Field Name
Type
Online
PreDef
Registration
IP
Name
Phone
Other
Aliases
Msg
TTL
Command Buttons
Add
Unregister
Unregister
All
Disconnect
Endpoint
Delete
Del Pre-def
Online
Properties
54
Existing Endpoints Parameter Definitions
Values Description
The endpoint type . When an endpoint attempts to register with the
Gatekeeper,
Gatekeeper, the Gatekeeper compares the endpoint type with the predefined
Gateway,
value. If the Gatekeeper detects a discrepancy, the registration is not
MCU,
accepted. If you are not sure of the endpoint type, select Undefined, which
Terminal,
allows any endpoint of any type to register with the Gatekeeper.
or
(Multipoint Control Units, MCUs, are used to facilitate conference calls.)
Undefined.
+ When "+" appears, the endpoint's registration is dynamic or "online."
or
[blank]
+ When "+" appears, the endpoint's registration is static or "predefined."
or
[blank]
n.n.n.n
The RAS address and RAS port of the endpoint.
0-255
The H.323 ID alias of the endpoint.
The e164 alias number (conventional PSTN phone number)of the endpoint.
Additional aliases for the endpoint: URL, e-mail address, transport address,
party.address, or private network number (per ISO/IEC 11571).
Alias addresses must be unique within a zone. Gatekeepers themselves cannot
have aliases.
LRQ, The type of message sent by the endpoint when the mode for processing
registration is manual. This can be an LRQ, RRQ, URQ, or AppURQ (which is
RRQ,
a URQ sent by the Gatekeeper).).).
URQ, or
AppURQ
seconds The time remaining in seconds before the TimeToLive timer expires. If the
endpoint fails to reregister within this time, the endpoint is unregistered.
-- Opens an empty Predefined Properties dialog box where you can
predefine a new registration.
-- Sends a URQ message to the selected endpoint, deleting the online (or
dynamic) registration properties and unregistering the endpoint.
-- Sends a URQ to all the online endpoints in order to unregister them.
-- Disconnects all calls with which the endpoint is involved.
-- Deletes the endpoint from the Gatekeeper database. A URQ will not be
sent to the endpoint.
-- Deletes the predefined (static) properties of the endpoint.
-- Opens the Online properties screen or the selected endpoint whereupon
are shown details of that endpoint's configuration.
