INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
These instructions are supplementary to the Installation and
Operating Instructions supplied with the replace and should be
kept together. Refer to the Installation and Operating Instructions for
proper gas supply, safety requirements and operating instructions.
Visit www.townandcountryfireplaces.net for the most recent version of this manual
240317-24
TC36
TRANQUILITY
BURNER KIT
INSTRUCTIONS
PART# TC36.NG04D
For TC36 Series D
Fireplaces
TC36_NG04D
5056.427D4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC36.NG04D and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TC36.NG04D

Summary of Contents for Town & Country Fireplaces TC36.NG04D

  • Page 1 Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions. TC36 TRANQUILITY BURNER KIT INSTRUCTIONS PART# TC36.NG04D For TC36 Series D Fireplaces Visit www.townandcountryfireplaces.net for the most recent version of this manual 240317-24 TC36_NG04D...

  • Page 2: Contents Of Package

    Contents of Package Figure 1: TC36 Tranquility burner kit parts. A. Burner assembly (including pilot & gas lines) B. Panel, base (attached to burner assembly). C. Pebble assembly D. Hardware - tapered plugs, screws, brush, panel clips. E. Side cover - left hand side. F.
  • Page 3 Tranquility Burner Installation If converting to propane see conversion instructions on page 15 before proceeding with Tranquility Burner Kit. Figure 2: Removing oor shield. 1. Remove oor shield (2 screws) and discard the shield. Use screws to plug vacant holes. 2.
  • Page 4 Figure 4: Base panel. 3. The base panel (Figure 4) is not used with the Tranquility burner kit and is a left over item to be discarded. 4. Remove the 10 screws securing the access cover for the valve control center (Figure 5). 5.
  • Page 5 Figure 7: Left hand side cover. Figure 8: Right hand side cover. 6. Place side covers between the burner tray and its base (Figure 7 and Figure 8) before the burner tray is inserted into the rebox. These will remain in the retracted position until later in the instal- lation process.

  • Page 6: Rear Panel

    Af x screw Af x screw here here Figure 11: Screw points for lower panel. 8. Mount the lower rear panel against the rear wall of the rebox and af x to the wall using the two screws previously removed from the air channel (Figure 11). 9.
  • Page 7 Interface module Figure 12: Gas and pilot supply tubes. 10. Attach the main gas supply line and the pilot gas supply line to the bulk head ttings and tighten (Figure 12). Ensure that there are no leaks. 11. Feed the ignition and sensor wires through the bulkhead plate and gasket to the rebox (Figure 13).
  • Page 8 Flame sensor wire (white) Ignition wire (red) Interface module Figure 14: Interface module. 12. Attach the ignition and sensor wires to the interface module as indicated in Figure 14. 13. Once the gas and electrical lines are connected to the bulkhead and the interface module, rein- stall the valve control center’s access cover (Figure 5 on page 4).
  • Page 9 Figure 16: Panel retainer removal. 14. Remove the two screws (Figure 15) which secure the panel retainer to the ceiling. Remove the panel retainer and keep for reinstallation (Figure 16). 15. The right hand side panel has a cut out which will t over the side cover. The correct orientation of the upper rear panel has the two insulation retaining clips on the rear of the panel at the top (both Figure 17).
  • Page 10 Figure 18: Right side panel partially installed. 16. Remove tag and plastic tie from the ue damper before installing the upper rear panel. 17. Install the right side panel until it’s nearly up against the rebox wall (Figure 18). Leave enough room between the panel and wall so that the upper rear panel can be slipped in behind the side panel.
  • Page 11 Figure 20: Left hand side panel installed. 19. Install the upper rear panel (Figure 19). Place one end on top of the lower rear panel and slip the side of the upper rear panel in behind the side panel. Hold the upper rear panel up against the rear panel tension tabs while preparing to install the left hand side panel.
  • Page 12 Figure 22: Securing side covers. 22. Move the two side covers previously placed between the burner and its base, out to the side panels. Line the screw holes in the side covers up with the screw holes in the burner tray base. Use supplied self taping screws to secure the covers to the base (Figure 22).
  • Page 13 Figure 24: Applying sand to burner tray. 25. Remove tapered plugs from ports. 26. Remove pebble assembly from packaging by placing hand on top and tipping upside down. Note that the rock in the lower right is hollow underneath and will t over top of the pilot assembly (Figure 25).
  • Page 14 Rock set location pins Figure 26: Location pins for rock set. 27. Gently place pebble assembly onto sand base aligning 3 holes in the bottom of the rock set to the 3 pins located on the burner tray (Figure 26). 28.

  • Page 15: Propane Conversion

    Propane Conversion WARNING This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer's instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fire, explosion or production of carbon monoxide may result causing property damage, personal injury or loss of life.
  • Page 16 Ignition and sensor wires Pilot gas supply Main gas supply connection connection (Do not disconnect) Figure 29: Connections at bulkhead. 4. Disconnect the pilot gas supply line at the bulkhead (Figure 29). DO NOT disconnect the main gas supply line from the bulkhead. Flame sensor wire (white) Ignition wire (red)
  • Page 17 Pilot assy. bracket Pilot gas line Air shutter Ori ce Figure 31: Removing front burner tray screws. Figure 32: Underside of burner. 6. Remove the 2 front and 1 rear screws holding the burner tray in place (Figure 31). 7. Gently lift up the burner tray from its supports while sliding it to the left to disengage the burner tube from the ori ce.
  • Page 18 Figure 36: Removing pilot assembly. Figure 35: Air shutter half opened for propane gas. 9. Loosen the primary air shutter screw (Figure 34), open shutter half way and re-tighten (Figure 35). 10. Remove the 2 screws holding the pilot assembly in place with a short screwdriver (Figure 36). 11.
  • Page 19 Hole in band Figure 38: Band in natural gas position. Figure 39: Band in liquid propane position. 12. Slide the pilot adjustment band over and ensure that the hole in the ori ce band is showing. Figure 38 shows the pilot in the natural gas position. Figure 39 shows the pilot in propane gas position.

  • Page 20: Gas Pressure Check

    Gas Pressure Check Note: To test the gas pressure, turn off the gas supply before removing the plug from the supply pressure test port or manifold pressure test port. Verify gas pressures with the fireplace lit and on the highest setting. Remove the plug from the pressure test port.

  • Page 21: Burner Flame Adjustment

    Burner Flame Adjustment The air shutter on the burner tube controls the primary combustion air. It is set to the closed position at the factory for natural gas fuel. Some adjustment may be necessary to obtain desired ame and to eliminate carbon deposits. Evaluate ame appearance after the replace has reached operating temperature.

  • Page 22: Replacement Parts

    DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. #5 PILOT ASSEMBLY, CONVERTIBLE ..TCRP.5005025 #1 TRANQUILITY BURNER KIT ....TC36.NG04D #6 ORIFICE, NATURAL GAS ....... 5022.12 #2 PEBBLE ASSEMBLY ......... TC36.9499 #7 SAND ..........TC36.SAND22 #3 MAIN SUPPLY TUBE ........5019.223 #8 PROPANE CONVERSION KIT ...
  • Page 23 TC36_NG04D 240317-24 5056.427D4...
  • Page 24 © 2017 Copyright Paci c Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer. Web site: www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
