Using SCXI Channel Strings with
Traditional NI-DAQ (Legacy) 7.0
or Later
Note This appendix is not applicable if you use the virtual channels to configure and
measure the SCXI channels. Virtual channels are configured using MAX. If you use virtual
channels, you address the SCXI channels by specifying the channel name(s) in the channel
string input.
© National Instruments Corporation
When using LabVIEW, and Visual Basic, the SCXI channel string
determines which SCXI channels are scanned and the scanning sequence.
The SCXI channel string allows you to take measurements from several
channels on one module with only one channel string entry. An array of
these channel string entries configures multiple modules for scanning.
When the application program runs, the channel string is used
for programming the channel information into the SCXI system.
The format of the channel string is as follows:
ob x ! sc y ! md z ! channels
where
• is the onboard E/M Series DAQ device channel, with
ob x
representing a particular channel where the multiplexed channels are
sent. This value is 0 for E/M Series DAQ device channel 0 in a
single-chassis system. In a multichassis or remote chassis system, the
E/M Series DAQ device channel
– 1, where E/M Series DAQ device channel
n
the nth chassis in the system.
• is the SCXI chassis ID, where
sc y
configuring the chassis.
• is the slot position where the module is located, with
md z
particular slot number. The slots in a chassis are numbered from left to
right starting with 1.
corresponds to chassis number
x
is the number you chose when
y
B-1
B
x
is used for scanning
x
being the
z
SCXI-1125 User Manual
