  • Page 1 6H.XULW\6\VWHP ,QVWDOODWLRQDQG6HWXS*XLGH ARMED READY AWAY STAY TEST BYPASS INSTANT CODE CHIME READY PANIC ® N7227V6 7/01...

  • Page 2: Recommendations For Proper Protection

    RECOMMENDATIONS FOR PROPER PROTECTION The Following Recommendations for the Location of Fire and Burglary Detection Devices Help Provide Proper Coverage for the Protected Premises. Recommendations for Smoke and Heat Detectors With regard to the number and placement of smoke/heat detectors, we subscribe to the recommendations contained in the National Fire Protection Association's (NFPA) Standard #72 noted below.

  • Page 3: Table Of Contents

    Table of Contents • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Conventions Used In This Manual ..................vi Section 1 Introduction.......................1–1...
  • Page 4 VISTA-10SE Installation and Setup Guide Section 8 Alpha Descriptor Programming ( 82 Menu Mode)........8-1 About Alpha Descriptor Programming......................8-1 Programming Zone Descriptors ........................8-1 Adding Custom Words............................8-3 Section 9 System Communication..................9-1 Panel Communication with Central Station ....................9-1 Report Code Formats............................9-1 System Communication Programming ......................9-3 Section 10 System Operation...................10-1 Security Codes ..............................10-1 Keypad Functions ............................10-1...
  • Page 5 List of Figures • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Figure 2-1 Installing the Cabinet Lock .......................2-1 Figure 2-2...

  • Page 6: Conventions Used In This Manual

    These prompts appear as shown at left in a double-line box, for example. When programming the system, data fields are indicated by a “star” ( ), followed by the data field number. PRODUCT MODEL NUMBERS: Unless noted otherwise, references to specific model numbers represent ADEMCO products.

  • Page 7: Introduction

    S E C T I O N Introduction • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • The VISTA–10SE is a control that supports up to 22 hardwired and wireless zones, plus remote keypads.
  • Page 8 VISTA-10SE Installation and Setup Guide Optional VIP Module • The system can be uploaded, downloaded, or • Supports the ADEMCO 4285/4286 VIP Module. controlled via an IBM-compatible computer, using • Provides access to the system via on-premises or off- ADEMCO's Compass Windows downloading software, and a modem specified by ADEMCO.

  • Page 9: Installing The Control & Peripherals

    • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Notes: Cabinet and Lock Installation • Use an ADEMCO No. N4445 Lock. For Residential Fire and/or Burglary installa- • The cabinet can be closed and secured without a lock tions, use the ADEMCO RES-UL cabinet.

  • Page 10: Mounting Control With Rf Receiver

    VISTA-10SE Installation and Setup Guide Mounting Control with RF Receiver 7. Insert both grounding lugs (supplied with the To mount the control panel and RF receiver boards receiver) through the top of the cabinet into the left- together in the cabinet, do the following: hand terminals of the antenna blocks (located at the 1.

  • Page 11: Mounting The Keypads

    Section 2 – Installing the Control & Peripherals Mounting the Keypads Wiring the Keypads 1. Make sure addressable-type keypads (6128, 1. Determine wire gauge by referring to the wiring 6137, 6138, and 6139) are set to non-addressable length/gauge chart on the next page. mode (address 31), which is the factory default For devices (keypads, RF receivers, etc.) connected setting.

  • Page 12: Sounder (Bell) Connections

    VISTA-10SE Installation and Setup Guide SUPPLEMENTARY CONTROL TERMINAL STRIP POWER SUPPLY – AUX. AUX. DATA DATA – IMPORTANT: MAKE THESE CONNECTIONS DIRECTLY TO SCREW TERMINALS AS SHOWN. supp_pwr_supply-V0 Figure 2-5. Using a Supplementary Power Supply for Keypads Sounder (Bell) Connections TERMINALS ON Make sounder connections to alarm output CONTROL BOARD...

  • Page 13: Ac Powerup

    425mA 14AH NP4-12 (two) ‡ 500mA 17.2AH NPG18-12 ‡ NOTE: Use two batteries, connected in parallel. Obtain an ADEMCO Battery Harness Kit SA5140-1. (Both batteries will fit inside the panel’s cabinet.) AUXILIARY DEVICE CURRENT DRAIN WORKSHEET DEVICE CURRENT # UNITS...

  • Page 14: Earth Ground Connections

    VISTA-10SE Installation and Setup Guide AC Power Outlet Ground: Earth Ground Connections Available from 3-prong, 120VAC, power outlets only. To Metal Cold Water Pipe: test the integrity of the ground terminal, use a three- Use a non-corrosive metal strap (copper is recommend- wire circuit tester with neon lamp indicators, such as ed) firmly secured to the pipe to which the ground lead the UL-Listed Ideal Model 61–035, or equivalent,...

  • Page 15: Installing The 5881/5882 Receiver

    Section 2 – Installing the Control & Peripherals The RF receiver must be at least 10 feet from any Installing the 5881/5882 Receiver remote keypad to avoid interference from the RF System Installation Advisories microprocessors in those units. Follow the guidelines below when installing the RF Installation and Setup of the 5881/5882 Receiver receiver.

  • Page 16: Installing Other 5800 Series Transmitters

    VISTA-10SE Installation and Setup Guide Installing the 5800TM Module The 5800TM must not be installed within the control cabinet. Mount the unit using its accompanying Installation of this module is necessary only if you are mounting bracket. using one or more 5827BD Wireless Bi-directional keypads, or 5804BD Transmitters (wireless keys).

  • Page 17: Installing The 4204 Relay Module

    Section 2 – Installing the Control & Peripherals Transmitter Input Types Installing the 4204 Relay Module All of the transmitters described have one or more 1. Mount outside of the control panel's cabinet. unique, factory-assigned input (loop) ID codes. Each of 2.

  • Page 18: Standard Phone Line Connections

    VISTA-10SE Installation and Setup Guide If no touch tones are produced following access to the Connection to the incoming telco line via a RJ31X jack security system from on-premises (this problem may and direct-connect cord, as shown in Figure 2-11, is arise in rare cases), it may be necessary to reverse the essential, even if the system is not connected to a wires connected to terminals 3 and 4 on the Phone...

  • Page 19: Long-Range Radio Connections

    Section 2 – Installing the Control & Peripherals INCOMING TELECOM HANDSET LINE TERMINALS ON CONTROL EARTH GROUND INCOMING TELECOM LINE PLUG RJ31X PREMISES JACK RING PHONES DIRECT CONNECT CORD V10SE-024-V0 Figure 2-12. Standard Telephone Line Connections Long-Range Radio Connections The VISTA-10SE control panel features Dynamic If output to Long-Range Radio (LRR) is selected, all Signaling Delay (DSD) and Dynamic Signaling Priority messages that are programmed to go to the primary...

  • Page 20: Figure 2-13 Connection Of Aav Unit When Not Using A 4285/4286 Vip Module

    VISTA-10SE Installation and Setup Guide EARTH GROUND CONTROL EAGLE 19 20 21 SUPPLIED CABLE RED (R) GREEN (T) RJ31X GREY (R) BROWN (T) CONTROL/ DIALER HEADER 4204 RELAY 1 BROWN SHOWN TO PREMISES HANDSET DIP Switch INCOMING NO NC C PHONE LINE •...

  • Page 21: Programming Overview

    S E C T I O N Programming Overview • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • About Programming You can program the system at any time, even at the installer's premises prior to the actual installation.
  • Page 22 VISTA-10SE Installation and Setup Guide Type 05 Zone type 05 is usually assigned to a zone that contains foil-protected doors or windows; or covers a sensitive area (e.g., stock room, drug supply room, etc.) It can also be used on a Trouble by Day/ sensor or contact in an area where immediate notification of an entry is desired.

  • Page 23: Mechanics Of Programming

    Section 3 – Programming Overview Mechanics of Programming To program the system from a keypad: • You must use a 2-line Alpha display keypad. • The panel must be disarmed. Data Field Programming Procedures Task Procedure Enter Program Mode A) Press both [ ] and [#] at the same time within 50 seconds after power is applied to the control, B) After power-up, enter [Installer code (4-1-1-1)] + 8 + 0.
  • Page 24 VISTA-10SE Installation and Setup Guide...

  • Page 25: Data Field Programming

    S E C T I O N Data Field Programming • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • About Data Field Programming The following pages list this control’s data fields in numerical order.
  • Page 26 VISTA-10SE Installation and Setup Guide FIELD TITLE and DATA ENTRIES EXPLANATION Output To Long-Range Radio If selected, all messages programmed to go to the primary 0 = not used telephone line receiver will also be sent to the connected 1 = using Long Range Radio output ®...
  • Page 27 If Central Station Receiver is on WATS line: 2 = Pulse Dial; 3 = Tone Dial Report Format Selects the format to be used to report to the central station. 0 = 3+1; 4+1 ADEMCO Lo Speed Standard Enter 1 digit (0–9). (this is the default) (Enter as the 4th digit of 43 if 3+1 dialer reporting is to 1 = 3+1;...
  • Page 28 VISTA-10SE Installation and Setup Guide Example 2. Pager displays: 1 2 3 4 – 0 0 1 – 0 0 5 This indicates that Subscriber No. 1234’s system is reporting an opening (001) by User 5 (005). Note that no Restore Reports are sent to the pager. Important: AAV should not be used when Paging or Alarm Reports are being sent to a secondary number.
  • Page 29 Section 4 - Data Field Programming ® With ADEMCO Contact ID Reporting: Enter any digit (other than 0) in the first box, to enable zone to report This is an "enabling" code only and is disregarded in the actual reporting to the central office. Entries in the second boxes will be ignored.
  • Page 30 VISTA-10SE Installation and Setup Guide If an exit or interior zone contains a fault as the exit delay ends, the local bell and keypad sound continuously. a) If the subscriber then disarms the system before the ensuing ENTRY delay ends, no message is transmitted to the central station, but a zone indication and "Canceled Alarm"...
  • Page 31 Section 4 - Data Field Programming FIELD TITLE and DATA ENTRIES EXPLANATION Low Bat Restore Report Code This is a 2-digit entry field. This is sent when a system low battery condition is 0 = no report restored to normal. For both digits: 1-9, A-F (Refer to table on previous page for method of programming report codes.)
  • Page 32 VISTA-10SE Installation and Setup Guide And message is… Then… If Priority ( 93, 2nd entry) is… Primary Phone No. ("0" entered) Acknowledged before delay expires Message is removed from queue and no message is sent to LRR. Not acknowledged before delay Message is sent to both the Primary Phone Number and expires LRR.
  • Page 33 SET ALL PROGRAM FIELDS TO DEFAULT (No data entry required; pressing 97 automatically loads VALUES all ADEMCO defaults). Do not use if previously programmed with other values. TO EXIT PROGRAMMING MODE ( 98 or 99) EXITS PROGRAMMING MODE Prevents reentry by: INSTALLER Code + 8 + 0.
  • Page 34 VISTA-10SE Installation and Setup Guide 4-10...

  • Page 35: Zone Programming

    S E C T I O N Zone Programming ( 56 and 58 Menu Mode) • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • About Zone Programming Programming Wireless Zones 5800 Series transmitters have built-in serial numbers that must be enrolled into the system using the 56 or...
  • Page 36 VISTA-10SE Installation and Setup Guide PROMPT VALID ENTRIES EXPLANATION È Zone Number Enter the Zone Type response (or change it, if necessary). Zone Type (ZT) Each zone must be assigned to a zone type, which defines the way 00-10, 20-23 = Zone type 10 Zone Type in which the system responds to faults in that zone.
  • Page 37 Section 5 - Zone Programming PROMPT VALID ENTRIES EXPLANATION Loop Number Entry NOTE: If you use the [C] key to copy the previously enrolled serial 10 INPUT S/N number, the cursor moves to the Loop column (L) with the serial A 0 2 2 - 4 0 6 4 number displayed, and displays a question mark ‘?”...

  • Page 38: Figure 5-1 5800 Series Wireless Devices

    VISTA-10SE Installation and Setup Guide 5800 Series Transmitter Input Loop Identification All the transmitters illustrated on this page have one or more unique factory-assigned input (loop) ID codes. Each of the input loops requires its own programming zone (e.g., a 5804's four input loops require four programming zones).

  • Page 39: 58 Expert Programming Mode Procedures

    Section 5 - Zone Programming 58 Expert Programming Mode Procedures This method is designed for use by installers with previous experience in programming control panels. Zone Programming involves: 1. Entering the programming mode by pressing 20 2. Pressing 22 (RF System) to enable reception of 5800 series transmitters 3.
  • Page 40 VISTA-10SE Installation and Setup Guide PROMPT VALID ENTRIES EXPLANATION The prompt to confirm appears. This prompt will only appear if the Confirm XMIT TO CONFIRM first prompt after entering 58 was answered “Yes.” To confirm, [ ] to continue PRESS TO SKIP activate the loop input or button that corresponds to this zone.
  • Page 41 Section 5 - Zone Programming PROMPT VALID ENTRIES EXPLANATION 4. Enter 00. This sets the zone type to Zone Disabled. Zone Type 1 0 Z o n e T y p e The prompt at left appears confirming 00 entry in previous step. Zone Disabled to continue 5.
  • Page 42 VISTA-10SE Installation and Setup Guide NOTE: Be sure to remove one of the serial number labels from the new transmitter and affix it over the old serial number label in the ENROLLED TRANSMITTERS worksheet in the Programming Form. To Enter and Duplicate Wireless Keys If you pressed the [D] key previously (from the beginning of the 58 mode) to enter and duplicate 5804 and/or 5804BD wireless keys, the following screens appear: PROMPT...

  • Page 43: Figure 5-2 5804 Wireless Key Transmitter

    Section 5 - Zone Programming PROMPT VALID ENTRIES EXPLANATION If the serial number transmitted does not match the Not Confirmed Keyd A022-4063 – serial number entered, a display similar to the one at left appears. Rcvd A022-4064 3 If it doesn't match, press any button on the transmitter once again.
  • Page 44 VISTA-10SE Installation and Setup Guide 5–10...

  • Page 45: Output Device Programming

    S E C T I O N Output Device Programming ( 80 Menu Mode) • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • About Output Device Programming This system supports up to four relays (devices) when a 4204 relay module is connected.

  • Page 46: Programming Output Devices

    VISTA-10SE Installation and Setup Guide STOP (STP) The "STOP" programming determines when and under what conditions the relay will be de-activated. The following options are available: RESTORE ZONE LIST (ZL). If a "ZONE LIST" is used as the “Stop” event, the relay will de-activate when all the zones in that list restore from a previous fault, trouble, or alarm condition.
  • Page 47 Section 6 - Output Device Programming PROMPT VALID ENTRIES EXPLANATION Output Device Displays Enter Relay No. Upon pressing 80, this screen will appear. Enter the Relay E n t e r R e l a y N o . Number 01, 02, 03, or 04 for a 4204 (or 00 to end these entries). ( 0 0 = Q u i t ) 0 1 The [ ] key is used to accept an entry and advance to the next prompt.
  • Page 48 VISTA-10SE Installation and Setup Guide PROMPT VALID ENTRIES EXPLANATION If a zone list will be used to STOP, or restore, the relay action, STOP by Zone List 02 Stop: Zn List enter the zone list (ZL) number 1, 2, or 3 (to be programmed in to continue No List 81 mode).

  • Page 49: Zone Lists

    S E C T I O N Zone Lists ( 81 Menu Mode) • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • About Zone Lists Zone lists let you group individual zones for use with certain system actions.
  • Page 50 VISTA-10SE Installation and Setup Guide Notes: • Any list may include any or all of the system's zone numbers. • A zone list can be assigned to more than one output relay. • If you only want to review what has been programmed previously, press #81. The review can be advanced by using the key.

  • Page 51: Alpha Descriptor Programming ( 82 Menu Mode)

    S E C T I O N Alpha Descriptor Programming ( 82 Menu Mode) • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • About Alpha Descriptor Programming This Interactive mode section provides instructions for programming alpha descriptors and for adding custom words.
  • Page 52 VISTA-10SE Installation and Setup Guide PROMPT PROCEDURE Default Descriptor ↓ If a descriptor was not entered previously for zone 01, the default descriptor for zone 01 will be Z N 0 1 Z O N E 0 1 displayed. Note that no entries can be made. Entries can be made only when the display contains a flashing cursor, which signifies the “entry mode.”...

  • Page 53: Adding Custom Words

    Section 8 – Alpha Descriptor Programming PROMPT PROCEDURE 14. Enter 00. The “Program Alpha?” prompt at left appears. P r o g r a m A l p h a ? Press 0 (No). The Alpha Pgm prompt appears. 0 = No, 1 = Yes Press [ ] to continue 15.
  • Page 54 VISTA-10SE Installation and Setup Guide ALPHA VOCABULARY LIST (For Entering Zone Descriptors) NOTE: Some rarely used words appearing in previously published lists have been deleted from the list below. Use only this list for selecting zone descriptors. (Word Space) DISPLAY •...

  • Page 55: System Communication

    Comprises a 4-digit subscriber number and 2-digit report code. 4+2 Format ® Comprises a 4-digit subscriber number, 1-digit event qualifier ("new" or ADEMCO Contact ID "restore"), 3-digit event code, and 3-digit zone number, user number, or Reporting Format system status number (see the following page).
  • Page 56 VISTA-10SE Installation and Setup Guide The following table lists codes for reports sent in different formats: Code for Code for Type of 3+1/4+1 3+1/4+1 Code for Report Standard Expanded Alarm SSS(S) A SSSS AZ SSS(S) A AAA(A) Z SSS(S) B Trouble SSS(S) T SSSS Tt...

  • Page 57: System Communication Programming

    Section 9 – System Communication ® ADEMCO Contact ID Reporting takes the following format: CCCC Q EEE GG ZZZ where: CCCC = Customer (subscriber) ID Q = Event qualifier, where: E = new event , and R = restore EEE = Event code (3 hexadecimal digits) NOTE: For a complete list of event codes, refer to the central office receiver manual.
  • Page 58 VISTA-10SE Installation and Setup Guide...

  • Page 59: Section 10 System Operation

    S E C T I O N System Operation • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Security Codes The system supports up to seven security codes;...

  • Page 60: Panic Keys

    VISTA-10SE Installation and Setup Guide Panic Keys There are three individual panic keys and/or, on some keypads, panic key pairs. If programmed, they can be used to manually initiate alarms and send a report to the central station. Each key (or key pair) can be individually programmed for 24-hour Silent, Audible, Personal, or Fire Emergency responses. The panic function is activated when both keys of the appropriate key pair are pressed at the same time, or the appropriate lettered key is pressed for at least 2 seconds.

  • Page 61: Section 11 Testing The System

    S E C T I O N Testing the System • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Local Tests After the security system installation is complete, test the system as follows: With the system in the disarmed state, check that all zones are intact.

  • Page 62: Go/No Go Test Mode

    VISTA-10SE Installation and Setup Guide Go/No Go Test Mode By keying Installer code + [#] + [4], a mode similar to the test mode is entered, but the wireless receiver gain is reduced. Checking in this mode not only assists in determining good mounting locations for the transmitters when the system is being installed, but also verifies that the RF transmission has sufficient signal amplitude margin for the installed system.

  • Page 63: Other Displays (Fixed-Word Keypad Displays Are In Parentheses)

    Section 11 – Testing the System Other Displays (fixed-word keypad displays are in parentheses) Busy-Standby (dI). If this remains displayed for more than 1 minute, the system is disabled. Modem Comm (CC) The system is in communication with the central station for change of function or status verification. Comm.
  • Page 64 VISTA-10SE Installation and Setup Guide Troubleshooting Guide (continued) S Y S T E M ( i n c l u d i n g W i r e l e s s ) SYMPTOM POSSIBLE CAUSE REMEDY Transmitter signal not 1a.
  • Page 65 Section 11 – Testing the System Troubleshooting Guide (continued) S Y S T E M ( i n c l u d i n g W i r e l e s s ) SYMPTOM POSSIBLE CAUSE REMEDY 5b. If no response at all from this transmitter, 5b.
  • Page 66 VISTA-10SE Installation and Setup Guide 11-6...

  • Page 67: Section 12 Remote Programming And Control (Downloading)

    About Remote Programming The VISTA–10SE can be remotely programmed from an IBM compatible Personal Computer (PC), a modem, and ADEMCO’s Compass Windows downloading software. Programming the control from a remote location is protected against compromise by someone attempting to defeat the system, using multi-levels of security protection: 1.
  • Page 68 VISTA-10SE Installation and Setup Guide 12-2...

  • Page 69: Section 13 Specifications And Accessories

    Physical: 12-1/2" W x 14-1/2" H x 3" D (318mm x 368mm x 76mm) Electrical: VOLTAGE INPUT: 16.5VAC from plug-in 25VA transformer, ADEMCO No. 1321 RECHARGEABLE BACKUP BATTERY: 12VDC, 4AH-17.2AH (Sealed Lead Acid). Refer to Backup Battery paragraph in SECTION 2: Installing the Control & Peripherals to determine the actual battery size needed.
  • Page 70 3. Interface Wiring: Refer to 6127 keypad. 4. Range: 200 ft (60m) nominal indoors from wireless transmitters (actual range to be determined with system in TEST mode). 5. Zones: (With the (ADEMCO VISTA-10SE) 5881L: accepts up to 8 transmitters 5881M/5881H: accepts up to 16 transmitters.
  • Page 71 Low-profile 4-wire photoelectric smoke detector w/135º F (57º C) heat detector. Compatible Sounders ADEMCO AB-12M 10” Motorized Bell & Box Motor bell & box. UL Grade A. 100mA current drain. ADEMCO 1011BE12M 10” Motorized Bell & Motor bell & box. UL Listed. 100mA current drain.
  • Page 72 ADEMCO 705–820, 20-watt, 8-ohm indoor or outdoor speaker. Requires a driver. 5-inch Round Speaker ADEMCO 713 Speaker 40-watt, 8-ohm, indoor/outdoor speaker. Requires a driver. System Sensor PA400B (beige)/PA400R Indoor piezo sounder (red or beige), rated at 90 dB @ 10 feet.

  • Page 73: Appendix A Regulatory Agency Statements

    A P P E N D I X Regulatory Agency Statements • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • FEDERAL COMMUNICATIONS COMMISSION (FCC) PART 15 STATEMENT This equipment has been tested to FCC requirements and has been found acceptable for use.
  • Page 74 425mA 14AH NP7-12 (two) ‡ currents 500mA 17.2AH NPG18-12 ‡ NOTE: Use two batteries, connected in parallel. Obtain an ADEMCO Battery Harness kit. A dual-battery harness is provided with the kit. Both batteries will fit inside the panel's cabinet.

  • Page 75: Appendix B Limitations And Warranties

    A P P E N D I X Limitations and Warranties • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • WARNING THE LIMITATIONS OF THIS ALARM SYSTEM While this System is an advanced design security system, it does not offer guaranteed protection against burglary, fire or other...
  • Page 76 24 months from the date stamp control on the product or, for products not having an ADEMCO date stamp, for 12 months from date of original purchase unless the installation instructions or catalog sets forth a shorter period, in which case the shorter period shall apply.

  • Page 77: Index

    Accessories (Compatible Devices)......13-3 FCC-Part 68 Statement..........A-1 Adding Custom Words........... 8-3 Fire alarm sounder timeout ........... 4-2 ADEMCO Contact ID Reporting ......4-5, 9-3 Fuse ................13-1 Alarm Output ............1-2, 2-4 GO/NO GO Test Mode..........11-2 Alpha Descriptor Programming ........8-1 Handshake ..............
  • Page 78 Index Limited Warranty ............B-2 Sounder (Bell) Connections .......... 2-4 Local Tests ..............11-1 Specifications and Accessories ........13-1 Lock................2-1 Split/Dual Reporting ............4-3 Long-Range Radio ..........1-2, 2-11 Summary of Arming Modes......... 10-1 Loop ................5–1 Supervised Fire ............. 3-2 Low Bat Message............
  • Page 79 STEADY FOR BURGLARY/PANIC, TEMPORAL 6139 KEYPAD. IT NEED THIS DEVICE COMPLIES WITH PART 15 OF FCC RULES. ASSOC., BATTERYMARCH PARK, QUINCY, SOUNDING FOR FIRE (e.g. USE ADEMCO 740 NOT REMAIN IN SYSTEM OPERATION IS SUBJECT TO THE FOLLOWING TWO MA 02269).
  • Page 80 165 Eileen Way, Syosset, New York 11791 Copyright © 2001 PITTWAY CORPORATION ¬19^l N7227V6 7/01...
