Installation
WARNING: It is essential that all installation work involving the suspension of these
loudspeaker products be performed by competent, knowledgeable persons who understand
safe rigging practices. Severe injury and/or loss of life may occur if these products are
improperly installed.
DANGER: It is essential that a safety cable (not supplied) be utilized whenever an ENTASYS
200 is mounted using the supplied Pan-Tilt Bracket. The safety cable must be secured to a
suitable load-bearing point on the wall or ceiling, with as little slack as possible so as not to
develop undue kinetic force if the Pan-Tilt Bracket were to fail.
FOR MORE INFORMATION
For applications support, service, or warranty information refer to Community's website, or contact
one of Community's TAG personnel (Technical Applications Group (tagteam@communitypro.com) at
800-523-4934 or 610-876-3400.

EXTERNAL HIGH-PASS FILTERS

It is required that an external high-pass filter of 24dB/octave (or steeper) be utilized with all
ENTASYS 200 systems. The small format, low frequency cone drivers are not capable of reproducing
high level low frequency information without damage. Recommended high-pass filter parameters are
shown below:
MODEL HI-PASS FREQUENCY
ENT203 150 Hz
ENT206 120 Hz
ENT212 100 Hz
ENT220 80 Hz
ENTASYS 200 Installation/Operation Manual — Page 13
FILTER SLOPE
(preferred)
24 db / octave
24 db / octave
24 db / octave
24 db / octave
