Other Application Documentation and Material

Traditional NI-DAQ (Legacy) CVI Examples

Traditional NI-DAQ (Legacy) Measurement Studio Examples

© National Instruments Corporation
After parallel mode has been configured in software, you can scan the
SCXI-1125 channels by entering the corresponding E Series DAQ device
channels or a sequential SCXI channel string in the channel parameter in
the analog input application. You can also enter virtual channels; however,
in parallel mode, virtual channels containing CJC are disabled in MAX.

C and Parallel Mode

When using a C-based ADE, you need no special steps for configuring the
chassis, the SCXI-1125, or the E Series DAQ device for parallel scanning.
You still have to configure the gain and filter settings by using
and
SCXI_Set_Gain
E Series DAQ device analog input functions to get the data from the eight
channels of the SCXI module. After scanning, convert the binary data to
voltage data by using
SCXI_Scale.
additional information on parallel scanning of SCXI modules.
Refer to the ADE manual and the DAQ analog input examples that
come with your application software for more detailed information on
programming the SCXI modules for scanning in multiplexed mode.
Many example programs ship with NI-DAQ. For more example
information on how to create tasks and channels, refer to the example
programs. By default, the example programs are installed in
Files\National Instruments\CVI x . x \Samples
are installed by default in
Instruments\NI-DAQ\Examples
Many example programs ship with NI-DAQ. For more example
information on how to create tasks and channels, refer to the example
programs. By default, the example programs are installed in
Files\National Instruments\Measurement Studio 7.0
examples are installed by default in
Instruments\NI-DAQ\Examples
SCXI_Configure_Filter
Refer to the NI-DAQ User Manual for
C:\Program Files\National
.
C:\Program Files\National
.
5-29
Chapter 5 Using the SCXI-1125
. You can use any of the
C:\Program
. More examples
C:\Program
. More
SCXI-1125 User Manual
