CALIBRATION PROCEDURE
™
SCXI
-1125
™
For NI-DAQ
mx
Contents

Conventions

»
Note
This icon denotes a note, which alerts you to important information.
This document contains information and instructions for calibrating the
National Instruments SCXI-1125 signal conditioning module.
Conventions ............................................................................................ 1
Software .................................................................................................. 2
Documentation ........................................................................................ 2
Calibration Interval ................................................................................. 3
Password ................................................................................................. 3
Test Equipment ....................................................................................... 3
Test Conditions ....................................................................................... 3
Calibration Process ................................................................................. 4
Initial Setup...................................................................................... 4
Verification Procedure ..................................................................... 5
Adjustment Procedure...................................................................... 10
Verifying Adjusted Values .............................................................. 12
Test Limits .............................................................................................. 13
Gain and Offset ................................................................................ 13
SCXI-1125 Front and Rear Panel Diagrams........................................... 15
World Wide Support and Services.......................................................... 18
The following conventions are used in this document:
The » symbol leads you through nested menu items and dialog box options
to a final action. The sequence File»Page Setup»Options directs you to
pull down the File menu, select the Page Setup item, and select Options
from the last dialog box.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCXI-1125 and is the answer not in the manual?

Questions and answers

Related Manuals for National Instruments SCXI-1125

Summary of Contents for National Instruments SCXI-1125

  • Page 1: Table Of Contents

    Adjustment Procedure..............10 Verifying Adjusted Values .............. 12 Test Limits ....................13 Gain and Offset ................13 SCXI-1125 Front and Rear Panel Diagrams........... 15 World Wide Support and Services............18 Conventions The following conventions are used in this document: »...

  • Page 2: Software

    You can access these documents by selecting Start»All Programs» National Instruments»NI-DAQmx after installing NI-DAQmx. For more information about the SCXI-1125, refer to the SCXI-1125 User Manual. For information about installing and configuring SCXI modules, refer to the SCXI Quick Start Guide.

  • Page 3: Calibration Interval

    • Keep relative humidity below 80%. • Allow a warm-up time of at least 15 minutes for the SCXI-1125 and 30 minutes for the DAQ device to ensure that the measurement circuitry is at a stable operating temperature. © National Instruments Corporation...

  • Page 4: Calibration Process

    Verifying Adjusted Values—Perform another verification to ensure that the SCXI-1125 is operating within its test limits after adjustments. Initial Setup Complete the following steps to configure the SCXI-1125 for calibration: Make sure that all the appropriate driver and application software is installed.
  • Page 5 Assemble the SCXI-1125, SCXI chassis, terminal blocks, and DAQ device as shown in Figure . You must cable the SCXI-1125 directly to the DAQ device. ® 1 SCXI-1320 Terminal Block 7 CB-50 Connector Block 2 SCXI-1125 Module 8 Cable to DMM...

  • Page 6: Verification Procedure

    You can use this information to select the appropriate calibration interval for your application. The SCXI-1125 stores gain and offset calibration constants for each gain setting per analog input channel. A complete verification of the inputs involves measuring the accuracy at all possible gain settings on all channels of the SCXI-1125.
  • Page 7 Complete the following steps to verify the accuracy of each SCXI-1125 analog input channel: Use the DAQmx Self Calibrate VI to verify the DAQ device. This VI measures the onboard reference voltage of the DAQ device and adjusts the self-calibration constants to account for any errors caused by short-term fluctuations in the operating environment.
  • Page 8 Where refers to the channel you are verifying. Set the SCXI-1125 to a gain setting that corresponds to the current test point in Table 2 using the DAQmx Channel Property Node. You can find the AI.Gain property by selecting Analog Input»General Properties»Advanced»Gain.
  • Page 9 For each new test point, use the Time Delay Express VI to account for the 5 second settling time. LabVIEW Block Diagram Function Call Call a function to suspend sleep wait execution for the necessary settling time. Delay Time: © National Instruments Corporation SCXI-1125 Calibration Procedure...

  • Page 10: Adjustment Procedure

    14. Repeat steps 4 through 13 for the remaining channels. 15. Repeat steps 3 through 14 for all test points in Table 2. You have finished verifying the analog input accuracy of the SCXI-1125. Adjustment Procedure The adjustment procedure adjusts the gain and offset calibration constants on the SCXI-1125.
  • Page 11 DAQmxInitExtCal parameters: deviceName: "SC1Mod1" password: "NI" calHandle: &calHandle Set the SCXI-1125 to a gain value listed in Table 3 using the DAQmx Setup SCXI Calibration VI. LabVIEW Block Diagram NI-DAQmx Function Call Call with the following DAQmxSetup1125Cal parameters: calHandle:...

  • Page 12: Verifying Adjusted Values

    10. Repeat steps 3 through 9 for all gain values in Table 3. 11. Repeat steps 2 through 10 for the remaining channels. You have finished adjusting the gain and offset of the SCXI-1125. Verifying Adjusted Values After calibrating the SCXI-1125, NI recommends that you verify the...

  • Page 13: Test Limits

    Table 2 contains the test limits to use when verifying the gain and offset of the SCXI-1125. Table 3 contains the set points for the adjustment. If the SCXI-1125 was calibrated within the last year, the test point value should fall between the Lower Limit and Upper Limit values found in Table 2.
  • Page 14 Limits valid for 4 Hz or 10 kHz filter settings. Valid when using an MIO device after performing an MIO internal calibration. Valid for both filter settings with 1,000 point averaging at 1,000 samples per second. SCXI-1125 Calibration Procedure ni.com...

  • Page 15: Scxi-1125 Front And Rear Panel Diagrams

    -0.00075 -0.0015 -0.00225 SCXI-1125 Front and Rear Panel Diagrams Table 4 shows the pin assignments for the SCXI-1125 front panel connector. Table 5 shows the pin assignments for the SCXI-1125 rear signal connector. © National Instruments Corporation SCXI-1125 Calibration Procedure...
  • Page 16 — — — RSVD — RSVD — — — RSVD — RSVD — — — +5 V — CJ TEMP — — — RSVD—Reserved CHS GND — RSVD NC—no connection — — — — no pin SCXI-1125 Calibration Procedure ni.com...
  • Page 17 39 40 — AI HOLD COMP, AI HOLD 41 42 43 44 SER CLK — 45 46 — — 47 48 — — 49 50 — — — SYNC — — — — © National Instruments Corporation SCXI-1125 Calibration Procedure...

  • Page 18: World Wide Support And Services

    For patents covering NI products/technology, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your media, or the National Instruments Patents Notice at ni.com/patents. You can find information about end-user license agreements (EULAs) and third-party legal notices in the readme file for your NI product.
