Click on the Memory Setting button to access the Memory screen. The configurable fields must be
configured as shown below.
Field Name
GK Memory Values
Maximum
Calls
Maximum
Registrations
RAS Parameters
Response
TO
RAS Port
Q.931 Parameters
Response
TO (sec)
Connect TO
(sec)
Q.931
Signaling
Port
Buttons
Default
52
GK General Settings Definitions (cont'd)
Values Description
The maximum number of concurrent calls. MVP210AV support 5 calls;
10, 20, 30
MVP410 AV supports 10 calls; MVP810 AV supports 15 calls.
Maximum number of endpoints that can be registered on the
2 - 250
gatekeeper-controlled network.
Note: IP phones registrations are limited to 15 regardless of this
setting.
In H.323, RAS parameters pertain to Registration, Admission, and
Status in the H.225 Call Signaling Protocol.
The timeout (in seconds) before re-transmission of a RAS message that
had previously fetched no response.
The RAS port for gatekeeper communication with endpoints.
Default value = 1719
In H.323, Q.931 parameters are those that pertain to the set-up and
tear- down of connections between H.323 endpoints.
The timeout (in seconds) waiting for the TCP reply.
The timeout (in seconds) waiting for the Connect message of a call.
Logical port through which Q.931 protocol messages are handled.
Default value = 1730
Invokes default values for all parameters on the GK General Settings
screen.
