Community MVP37 Specifications

S (See notes 1 and 2)
PECIFICATIONS
MVP37
Specifications (See notes 1 and 2)
Loudspeaker Type: Two-way, Full-range
Operating Range: 60 Hz - 16 kHz
50 Hz - 14 kHz (+/-6dB)
Max Input Ratings:
400W continuous, 1000W Program
40 volts RMS, 89 volts momentary peak
Recommended Power Amplifier:
800W to 1200W @ 4 Ohms
Sensitivity 1W/1m:
98 dB SPL (63 Hz - 12500 Hz 1/3 octave bands)
98 dB SPL (250 Hz - 4 kHz speech range)
Maximum Output: 124 dB SPL / 131 dB SPL (peak)
Nominal Impedance: 4 Ohms
Min Impedance: 3.3 Ohms @ 40 Hz
Nominal -6dB Beamwidth:
90° H (+-12° / --44°, 2 kHz - 12.5 kHz)
40° V (+16° / --19°, 2 kHz - 12.5 kHz)
Axial Q / DI: 12.9 / 11.1, 2 kHz - 12.5 kHz
Crossover Frequency: 2 kHz
Recommended Signal Processing: None
Drivers: LF (2) 15"
HF (1) LM20™ Compression driver,
Non-metallic, Ferrofluid-cooled
Driver Protection: Thermal Link™
Input Connection: (2) Locking Connectors
(NL4MP compatible)
(2) 1/4 in. jacks
Controls: None
Enclosure: MDF
Enclosure Hardware: (2) Handles
(8) Corner protectors
Mounting / Rigging Provisions:(6) 5/16-18 hanging point inserts
Grille: 16 gauge perforated steel
Required Accessories: 60Hz High pass filter
Supplied Accessories: None
Optional Accessories: STRAPKIT: (3) steel straps for suspending
Dimensions: Height: 43 in. / 1092 mm
Width (front): 18 in. / 457 mm
Width (rear): 12 in. / 305 mm
Depth: 19 in. / 483 mm
Weight: 86 lb. / 42.5 kg
Shipping Weight: 97 lb. / 44 kg
1. Sensitivity: Free field pink noise measurement at 40 ft / 12.2 m at 50% power;
extrapolated to 1 meter and an input of 2 volts RMS.
2. Watts: All wattage figures are calculated using the rated nominal impedance.
333 East 5th Street, Chester, PA USA 19013-4511 TEL (610) 876-3400 FAX (610) 874-0190
TWO-WAY TRAPEZOIDAL LOUDSPEAKER WITH 90° X 40° HF HORN
COMMUNITY PROFESSIONAL LOUDSPEAKERS
www.loudspeakers.net
Specifications subject to change without notice.
MVP37
APPLICATIONS:
·
S R /P
· OUND EINFORCEMENT ORTABLE
C /DJ
· LUBS
B
ANDS
·
H W
· OUSES OF ORSHIP
P I
ERMANENT NSTALLATION
·
S F & H C
· PORT ACILITIES EALTH
R S
ENTAL YSTEMS
·
K
ARAOKE
FEATURES:
·
S P LED
IGNAL RESENT
·
T L ™ HF D P
· HERMAL INK RIVER
LM20™ L M F F
OW ASS ERRO LUID
·
H B MDF C
· EAVILY RACED ONSTRUCTION
T ¼" I C ,
WO NPUT ONNECTORS AND
·
R H
· ECESSED ANDLES
16 S G
GAUGE TEEL RILLES
D
ESCRIPTION
The MVP37 is a two-way, full-range loudspeaker system. Outfitted with
dual cast frame 15-inch drivers the enclosure's substantial low-end per-
formance allows the unit to easily provide full-bandwidth sound rein-
forcement without the use of subwoofers, while its overall height is such
that it can effortlessly project over the tops of crowds. Central to the
MVP37 is a bass-ported design and a one-piece 90x40 lrge format
molded horn section housing Community's new proprietary LM20™
compression driver.
Just like all he other MVP Series, the MVP37 offers a Thermal-Link™
Driver Protection System automatically monitoring high frequency per-
formance. The Thermal-Link circuit is designed to automatically adjust
to the constantly changing protective threshold unique to a given appli-
cation based upon driver temperature. Solid-state and self-resetting,
this safeguarding network guarantees that each enclosure can remain
running at maximum output, without risk of speaker damage.
Externally corner protectors, recessed steel handles, rigging points, rub-
ber feet, a 16-guage steel grille, ¼" and locking connectors are all found
on each MVP37 enclosure.
MVP37 [07-24-02]
PA
LUBS
ROTECTION
-C N -M D
OOLED ON ETALLIC IAPHRAGM
T L C
WO OCKING ONNECTORS
MVP37 Page 1 of 2
