Specifications; Input Characteristics; Table A-1. Input Signal Range Versus Gain - National Instruments Module SCXI-1125 User Manual

Specifications

Input Characteristics

Refer to Tables 5-1 and 5-2 for extended range using the SCXI-1313A, SCXI-1327,
Note
and TBX-1316.
© National Instruments Corporation
This appendix lists the specifications for the SCXI-1125 modules. These
specifications are typical at 25 °C unless otherwise noted.

Table A-1. Input Signal Range Versus Gain

Overall Gain
1
2
5
10
20
50
100
200
250
500
1000
2000
Overall Voltage Range
±5 V or VDC
peak
±2.5 V or VDC
peak
±1 V or VDC
peak
±500 mV or VDC
peak
±250 mV or VDC
peak
±100 mV or VDC
peak
±50 mV or VDC
peak
±25 mV or VDC
peak
±20 mV or VDC
peak
±10 mV or VDC
peak
±5 mV or VDC
peak
±2.5 mV or VDC
peak
A-1
A
SCXI-1125
Gain
1
2
5
10
20
50
100
200
250
500
1000
2000
SCXI-1125 User Manual
