ELECTRONIC CONTROLS
Control Panel
FUNCTION
Turns power to ice maker on or off. Use to disable ice
maker during extended vacations.
Activates or deactivates max ice feature which increases
ice production 40% for a 24-hour period.
Adjusts tem per ature in one-degree increments. Com-
bination units have separate temperature controls for
refrigerator and freezer. Temper atures are preset at 3°C
and -18°C.
Activates or deactivates air purification system.
Activates or deactivates door alarm. An audible chime
indicates door has been left ajar for more than 60
seconds.
Turns unit on or off. When power is off, 'OFF' will appear
in control panel display. Turning power off at the control
panel eliminates the need to unplug or turn power off at
the circuit breaker during service or extended vacations.
Control panel and display (model ICBBI-30U shown).
Display
INDICATOR
Illuminates or flashes when electronic control system
has detected a temperature or ice maker problem, or if
condenser needs to be cleaned.
Illuminates when air purification system is activated and
flashes when cartridge needs to be replaced. After the
cartridge has been replaced, touch and hold
control panel for 5 seconds to reset.
Illuminates when water filtration system is activated and
flashes when filter needs to be replaced.
Illuminates when ice maker system is activated.
Illuminates when max ice feature is activated.
Illuminates when door alarm is activated.
STORAGE
Keeping Food At Its Best
This Sub-Zero features a unique dual refrigeration system to
keep food fresher longer.
With the Sub-Zero dual refrigeration system, individual
refrigerator and freezer systems have been designed to
maintain accurate, consistent temperatures and proper
humidity levels for longer food life expectancy. Dual refrig-
on the
eration eliminates transfer of fresh food odors to frozen food
and ice and does not freeze the moisture out of the air in the
fresh food section.
For handy tips and information on how to maximize
food freshness, refer to the freshness cards stored in the
refrigerator.
Refrigerator Storage

DOOR SHELVES

To remove a door shelf or the dairy compartment, lift from
the bottom and slide out. To reinstall, place in the desired
position and slide the shelf down onto the guides. Refer to
the illustration below.
If door opening is limited to 90°, door
IMPORTANT NOTE:
shelves may need to be removed before removing a storage
drawer or glass shelf.
Door shelf removal.
STORAGE DRAWERS
To remove a storage drawer, pull forward until the drawer
stops. Lift the front of the drawer slightly, then pull forward.
Refer to the illustration below.
For the French door model, drawer slides may need to be
pushed back manually to provide sufficient clearance for
removal.
To reinstall, push drawer slides in. Align the drawer with
slides and push back until it stops. Press down on the front
of the drawer to engage the slides.

GLASS SHELVES

To remove or adjust a glass shelf, tilt up, then lift up and out.
To reposition, insert shelf in the tracks along the back wall,
then lower the front until it locks into position. Refer to the
illustration below.
Use care when handling glass shelves to
IMPORTANT NOTE:
prevent breakage or scratching the interior.
CAUTION
Glass shelves should warm to room temperature before
immersing in warm water.
Storage drawer removal. Glass shelf removal.
subzero.com
|
3
