Multitech 410 Configuration Manual page 34

Field Name Values
Use Fast Start Y/N
Call Signaling port number
Port
Delay Before
in milliseconds
Dial
Gatekeeper alpha-numeric string
Name
Gateway
Prefix
Gateway H.323
ID
Phone numeric
Number/
Extension
Security Code alpha-numeric
Buttons
Default
Unregister
Register
Columns
GateKeeper IP
Address
RAS Port
GateKeeper
Name
Rows
Primary
[gatekeeper]
Alternate GK 1
Alternate GK 2
34
Communication Manager Parameter Definitions Continued
Description
Q.931 Parameters
Enables the H.323 Fast Start procedure. If
Communication Manager Gatekeeper"
"N" and cannot be changed.
This value must be unique for each of the MultiVOIP's FXS ports.
This value must be the same for all of the MultiVOIP unit's
FXO/DID ports that are managed by CM.
Applicable to FXO ports only. It indicates the amount of delay that
will be introduced before a dialed sequence is sent.
GateKeeper RAS Parameters
Optional. The name of the GateKeeper with which this MultiVOIP is
trying to register.
If
"Register with Communication Manager Gatekeeper"
field is not used. This number becomes registered with the
GateKeeper. Call requests sent to the gatekeeper and preceded by
this prefix will be routed to the VOIP gateway.
The H.323 ID is used to register FXO trunks with the MultiVOIP
GateKeeper.
This phone number (PBX extension) must match the extension
configured on the Communication Manager "station" form (dialog
box). It is only relevant for the MultiVOIP's FXS channels.
This field value must match the security code configured on the
Communication Manager "station" form (dialog box). It is only
relevant for the MultiVOIP's FXS channels.
Applies default values to all fields in the Communication Manager
Parameters screen.
Allows you to unregister the registered station or trunk with respect
to the Communication Manager Gatekeeper. This command has an
immediate effect. This is a very useful diagnostic command.
Allows you to register the unregistered station or trunk with respect
to the Communication Manager Gatekeeper. This command has an
immediate effect. This is a very useful diagnostic command.
The IP address of the Communication Manager Gatekeeper.
Typically this is 1719.
This field must be left blank
One PBX in the system must serve as the primary gatekeeper.
It is optional for the system to have a PBX that serves as a first
alternate gatekeeper.
It is optional for the system to have a PBX that servers as a second
alternate gatekeeper.
Chapter 3 – Related MultiVOIP Setup Parameters
Multi-Tech Systems, Inc. Avaya Communication Manager Guide
"Register with
is enabled, this field defaults to
is enabled, this
