel, you can Enable it and select the information, see Figure 4-13.
  • Page 49: How To Set Corridor Mode

    Figure 4-14 Please note you can get the zero-channel image only on the web service (see Figure 4-14) and NVR/HCVR/DVR will not able to record it in HDD. 4.11 How to set corridor mode Figure 4-15 Please rotate the IP camera in Clockwise 90 on DVR/HCVR/NVR (disabled by default) by Menu->image value->...
  • Page 50: How To Use Pip (Picture In Picture)

    Figure 4-16 Then enable the ‘original scale’ on Menu->System->Display (see Figure 4-16), you will see a corridor image in preview. 4.12 How to use PIP (picture in picture) Figure 4-17 Figure 4-18...
  • Page 51: How To Use The Second Hdmi

    Note:This function is available only on DVR7XXX series and HCVR74XXL, HCVR78XXS, HCVR5424/32L (-S2), HCVR5824/32S (-S2). It is to overlay one picture on another picture in 1-window mode. 1) Right click and select “View PIP” in the Menu. You can switch the position of the large window and the small window.
  • Page 52: Hdd

    5. HDD HDD Requirements Please refer to the hard disk selection lists: 1) For HCVR: http://www.dahuasecurity.com/download/20150826ethnwl.pdf 2) For NVR: http://www.dahuasecurity.com/download/20150522gwjext.pdf 3) For DVR: http://www.dahuasecurity.com/download/20150522mejgew.pdf How to check the HDD information 5.1.1 HDD type 1) From Main menu->Setting->Storage->HDD Manager, you can go to HDD management interface.
  • Page 53: How To Do Hdd Detect

    Figure 5-2 Figure 5-3 Note:S.M.A.R.T means Self-Monitoring Analysis and Reporting Technology. S.M.A.R.T technology can conclude hard disk failure condition and give prompt information by detecting hard disk's attributes, such as data throughput performance, the motor starting time, seek error rates and other attribute values. 5.1.3 How to do HDD detect...
  • Page 54 1) From Main menu->SETTING->STORAGE->HDD DETECT, you can go to HDD DETECT interface. 2) Choose different detect type and detailed hard disk. 3) Click Start Detect button, detecting process is shown as in Figure 5-4 4) Click Report button 5) Click checking button to know the detailed information shown as in Figure 5-7 Figure 5-4 Figure 5-5...
  • Page 55 Figure 5-6...
  • Page 56: How To Set Hdd Group Setting

    Figure 5-7 5.2 How to set HDD group setting HDD group setup for main stream, sub stream and snapshot operation. The HDD group mode is shown as Figure 5-8. 1) HDD: Here you can view the HDD amount the device can support. 2) Group: It lists the HDD Group number of current hard disk.
  • Page 57: How To Set Raid 5

    Redundancy: System supports redundancy backup function. It allows you backup recorded file in two disks. Please note this function is null if there is only one HDD. Showing as Figure 5-10. 2) Highlight Redundancy button to activate this function. Showing as Figure 5-11. 1) Please set at least one HDD as redundant.
  • Page 58 3) Checking the status 4) Double click to see the detailed information...
  • Page 59 5) Hot Spare disk setting Note: Global for all Raid group.Local for special Raid group, we can add this hotspare HDD for only Raid.
  • Page 60: Recording

    For the encode function , the main stream we can set three different stream type.We have “MD” ”Alarm” ”Regular” different type for different stream type. These different type settings only support with Dahua IP cameras. Also, we have the sub-stream settings from the IPC. All the settings can be set as the second encoding option for the channel.
  • Page 61 ① ② ③ Figure 6-2 1) Auto: System enables auto record function as you set in schedule interface (General/Motion detect/Alarm) 2) Manual: It has the highest priority. Enable corresponding channel to record no matter what period applied in the record setup. Now system is record general file. 3) Off: Stop current channel record/Snapshot no matter what period applied in the record setup.
  • Page 62: Recording-Schedule (Normal, Md And Alarm)

    6.3 Recording-Schedule (Normal, MD and Alarm) 6.3.1 How to set Pre-recording We can find the menu on “SETTING”-“STORAGE”-“SCHEDULE”, as figure 6-3 shows. ② ③ ① Figure6-3 1) Choose the channel we want to set. 2) Set the time that we want to pre-recording, and then we can get the recording of this time before the event start up.
  • Page 63 We can find the menu on “SETTING”-“SYSTEM”-“GENERAL”, as figure 6-4 shows. ③ Figure 6-4 1: Click it we can modify the holiday, then we can get the interface as Figure 6-5 shows; 2: Click it we can close or open holiday; 3: Click it we can add new holiday.
  • Page 64: How To Set Redundant Option

    ② Figure6-6 Figure 6-7 1) Choose the event that we want to set Holiday recording; 2) Click it we can get the interface like the Figure 6-7 shows; 3) There are six periods that we can choose to set; 4) Click it we can choose the trigger event; 5) Choose ALL, we can apply the settings to everyday.
  • Page 65 If there are more than 2 SATAS, We can set one of the SATA as the Redundant HDD and another is Redundant. There are 4 types that we can choose: Read Write; Read-only; Redundant; Format. We can find the menu on “SETTING”-“STORAGE”-“SCHEDULE”, as figure 6-8 and figure 6-9 shows.
  • Page 66: How To Set Md Recording Plan

    2) If we want to set redundant, we must enable it. 3) Click Apply. 4) Set the type of the SATA. 5) Click Apply. 6.3.4 How to set MD recording plan We can find the menu on “SETTING”-“EVENT”-“VIDEO DETECT”, as figure 6-10. Figure 6-10 1) Choose the channel we want to record.
  • Page 67 Figure 6-11...
  • Page 68: How To Set Alarm Recording Plan

    Figure 6-12 6.3.5 How to set alarm recording plan We can find the menu on “SETTING”-“STORAGE”-“SCHEDULE”, as Figure 6-13 shows. ① ② ③ Firstly we must enable Alarm. Figure 6-13 Click it we can remove period. Click it we can set period. Click , we will get into timing setup interface, as Figure 6-14 shows.
  • Page 69 Figure 6-14 We can find the menu on “SETTING”-“ALARM”-“EVENT”, as Figure 6-15 shows. Figure 6-15 1) Choose the channel we want to set. 2) Choose” Enable” to enable alarm. 3) Click button “SETTING” behind “Period” to set alarm period. We will see the menu like Figure 6-16 shows.
  • Page 70: How To Set Snapshot Plan

    Figure 6-16 1) We can set the period by "setting" or Directly modified in time point as Figure 6-17 shows. Figure 6-17 6.4 How to set snapshot plan We can find the menu on “SETTING”-“ENCODE”-“Snapshot”, as Figure 6-18 shows.
  • Page 71 1) There are Timing and Trigger can be choosed, if we set the mode Timing, system will snapshot Figure 6-18 by time. if we set the mode Trigger, system will snapshot by EVENT. 2) Click it we can choose the image side that we want to get. 3) Click it we can choose the image quality leavel.
  • Page 72 Figure 6-20 1) Click it we can set the Snapshot of the VIDEO DETECT.  ALARM ① Figure 6-21 1) Click it we can set the Snapshot of the ALARM.
  • Page 73: How To Record Into Ftp

    6.5 How to record into FTP We can find the menu on “SETTING”-“FTP”-“NETWORK”, as Figure 6-22 shows. Figure 6-22 1) Choose the channel we want to set. 2) Please input the FTP server, for example: IP: 10.15.5.100, Port: 21. 3) We can set username by this way, for example: username: 1. 4) We can set password by this way, for example: password: 1.and if we don’t want to set it we can choose Anonymous.
  • Page 74: Playback And Backup

    7 Playback and Backup 7.1 How to search and playback 1) From Main menu->Search, or on the preview interface right click mouse and then select search item, you can go to the following interface(Figure 7-1) Figure 7-1 2) Two ways to search records,refer to Figure 7-1 2.1) Calendar: The blue highlighted date on calendar means there is picture or file.
  • Page 75: How To Make The Sync Playback

    Figure 7-3 3) Then you could use playback control pane and time bar to control the process of playback. 7.2 How to make the sync playback Enable the before play the records. The records of the channels selected would be played synchronously.
  • Page 76: How To Playback The Mark Video

    Figure 7-4 1) During the multiple-channel playback mode, dblclick a window to choice one channel. 2) Click this button , then the image of this channel will gridding. 3) Press the left button and drag the mouse to choice the smart zone. 4) Click this button , this channel will play motion detect video, or it’ll prompt that “there’s no motion detect data in current region”.
  • Page 77 Figure 7-5 layback Marked record During windo...
  • Page 78: How To Playback With Ivs(Face Detection)

    playback mode, click mark file list button, you can go to mark filelist interface. Figure 7-6 Double click one mark file, you can begin playback from the mark time. 7.7 How to playback with IVS(face detection) Firstly you need enable the IVS and the FACE DETECT function and set recording schuedule for IVS .
  • Page 79: How To Playback With Splicing

    NOTE IVS and face detection supporting models : NVR6XX-4K,NVR724-256, NVR4XXX-4K 7.8 How to playback with splicing This function improves the video query efficiency significantly. For example, if you choose 1 hour, 4 channel playback video, you can see it in only 15minutes. Channel 1 from 0 to 15minute.
  • Page 80: How To Make The Video Cut And Back Up

    Figure 7-8 NOTE: The minimum interval is 5 minutes in each channel. If the time interval is 10-15 minutes, it will be 2 splits; if 16-20,3 splits; above 20,4 splits. Model supporting splicing playback HCVR5X04-V2,HCVR5X08-V2, HCVR5X16-V2,HCVR7X04-V2, HCVR7X08-V2 HCVR4X04-S2, HCVR4X08-S2, HCVR4X16-S2, HCVR5X04-S2, HCVR5X08-S2, HCVR5X16-S2, HCVR7X04-S2, HCVR7X08-S2 NVR6XX-4K 7.9 How to make the video cut and back up...
  • Page 81: How To Lock The Recording Files

    Figure 7-10 1) select start time by time cursor,click Clip 2) select end time by time cursor,click Clip, 3) click to backup record to USB flash 7.10 How to lock the recording files...
  • Page 82: How To Make Quick Backup

    Figure 7-11 Search record by file,selectfile,click to lock this record,Click to view locked files list and unlock file. Note: Locked file can not be overwriting any more. 7.11 How to make quick Backup...
  • Page 83: How To Make Web Backup

    Figure 7-12 Click enable playback in full screen,click ,system will inform you to save a snapshot to the specified path. 7.12 How to make web backup Two ways for web backup Quick backup 1) Download by time...
  • Page 84 Figure 7-13 Click ,type start and end time,click save menu to backup record to local path ,default path is C:\RecordDownload 3) Download by file: Select Files,click begin to download record local disk. Figure 7-14 Advanced backup : Click to go to advanced download operations 1) Download by file,search record with channel/Type/stream type/Start and end time,begin to download to Local or USB.
  • Page 85: How To Use Smart Player

    2) Download by time,selectChannel,stream type ,start time and end time,download to local disk,Record format is DAV and ASF optional Figure 7-16 7.13 How to use smart player Download SmartPlayer from Dahua WEB page, http://www.dahuasecurity.com/download_2.html Smart Player interface is as below...
  • Page 86 Figure 7-17 Add File to Play Window Preview,splicesplayback,Player can devide one file into several parts,playback these parts in different windows synchronously. Export file to other format,JPG/BMP/DAV/AVI is optional Digital zoom when play video Drag video to different windows Play video in full screen Sequence play Sync play,enable,different channels will play synchronous with same time bar.
  • Page 87: Ptz

    For HDCVI PTZ: Note: HDCVI (High Definition Composite Video Interface) is an over-coaxial-cable analog HD video transmission standard which is submitted by Dahua Technology. The technology composites video, audio and PTZ signals together and have them transmitted over coaxial cable.
  • Page 88 1. Channel: Select the current camera channel. 2. PTZ type: There are two types: local/remote. Please select local mode if you are connect RS485 cable to connect to the Speed dome (PTZ). Please select remote mode if you are connecting to the network PTZ camera.
  • Page 89: How To Operate Ptz Control

    Figure 8-5 8.3 How to Operate PTZ Control Right click mouse (or click “Fn” Button in the front panel or click “Fn” key in the remote control). The interface is shown as in Figure 8-6. Please note you can only go to the PTZ control interface when you are in 1-window display mode.
  • Page 90 Please note the commend name is grey once device does not support this function. Figure 8-7 Here you can control PTZ direction, speed, zoom, focus, iris, preset, tour, scan, pattern aux function, light and wiper, rotation and etc. Speed is to control PTZ movement speed. The value ranges from 1 to 8.The speed 8 is faster than speed 1.
  • Page 91: How To Set Up Preset And Call

    Figure 8-9 Please refer to the following sheet for detailed information. Please note the above interface may vary due to different protocols. The button is grey and cannot be selected once the current function is null. Right click mouse or click the ESC button at the front panel to go back to the Figure 8- Icon Function Icon...
  • Page 92: How To Set Tour And Call

    Click in Figure 8-9, you can go to the following interface to set preset, tour, pattern, and scan. See Figure 8-9. Figure 8-10 In Figure 8-10, click preset button and use eight direction arrows to adjust camera to the proper position. The interface is shown as in Figure 8-11. Click Set button and then input preset number.
  • Page 93: How To Set Pattern And Call

    Tips Repeat the above steps to add more presets to the tour. Click Del preset button to remove it from the tour. Please note some protocols do not support delete preset function. Figure 8-12 In the interface shown as Figure 8-9, enter the Tour number and click call.
  • Page 94: How To Set Privacy Masking And Call

    Figure 8-14 Select Function setting-Idle motion, the interface is as shown in Figure 8-15: Figure 8-15 1. Enable the idle function 2. Select the time to activate the idle function 3. Select the type of idle function: preset, scan, tour, pattern 4.
  • Page 95: How To Use Keyboard To Control Ptz

    Figure 8-16 Enter the privacy masking function as it is shown in Figure 8-17 Figure 8-17 Enter the setting interface and it is shown in Figure 8-18 Figure 8-18 In the interface of Figure 8-18, use “←” to select the arrow to choose the direction and use “enter” to expand and narrow the masking: ↑: Expand vertically ↓: Narrow vertically...
  • Page 96 Figure 8-19 For NKB1000: Netwo Figure 8-20 Keyboard Operation Tips: Use the joystick on keyboard to move up/down/left/right to select items. Use keyboard to input number or character to set parameters. Click【ENTER】to confirm current operation. Click【ESC】to exit. 2. Set Keyboard to match with NVR For NKB1000, Network Connection: Go to NKB1000 Menu –...
  • Page 97 After successful connection, the interface is shown as below. See Figure 8-23. Figure 8-23 The lens movement supports 8 directions. It includes: up/down/left/right/top left/top right/bottom left/bottom right. Please use the joystick to control. Iris/Zoom/Focus On the keyboard, click 【IRIS】 button, use button 【+】and【-】or turn joystick up/down to control the iris.
  • Page 98 Figure 8-25 How to use keyboard to set Scan 1) Select Set and then click 【ENTER】, you can see an interface shown as in Figure 8-26. Figure 8-26 2) Select left limit and right limit, click 【ENTER】 to set. 3) Use joystick to control PTZ to set limit. How to use keyboard to Start and Stop Scan Select start and then click 【ENTER】,system begins to scan according to the left/right ...
  • Page 99 Figure 8-28 How to use keyboard to set Tour a) Select set item, the interface is shown as in Figure 8-29. Figure 8-29 b) Input a value at the tour No. c) Add preset to the tour.  Select preset No. and then input a preset number. ...
  • Page 100: Event And Activation

    9 Event and Activation 9.1 Explain IPC ext, IPC offline, Net alarm, HDCVI alarm, IVS alarm, Video loss, Tampering 9.1.1 What is IPC External alarm Figure 9-1 This is the alarm signal from IPC local alarm in. 9.1.2 What is IPC Offline alarm Figure 9-2 This alarm will be triggered if there’s IPC dropping off.
  • Page 101 Figure 9-3 This alarm signal is from network. Generally it is an VMS and some network alarm generator. 9.1.4 What is HDCVI alarm Figure 9-4 This alarm signal is from HDCVI camera alarm input. HDCVI solution will transmit the alarm signal via coaxial cables. Notes, it only works on HDCVI recorders.
  • Page 102 Figure 9-5 1) It is an alarm signal triggered by rules on IVS ( tripwire, intrusion, object, scene change and can activate the local NVR/HCVR. Figure 9-5 shows the location of IVS alarm. 9.1.6 What is Video loss alarm Figure 9-6 1) System alarms when video image does not showing but camera connects.
  • Page 103: How To Set Video Recording Activation

    Figure 9-7 System alarms when camera is viciously masking. When someone viciously masks the lens, or the output video is in one-color due to the environment light change, the system can alert you to guarantee video continuity. 9.2 How to set video recording activation...
  • Page 104 ① Figure 9-8 1) Set Alarm schedule in STORAGE-SCHEDULE-Record (The pre-record is the extra record time before alarm triggered.) Figure 9-9 2) Go to storage->record, set to Auto. Only in auto mode it works as your schedule setup.
  • Page 105: How To Set Snapshot Activation

    Figure 9-10 3) Go to setting-> Camera-> Encode->Encode, choose Code-Stream Type to Alarm, if you want to set the recording of alarm different from regular recordings. Figure 9-11 4) Enable Record Channel in EVENT, Record Delay is the recording time after the event finished.
  • Page 106 Figure 9-12 1) Set Alarm schedule in STORAGE-SCHEDULE-Snapshot Figure 9-13 2) Enable Record- Snapshot in STORAGE-RECORD...
  • Page 107: How To Set Alarm Upload

    Figure 9-14 Go to Camera->Encode->snapshot, select Mode to Trigger, and set the snapshot frequency, during alarm active. 9.4 How to set Alarm upload 9.4.1 Set Alarm Center...
  • Page 108 ① ② ③ ④ Figure 9-15 1) Enable Alarm Server in SETTING-NETWORK-ALARM SERVER 2) Set Host IP to the IP of your Alarm server 3) Set port, you can set any port according to your situation. Please confirm the port is usable and not be occupied 4) Set the report time 5) Then “Apply”...
  • Page 109: How To Set Email Upload

    ① ② ③ Figure 9-16 1) Enable the Motion Detect 2) Enable Alarm Upload 3) Apply and OK to save 9.5 How to Set Email Upload 9.5.1 Set Email...
  • Page 110 ① ② ③ ④ ⑤ ⑥ Figure 9-17 Enable: Check the box to enable the Email Setting in SETTING-NETWORK SMTP server and port: Input the SMTP server of sender mail box, e.g.,smtp.126.com or IP address of the smtp server. Generally the port is 25. User name and password: The username and password of the sender mailbox.
  • Page 111 ① ② ③ Figure 9-18 Choose the correct channel to Enable “Motion Detection” in SETTING-EVENT-VIDEO DETECTION Enable “Send Email” Enable “Snapshot” if you want to get snapshot of the channels when motion occurs Notes, If you want to get snapshot in email when motion detected. Do following steps...
  • Page 112: How To Set Up Ptz Activation

    ① Figure 9-19 1) Enable Snapshot in SETTING-STORAGE-RECORD ② Figure 9-20 2) Set Motion snapshot schedule in SETTING-STORAGE-SCHEDULE-Snapshot 3) Set the Snapshot Encode setting in SETTING-REMOTE-AUDIO/VIDEO-Snapshot 9.6 How to set up PTZ activation...
  • Page 113: How To Set Up Easy Space

    Figure 9-21 1) Tick the box of PTZ Activation in the Alarm setup page Figure 9-22 Click Setup, it’s viable to trigger Preset, Tour and Pattern of the PTZ camera, and enter the number of that Preset. Please Apply when you finishing the setting. 9.7 How to set up Easy Space...
  • Page 114: How To Set The Local Alarm In/Out

    Figure 9-23 1) Go to Setting -> Network -> Easy Space, put in your Dropbox/Skydrive username and password and enable this function. Click Apply when finishing the setting. Figure 9-24 2) Go back to the event settings, tick the box of Easy Space of Snapshot/Record Channel. Once the alarm is triggered, the snapshot/video will be uploaded to Dropbox/Skydrive.
  • Page 115: Alarm Setup On Nvr/Hcvr/Dvr

    Alarm input: 1. NO: triggered by short circuit Alarm and Ground. 2. NC: triggered by disconnect Alarm and Ground. Alarm output: 1. NO: when alarm is active, the NO and Ground will short circuit 2. NC: when alarm is active, the NC and Ground will disconnect. 9.8.2 Alarm Setup on NVR/HCVR/DVR.
  • Page 116 ① ② ③ ④ ⑤ ⑥ ⑦ Figure 9-25 Choose the alarm index which corresponding the number in the physical interface of alarm 1) Enable local alarm. 2) Choose the alarm in type, Normal Open or Normal Close 3) Setup the alarm schedule 4) Anti-dither: The minimum time between 2 alarm input.
  • Page 117: Network Connection

    IP information. Besides, when PPPoE is operating, you can`t modify IP/Subnet mask /Gateway. ① Figure 10-1 10.2 How to use P2P DMSS DMSS (DAHUA Mobile Phone Surveillance software) is a good mobile platform monitoring software specially designed for security field. It is built on traits of mobile device...
  • Page 118 to include functions of multiple touch control, touch signal recognition, alarm push, P2P function, DDNS analysis and etc. User can preview, control PTZ, play video and etc. from front-end camera, DVR, and speed dome, under 3G, 4G and WIFI environments. Android: Open Google Play app in your smart phone.
  • Page 119 How to use 1)Open app, you will see Live Preview interface. ① Figure 10-2 2)Click the button and open the main menu.
  • Page 120 ③ ② Figure 10-3 Figure 10-4 3)Click on the device manage to add or delete devices. 4)Click on the plus button to add devices.
  • Page 121 ④ Figure 10-5 Figure 10-6 5)Click and add devices through P2P. 6)Input the device SN or scan the QR code. 7)Check the live preview state depend on the front-end device. 8)Save and finish. 9)Start live preview. Then you can specify some channels to start/end live preview (video/audio) and do some operations, such as snapshot, recording to local, talk, etc.
  • Page 122: How To Set Ddns

    You can also use P2P function on smart PSS. ② ① Figure 10-7 1)Open devices interface, click on the manual add. 2)Choose register mode, input the SN, add device. 10.3 How to set DDNS Device IP is not fixed if you use ADSL to login the network. The DDNS function allows you to access the NVR via the registered domain name.
  • Page 123: How To Use Smart Pss To Connect

    2)Click NETWORK and DDNS item. 3)Enable the function and choose a DDNS type. Please note DDNS type includes: Dahua DDNS, NO-IP DDNS, CN99 DDNS, Dyndns DDNS and Sysdns DDNS. All the DDNS can be valid at the same time, you can select as your requirement.
  • Page 124 ① Figure 10-9 Step1. Click devices in the settings pane, system goes to the device manager interface; you can see an interface is shown as below. ② ③ Figure 10-10 Step2. Choose the device you want, click Add button.
  • Page 125: How To Use Config Tool

    ④ ⑤ Figure 10-11 Step3. After you added new devices, return to the home page, click live view button in the settings pane, you can go to the live view interface. Then drag the devices to the screen directly, and continue to operate other functions. After installation completes, double click on ConfigTool, system pops up the software 10.5 How to use Config tool interface as below.
  • Page 126 If your device and the PC where ConfigTool is installed are in the same segment, then ConfigTool will automatically search devices and display devices it finds in device list. Double click IP address of the device or click , system pops up login progress bar as below Manually Login Interface If the device is not displayed in device list of ConfigTool, then you can manually input its IP, Figure 10-13...
  • Page 127: How To Use Ie/Chrome/Safari

    Figure 10-15 ConfigTool supports viewing device real time monitoring, setting video effect, network parameter, encoding parameter and upgrade. Figure 10-16 In our latest version of ConfigTool, we can use batch operation functions like config, modify IP and upgrade. For more information, please refer to config User’s Manual at top-right corner. 10.6 How to use IE/Chrome/Safari...
  • Page 128 After the device connect to the PC or the network,you can input the IP directly in the browser to open the web client or use ConfigTool to login. The operating interfaces of different browsers are the same. Figure 10-17 IE login interface, recommend to use IE9 or above. Figure 10-18(Chrome 43.0.2357.132)...
  • Page 129 Figure 10-19(Safari 5.1.7) First time using, the browser will let you install the plug-in. Figure 10-20 Download and install, restart browser. Then you will enter the normal interface.
  • Page 130: Device Information And Upgrade

    11 Device information and upgrade 11.1 NVR upgrade 11.1.1 USB upgrade 1) Plug the USB disk which included with the upgrading file into the device. 2) From the SETTING ->SYSTEM ->UPGRADE, click Upgrade button, select upgrade file through USB device to begin update. Figure 11- 1 11.1.2 network upgrade 1) Login the web of the device...
  • Page 131 Note: you can also use configtool to do network upgrading. 1) You can download the configtool from the website of Dahua 2) Login the configtool to search the device, and click the button to login the device. 3) Click upgrade to see the interface as showed in Figure 11- 5.
  • Page 132 Figure 11- 4 Figure 11- 5...
  • Page 133: Ipc Upgrade With Nvr

    1) From SETTING ->CAMERA ->REMOTE ->Upgrade, showing as Figure 11-6. 11.2 IPC upgrade with NVR 2) Choose the camera and file to upgrade. Figure 11- 6 1) From Main-manual->Info->Version, you will see the NVR firmware version. 11.3 NVR and IPC information checking...
  • Page 134 Figure 11- 7 Figure 11- 8 Image above shows the info of IPC. Under the CAMERA->REMOTE->Firmware, there is the IPC’s info, including IPC’s channel, status, IP address, port, device name etc. 10FAQ, Onvif information and third part vms list...
