Page 1 VISTA-100 COMMERCIAL FIRE AND BURGLARY PARTITIONED SECURITY SYSTEM with SCHEDULING INSTALLATION INSTRUCTIONS PROGRAMMING GUIDE N6019-2 1/96 www.PDF-Zoo.com firealarmresources.com...
Page 2 RECOMMENDATIONS FOR PROPER PROTECTION The Following Recommendations For The Location Of Fire And Burglary Detection Devices Help Provide Proper Coverage For The Protected Premises. Recommendations For Smoke And Heat Detectors With regard to the number and placement of smoke/heat detectors, we subscribe to the recommendations contained in the National Fire Protection Association's (NFPA) Standard #72 noted below.
Page 3: Table Of Contents
TABLE OF CONTENTS HOW TO USE THIS MANUAL ................iii CONVENTIONS USED IN THIS MANUAL............iv RECOMMENDATIONS FOR PROPER PROTECTION ........v Section 1. GENERAL DESCRIPTION .................. 1 Section 2. PLANNING A PARTITIONED SYSTEM .............. 6 Theory of Partitioning ................... 6 Setting Up a Partitioned System ................
Page 4 Section 7. POLLING LOOP EXPANSION ................31 Common Characteristics of Polling Loop Zones ..........31 Wiring/Addressing RPM Devices................31 Polling Loop Supervision..................34 Programming Polling Loop Zones ................ 34 Check-Out Procedure For Polling Loop Zones ............ 36 Compatible Polling Loop Devices................. 37 Section 8.
Page 5 Section 12. J2 TRIGGER OUTPUTS..................70 General Information....................70 Remote Keypad Sounder Operation and Wiring ..........71 Remote Keyswitch Operation and Wiring............. 71 5140LED Indicator Module ................... 73 Auxiliary Alarm Signalling Equipment..............74 Event Log Printer Connections ................76 Direct Wire Downloading ..................76 Section 13.
Page 6 TABLE OF CONTACT ID EVENT CODES ............154 COMMUNICATION DEFAULTS for LOW SPEED FORMAT....... 156 COMMUNICATION DEFAULTS for ADEMCO EXPRESS FORMAT ....156 COMMUNICATION DEFAULTS for ADEMCO HIGH SPEED FORMAT .... 156 COMMUNICATION DEFAULTS for ADEMCO's CONTACT ID FORMAT ..156 COMMUNICATION DEFAULTS for ZONES ............156 –vi–...
Page 7 Section 25. DOWNLOADING PRIMER................... 160 General Information....................160 Getting On-Line with a Control Panel ..............160 On-Line Control Functions ................... 161 Access Security....................162 Connecting a 4100SM Module for Direct Wire Downloading ....... 163 Section 26. SETTING THE REAL-TIME CLOCK ..............164 General Information....................
Page 8 INDEX ........................192 THE LIMITATIONS OF THIS ALARM SYSTEM ..........195 ADEMCO LIMITED WARRANTY ................ 196 SUMMARY OF CONNECTIONS DIAGRAM ......Inside Back Cover LIST OF FIGURES Installing The Lock ..................11 Cabinet Attack Resistance Considerations ..........12 Mounting The PC Board ................13 Keypad Connections to Keypad Port 1 Terminals ........
Page 9: How To Use This Manual
This manual is written to accommodate both the new and the experienced installer of Ademco products. A general description of the entire system is located at the beginning of the manual, followed by the basics of programming. The wiring and physical setup of the hardware follows.
Page 10: Conventions Used In This Manual
These prompts are shown in a double-line box. When programming the system, data fields are indicated by a “star” ( ) followed by the data field number. PRODUCT MODEL NUMBERS: Unless noted otherwise, references to specific model numbers represent Ademco products. –x– www.PDF-Zoo.com firealarmresources.com...
Page 11: General Description
Section 1. GENERAL DESCRIPTION The VISTA-100 is an 8-Partition, UL listed Commercial Fire and Burglary Control Panel that supports up to 87 zones using basic hardwired, polling loop, and wireless zones. It also includes zones for supervision of bells, phone lines, keypads, RF Receivers, and relays. In addition, the control offers scheduling capabilities and allows certain operations to be automated by pressing a single button.
Page 12 Supervisory Zones Provides additional zones for supervision of all peripheral devices such as keypads, RF Receivers, and relay modules, as well as for system zones (bells, dialers (telephone lines), earth ground, keypad panics, etc.) and individual relays. Zone assignments are as follows: Individual Relay Zones 601-616 Peripheral Device Zones...
Page 13 Supports the Ademco 4285 VIP Module. This permits access to the security system to do the following: • Obtain system status information • Arm and disarm security system • Control relays The 4285 VIP Module is not Listed for use with the Vista-100 control panel. – 3 – www.PDF-Zoo.com firealarmresources.com...
Page 14 (e.g. lobby door). Each partition can be assigned an access control relay. The Access Control funtion is not Listed for use with the Vista-100 control panel. Optional 24-Volt Power Supply Compatible with the PS24 Power Supply Module, which supplies: •...
Page 15 Built-in User's Manual and Descriptor Review For end-user convenience, the Vista-100 contains a built-in Users Manual. By depressing and holding any of the function keys on the keypad for 5 seconds, a brief explanation of that particular function scrolls across the alpha-numeric display.
Page 16: Planning A Partitioned System
Section 2: PLANNING A PARTITIONED SYSTEM This section provides the following information: • Theory of partitioning • Setting up a partitioned system • Common Lobby Logic • Master keypad setup and operation Theory of Partitioning This system provides the ability to arm and disarm up to 8 different areas, each as if it had its own control.
Page 17: Setting Up A Partitioned System
Setting Up a Partitioned System The basic steps to setting up a partitioned system are described below. If you need more information on how to program the prescribed options, see Section 4: THE MECHANICS OF PROGRAMMING , as well as each corresponding section's programming procedure.
Page 18 The following chart sums up how the common lobby partition will operate, if different options are set for another partition in fields 1*18 and 1*19. 1*18 1*19 Disarms when Attempts to arm when Can be armed if Affects Lobby Arms Lobby partition disarms? partition arms? other partitions...
Page 19 Do not assign Partition 1 as the common lobby. All fire zones should be assigned to this partition to ensure that all fire test modes operate correctly. How User Access Codes Affect the Common Lobby Codes with "Global" Arming If a code is given "global arming" when it is defined (see Section 27: USER ACCESS CODES ), the keypad will ask a "Arm all?"...
Page 20 The following is an example of a typical display: S Y S T E M 1 2 3 4 5 6 7 8 S T A T U S R R N N A Possible status indications include: A = Armed Away Armed Maximum S = Armed Stay Armed Instant...
Page 21: Mounting The Control, Pc Board & Lock
DO NOT ATTEMPT TO REMOVE KNOCKOUTS AFTER THE CIRCUIT BOARD HAS BEEN INSTALLED. Installing The Cabinet Lock Use an Ademco No. N6277 Cam Lock and No. P3422-2 Clip for universal commercial cabinet. 1. Insert the key into the lock. Position...
Page 22: Grade A Mercantile Premises Listing
(supplied) to the cabinet's right side wall as shown in the diagram below and wire it to zone 6. • Use a bell with a tamper protected housing such as the Ademco AB12. The bell housing's tamper switch and inner tamper linings must also be wired to zone 6.
Page 23: Installing The Control's Circuit Board
Installing the Control's Circuit Board Refer to the diagram below when mounting the PC board. • Hang the three mounting clips on the raised cabinet tabs. Make sure the clip orientation is exactly as shown in the diagram to avoid damage to the clip when mounting screws are tightened.
Page 24: Connecting The Ac Transformer
Connecting the AC Transformer and Battery This product uses the 1451 transformer, which must be hardwired into the premises electrical system. Therefore, we recommend wiring all zones and expansion modules according to each section's instructions before powering up the system for programming and testing. Refer to Section 17: FINAL POWER UP for specific instructions on how to connect the transformer and backup battery.
Page 25: The Mechanics Of Programming
• There are four sets of pre-programmed communication defaults available, including Low Speed, 4+2 Express, Ademco High Speed, and Ademco Contact ID. Loading one of these defaults automatically programs industry standard codes that will suit most of your needs.
Page 26: Moving From One Page Of Programming To Another
Moving from One Page of Programming to Another • The data fields are grouped into four levels (referred to as "pages"). The first page is accessed as soon as programming mode is entered. • The second, third, and fourth pages of data fields are indicated at the keypad by a 1,2, and 3, respectively in front of the 2-digit field address.
Page 27: Programming System-Wide Data Fields
Programming System-Wide Data Fields Values for some programming fields are system-wide (global), and some can be different for each partition (partition-specific). Note that the partition-specific programming fields are automatically skipped when programming the global fields. If the system has only 1 partition, the partition-specific fields will not be automatically skipped.
Page 28: #93 Menu Mode Programming
PROGRAMMING PARTITION-SPECIFIC FIELDS Press *91 to select a partition Enter the partition to be programmed Enter a partition-specific field # and make entry After partition -specific fields are programmed, press *91 to select next partition. Enter any global field number to return to the global fields at any time. #93 Menu Mode Programming The #93 Menu Mode is a mode through which much of the system's programming is done.
Page 29: Installing The Keypads
Section 5: INSTALLING THE KEYPADS This section provides the following information: • A list of wired keypads that may be used • Instructions for wiring and mounting the keypads • Instructions for addressing the keypads • A preliminary check-out procedure to ensure that the keypads are functioning properly in the system Keypads That May Be Used •...
Page 30: Using A Supplementary Power Supply
BLACK KEYPADS GREEN YELLOW CONTROL TERMINALS Figure 4. Keypad Connections To Keypad Port 1. Using a Supplementary Power Supply to Power Additional Keypads The control provides 1 amp of auxiliary standby power for powering keypads and other devices from the auxiliary power output. Aside from this, the control can support up to 16 peripheral devices (keypads, RF receivers, relay modules, etc.).
Page 31: Mounting The Keypads
SUPPLEMENTARY COMMUNICATOR POWER SUPPLY TERMINAL STRIP – AUX AUX. DATA DATA – IMPORTANT: MAKE CONNECTIONS DIRECTLY TO SCREW IMPORTANT: TERMINALS AS SHOWN. Make connections directly to screw terminals. Make no connection to the keypad blue wire (if present). Figure 5. Using A Supplementary Power Supply For Keypads Mounting the Keypads 1.
Page 32: Programming Remote Keypads
4. After addresses are set, the green “READY” LED should light, and the words DISARMED...READY TO ARM should be displayed on keypads set to addresses 00, 01, 02, and 03. If the “Ready” display does not appear on any of the keypads in the system (in either of the partitions), or a “Not Ready”...
Page 33 Addressable keypads can be individually programmed SOUND OPTION to suppress arm/disarm beeps, entry/exit beeps and chime mode beeps. This helps prevent unwanted sounds from disturbing users in other areas of the premises. Enter a number 0 0 -0 3 for the keypad sounding suppression options desired for the keypad: 00 = no suppression.
Page 34: Basic Hardwired Zones 001-008
Section 6: BASIC HARDWIRED ZONES 001-008 This section provides the following information: • Common characteristics of hardwired zones • Wiring burglary and panic devices to zones 1-8 • Wiring 2-wire smoke detectors to zones 1 and 2 • Wiring 4-wire smoke detectors to zones 1-8 •...
Page 35: Compatible 2-Wire Smoke Detectors
System Sensor 2100T Photoelectric w/B110LP base System Sensor 2151 NOTE: These smoke detectors are Listed for use with the Vista-100 and are the only 2-wire smoke detectors that may be used. Wiring 4-Wire Smoke Detectors to Zones 1-8 When programmed for fire warning usage, all zones can monitor 4-wire smoke detectors (zone types 9, 16), N.O.
Page 36: Compatible 4-Wire Smoke Detectors
Power to 4-wire smoke detectors must be supervised with an EOL device (use a System Sensor A77-716B EOL relay module connected as shown). • • 4-WIRE SMOKE POWER DETECTORS SUPERVISION RELAY MODULE VISTA-100 A77-716B CONTROL PANEL • SHOWN POWERED. RELAY OPENS WHEN POWER IS LOST. • 2000Ω...
Page 37: Wiring 2-Wire Latching Glass Break Detectors To Zone 8
This feature eliminates false alarms due to electrical or physical transients. Zone 6 Tamper Configuration Zone 6 may be used as a tamper loop for the Vista-100 cabinet door tamper switch and for the Ademco AB12 Grade A burglary bell box tamper switches and tamper liner.
Page 38: Programming Hardwired Zones
Compatible Glass Break Detectors Use detectors that meet the following ratings: Standby Voltage: 5VDC–13.8VDC Standby Resistance: Greater than 20k ohms (equivalent resistance of all detectors in parallel) Alarm Resistance: Less than 1.1k ohms (see note below) Alarm Current: 2 mA–10 mA Reset Time: Less than 6 seconds The IEI 735L series detectors have been tested and found to be compatible...
Page 39: Check-Out Procedure For Hard-Wired Zones
002 Zone Type Zone disabled 00 Each zone in a system must be assigned a zone type, which defines the way in which the system responds to faults in that zone. Enter the zone response type for each zone. The screen will automatically display the zone type for the number entered.
Page 40 Check-Out Procedure For Hard-Wired Zones After installation of all hard-wired zones is complete, each partition of the security system should be checked as follows: 1. Make certain that all devices and sensors connected to the hard-wired zones are not in a faulted state. Doors and windows with contacts should be closed, PIRs should be covered (use a cloth to mask them temporarily if necessary).
Page 41: Polling Loop Expansion
Section 7: 2-WIRE POLLING LOOP EXPANSION (ZONES 009 -087) This section provides the following information: • Polling loop overview • Common characteristics of polling loop zones • Wiring RPM devices to the polling loop • Addressing RPM devices • Programming polling loop zones •...
Page 42 Certain polling loop devices have a DIP switch which can be used either to select the device's zone number or to select the learning of a unique, embedded serial number by the control panel. When used with Vista-100, these devices must be set for the serial number mode of operation.
Page 43 DO NOT use the 4197 Polling Loop Extender module with the Vista-100. Be sure to include the total current drawn on the polling loop when figuring the total auxiliary load on the panel's power supply (use the AUXILIARY CURRENT DRAW WORKSHEET in Section 17: FINAL POWER UP PROCEDURE.
Page 44: Polling Loop Supervision
Notes: - Do not use 4197 module with VISTA-100. - Refer to 4297 instructions for more detailed installation information. The Limits shown below supercede the limits described in the 4297 instructions. - Do not connect 4297 modules in series. Extension Loop #1...
Page 45 Programming Polling Loop Zones 1. With at least one alpha keypad (6139/6139R) wired and set to a proper address, temporarily apply power to the system. 2. Enter data field programming mode: [Installer Code] + 8 0 0 0. 3. From data field programming mode, press #93 to display the "ZONE PROG?"...
Page 46: Check-Out Procedure For Polling Loop Zones
Enter the input device type as follows: 009 Input Type 6=serial number polling loop device (SL type); 7=DIP switch type (left loop) polling loop device (DP type); 8=right loop of DIP switch type device (PS type). Right loops refer to the use of the right (or secondary) loop on a 4190WH zone expander module and/or 4278 PIR.
Page 47: Compatible Polling Loop Devices
6. Power down and continue to the next section. 1. The 4208 must either be mounted inside the VISTA-100 cabinet or in a separate enclosure which has a tamper supervised cover. 2. The 4190WH right loop must not be used, and the left loop must be EOLR supervised.
Page 48 Compatible Polling Loop Devices 4208 8-Zone Expander • Accommodates up to 8 zones via the polling loop. • DIP switch programmable. • The first two zones can be either normal or fast response (DIP switch selectable). • All zones are EOLR supervised (first six zones = 4.7k ohms, last two zones = 30k ohms), provided with the 4208.
Page 49 Compatible Polling Loop Devices (cont'd) 4297 Extender Module • Used to increase the polling loop current (128mA), to extend the polling loop wire run length, and/or to provide individual, electrically isolated loops. • Connects to the polling loop and is powered from panel's auxiliary power or by a separate power supply with battery backup.
Page 50: Wireless Zone Expansion
Listing of the 5808 smoke detector for commercial fire installations is pending. Wireless Systems Available The VISTA-100 supports wireless zones which may be used exclusively or in addition to hardwire and/or polling loop zones. The system supports two different wireless systems which have many similarities, but notable differences in the programming of the transmitters for each system.
Page 51: Rf System Operation And Supervision
RF System Operation and Supervision • The receiver responds to status and alarm signals from wireless transmitters (@ 345MHz USA; 315MHz Canada) within a nominal range of 200 feet, and relays this information to the control. • Each supervised transmitter sends a supervisory signal to the receiver every 70-90 minutes.
Page 52: Installation And Setup Of The 4281/5881 Rf Receivers
Installation and Setup of the 4281/5881 RF Receivers 1. Mount the receiver. Receivers must be mounted externally to the control and can detect signals from transmitters within a nominal range of 200 feet. Take this into consideration when determining mounting location. 2.
Page 53: Installing The 5800Tm
Installing the 5800TM Module Installation of this module is necessary only if you are using one or more 5827BD Wireless Bi-directional keypads. The 5800TM must be located next to the 4281 or 5881 receiver (between one and two feet from the receiver's antennas). The 5800TM must not be installed within the control cabinet.
Page 54: Programming The Rf Receiver
The system House ID and the Device Address of the receiver are two different things and need not be the same. The House ID allows the system to identify transmitters with a matching House ID. The Device Address allows the system to identify the receiver as opposed to other devices connected to its keypad terminals.
Page 55: 5700 Series Transmitter
• Batteries in the wireless transmitters may last from 4-7 years, depending on the environment, usage, and the specific wireless device being used. External factors such as humidity, high or low temperatures, as well as large swings in temperature, may reduce the actual battery life in a given installation.
Page 56: Wireless Zone Assignments For 5700 Series Transmitters
Wireless Zone Assignments for 5700 Series Transmitters Each RF zone can be assigned any zone response type, such as ENTRY/EXIT, INTERIOR, PERIMETER, etc. (see the ZONE TYPES section for explanations of each zone type). For 5700 series transmitters, each response type uses a certain range of zone numbers.
Page 57: Compatible 5700 Series Transmitters
Compatible 5700 Series Transmitters Model Product Zone Num. Description 5701 Panic Transmitter 62 or 63 • Programmable for either silent or audible 24 hour alarm. 5706 Photoelectric Smoke 48-55 • One piece smoke detectors with built 5707 Detector in transmitter. •...
Page 58: 5800 Series Transmitter Setup
5800 Series Transmitter Setup 5800 series transmitters have built-in serial numbers that must be "learned" by the system using the # 93 Menu mode programming, or input to the control via the downloader. 5800 series transmitters (except 5827 described separately) do not have DIP switches.
Page 59: Compatible 5800 Series Transmitters
Do not install batteries in wireless transmitters until ready to learn, as will be indicated under Programming the RF Transmitters later in this section.. After learning, batteries need not be removed. Compatible 5800 Series Transmitters Model Product Learn As Description Input Type 5801 Wireless Panic...
Page 60 Model Product Learn As Description Input Type 5816 Door/Window • Has two unique input (loop) codes: Transmitter: one for a wired closed circuit contact loop; the other for a built- in reed switch (used in con junction with a magnet). 5817 Multi-Point Universal •...
Page 61: Programming Rf Transmitters
Programming RF Transmitters Zone number assignments can be from 001-063 for 5700 series transmitters, and 001-087 for 5800 series transmitters,, except for zone 64, which is reserved for a wireless keypad. 1. With at least one alpha keypad (6139/6139R) wired and set to a proper address (00-30), temporarily apply power to the system.
Page 62 Each zone in a system must be assigned a zone 009 Zone Type type, which defines the way in which the system Zone disabled 00 responds to faults in that zone. Enter the zone response type for each zone. The screen will Refer to the ZONE automatically display the zone type for the number TYPE DEFINITIONS...
Page 63 If the sensor's serial number has not been "learned," 009 LEARN S/N ? the serial number can be learned now by entering 1 1=YES 0=NO (or it can be learned later by using the SERIAL NUMBER LEARN mode). If learning the serial number now (entering 1 at the 009 INPUT S/N :L last prompt), this prompt appears.
Page 64: Check-Out Procedure For Wireless Zones
Check-Out Procedure for Wireless Zones Transmitter ID Sniffer Mode Use the Transmitter Sniffer Mode to test that transmitters have all been properly programmed. 1. Enter Installer Code + # 3. The keypad will display all zone numbers of wireless units programmed into the system. 2.
Page 65: Relay Outputs
Section 9: RELAY OUTPUTS Relay Basics Relays, used in conjunction with this control panel, are programmable switches that can be used to perform many different functions. They can be used to turn lights on and off, control sounders, or for status indications. In this system, each device must be programmed as to how to act (ACTION), when to activate (START), and when to deactivate (STOP).
Page 66: Programming The Relay Module
4204 RELAY MODULE SWITCH 4 2 0 4 A D D R E S S S E T T I N G S POSITION ("—" means "OFF") — — — — — — — — — — — — — —...
Page 67: Output Programming Options Defined
4. Press 0 (NO) to each menu option until the "DEVICE PROG?" prompt appears. Press 1 (YES) to enter DEVICE PROGRAMMING mode. DEVICE PROG? The following prompts will appear. 1=YES 0=NO The device address identifies the module to the control. DEVICE ADDRESS Enter the 2-digit address number as set at the module's 01-31, 00=QUIT...
Page 68 • NO RESPONSE when the device is not used. START (STT) The "START" programming determines when and under what conditions the device will be activated. The following START options are available : 1. EVENT (EV) is the condition (Alarm, Fault, Trouble) that must occur to a zone or group of zones (zone list) in order to activate the device.
Page 69: Programming Output Devices
The "STOP" programming determines when and under what STOP (STP): conditions the device will be de-activated. The following options are available: 1. RESTORE ZONE LIST (ZL). If a "ZONE LIST" is used as the “Stop” event, the device will de-activate when all the zones in that list restore from a previous fault, trouble, or alarm condition.
Page 70 A relay may be activated either by an Event used in 02 START EVENT conjunction with a Zone List, and/or by a Zone NOT USED Type/System Operation. If using an Event/Zone List combination, enter the event code as follows: 0=not used; 1=alarm; 2=fault; 3=trouble If not using a Zone List to activate the relay, enter 0.
Page 71 If the starting event will be limited to occurring on a 02 START PART specific partition, enter the partition number (1-8) in which the start event will occur. Enter 0 for any partition. Press to continue. If a zone list is being used to stop this relay action, 02 STOP: ZN LIST enter the zone list number 1-8.
Page 72: Zone List Programming
Zone List Programming After all relays have been programmed, upon entering 00 at the "ENTER RELAY NO." prompt, you will be asked to enter a Zone List. If a Zone List number was used to start or stop a relay, you must define the zones belonging to that list as follows: Enter the zone list number 01-08.
Page 73: 4285 Vip Module
Section 10: 4285 VIP MODULE The 4285 VIP Module is not permissible for Commercial Fire or UL Commercial Burglary installations. General Information The 4285 VIP Module is an add-on accessory that permits the user to access the security system (and relays) via a touch-tone telephone, either from the premises or by calling the premises from a remote location.
Page 74: Wiring The Vip Module
Wiring the VIP Module The 4285 is wired between the control panel and the premises handset(s). It listens for touch tones on the phone line and reports them to the control panel. During on-premises phone access, it powers the premises phones; during off- premises phone access, it seizes the line from the premises phones and any answering machines.
Page 75 PHONES ANSWERING MACHINE MAIN JACK DIALER JACK VISTA-100 CONTROL DIRECT CONNECT CORD @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ?
Page 76: Programming The Vip Module
Programming the VIP Module 1. With at least one alpha keypad (6139/6139R) wired and set to a proper address, temporarily apply power to the system. 2. Enter data field programming mode: installer code + 8 0 0 0. 3. Program the following data fields: VIP MODULE PHONE CODE RING DETECTION COUNT (cannot be set to 0) 4.
Page 77: Audio Alarm Verification (Aav) Unit
Section 11. AUDIO ALARM VERIFICATION (AAV) UNIT This section provides the following information: • General information about the AAV option • AAV operation • Connecting an Eagle AAV Module • AAV programming requirements The Audio Alarm Verification (AAV) feature is not UL Listed. General Information An Audio Alarm Verification (AAV) module (also known as two-way voice), such as the Eagle 1241, is an add-on accessory that permits voice dialog between an...
Page 78: Audio Alarm Verification Module Connections
Some AAV modules allow remote triggering by ring detection at the alarm installation. Please be advised that if this option is selected, it may defeat modem download and 4285 VIP module remote access capability. The DIP switch settings shown on the triggering diagrams disable remote AAV module trigger option.
Page 79 JACK 1.Remove any EOL ID UNIT resistor from control panel terminals 22 & 23, if any present. 8-CONDUCTOR DOUBLE PLUG CORD (SUPPLIED) JACK VISTA-100 PREMISES ANSWERING CONTROL MACHINE AND PHONES ANSWERING MACHINE All switches should be “off” except 1 2 3 4 5 6 switch 5, which should be “on.”...
Page 80: J2 Trigger Outputs
• Remote keypad sounder • UL Listed keyswitch • 5140LED Indicator Module • Auxiliary alarm signaling equipment such as an Ademco Long Range Subscriber Radio • Event logging serial printer (via the 4100SM Interface Module) • PC computer used to direct wire download the panel's programming information (via the 4100SM Interface Module) The trigger output ratings are listed below.
Page 81: Remote Keypad Sounder Operation And Wiring
8, and causing the control to disable keyswitch operation until the associated partition is disarmed from a keypad. The VISTA-100 allows 2 modes of keyswitch operation. When field *15 is set to a partition (1-8), the keyswitch operates as follows:...
Page 82 Faulted zones must either be corrected or bypassed before the system will arm. BROKEN LINES REPRESENT INSTALLER WIRING CONNECTIONS (ARMED) (READY) GREEN TO OUT 1 (J2 PIN 7) 820Ω 820Ω TO GND (J2 PIN 8) TO OUT 5 (J2 PIN 6) TO ZONE 8 + (TERM 27) 2000 TAMPER...
Page 83: 5140Led Indicator Module
5140LED Indicator Module An optional 5140LED Indicator Module can be used in municipalities which require dedicated indicators for communicator fault status. The 5140LED provides the following indicators: 1. AC POWER: ON if AC power is present. OFF if AC power is not present. 2.
Page 84: Auxiliary Alarm Signalling Equipment
These triggers may be used to trip auxiliary alarm signaling equipment such as Ademco's 7720, 7720ULF, and 7920SE Long Range Radios. Note that not all of these triggers are available for all settings of field 3*20. Consult the J2 PIN ASSIGNMENTS AND FUNCTIONS diagram shown earlier for configuration of the J2 triggers..
Page 85 7720 ULF WIRING DIAGRAM J2 CONNECTOR RADIO FAULT (PROGRAM FOR SHORT ON FAULT) SEE 7720 ULF INSTRUCTIONS FOR 7720 ULF RADIO MORE DETAILED INSTALLATION 4142TR INFORMATION CABLE 4142TR CABLE FAULT WIRE FAULT COLORS - CUT RESISTOR JUMPERS Z1-Z5. - DO NOT USE 2k EOL RESISTOR. - PROGRAM 7720 ULF FOR SLAVE OPERATION.
Page 86: Event Log Printer Connections
Event Log Printer Connections The VISTA-100's event log can be printed on a local serial printer. If used, program field 3*19 must be set to "1." This setting overrides the functions selected for INPUT 1 and OUT 2 made in field 3*20.
Page 87: External Sounders
• Selectable for no timeout or timeout of 2-30 minutes If you purchased a kit containing the PS24 Power Supply module, you may use this module to convert one or both VISTA-100 12VDC, 1.7A style Y supervised bell outputs to 24VFW, 1.7A style Y supervised bell outputs.
Page 88: Wiring
UL listed, non-polarized burglary indicating device rated for 10 -14 VDC operation on this output. Note that a local burglary grade A listing requires that a bell in a tamper protected housing be used (such as the Ademco AB12) and that bell wiring be run in conduit.
Page 89 BELL 1 FACTORY DEFAULTS Bell 1 is configured as a burglary bell circuit • Use non-polarized Grade A indicating devices (eg: Ademco No. AB12 - see below) • Wiring is not supervised; cut white jumper, W1, on main PCB –...
Page 90: Auxiliary Relay
Section 14: AUXILIARY RELAY The VISTA-100 provides a built-in "Form C" relay with contacts rated at 28 VAC/VDC, 2.8 amps max. This relay may be programmed for one of the functions below (determined by program field 3*61): • Alarm Activation •...
Page 91: Trouble/Supervisory Activation
The relay re-activates within a few seconds after AC power restores. • • 4-WIRE SMOKE POWER DETECTORS SUPERVISION RELAY MODULE VISTA-100 A77-716B CONTROL PANEL • SHOWN POWERED. RELAY OPENS WHEN POWER IS LOST. • 2000Ω...
Page 92: Dialer Outputs
Enabling the dialer outputs • Dialer Operation Dialer Outputs Available The VISTA-100 provides one main built-in dialer for communication to the central station and one optional 5140DLM backup dialer, both supervised for voltage and current on the phone lines. Telephone Line Connections Connect the main dialer and back-up dialer (if used) outputs to telephone company lines which provide loop start service using the RJ31X cables supplied.
Page 93 974 (Dialer 1) and 975 (Dialer 2). Dialer Operation When only the main dialer is enabled ([1,0] in field 3*30), the VISTA-100 will attempt to route all calls over the main output. When both main and back-up dialers are enabled ([1,1] in field 3*30), the VISTA-100 will attempt to route all calls over the main output until a fault is detected, at which time it will attempt to use the back-up output.
Page 94: Event Log Options
Interface Module. Event Log Printer Connections The VISTA-100's event log can be printed on a local serial printer. If used, program field 3*19 must be set to "1." This setting overrides the functions selected for INPUT 1 and OUT 2 made in field 3*20.
Page 95: Programming Event Log Options
This signal will be low (0-1.5VDC) when the printer is not powered, not properly connected, off- line or out of paper. The VISTA-100 will not send printing data to the printer unless the DTR signal is high.
Page 96 Display/Printing: After entering either the Display or Print mode, the following will be displayed: The Event Log holds up to 224 events, and can ENTER 0 = RECENT display or print all events in a category (complete), or 1 = COMPLETE only those events in a category occurring since the last Clear Event Log command (recent).
Page 97 After the last event in the selected category has been displayed (using either the [1] or [3] keys), the following will appear for a few seconds: END OF EVENT LOG TYPE CCC UUU Press [1] if Event Log is to be cleared from memory. CLEAR EVENT LOG All events in the log will still be displayed if the 0=NO 1=YES...
Page 98: Final Power-Up Procedure
1. Remove the front cover of the enclosure. 2. Mount the enclosure to the wall near the VISTA-100 panel. The enclosure has 4 mounting holes on its back surface for this purpose. 3. Run 120VAC wiring to the enclosure in conduit. A dedicated circuit must be used.
Page 99: Panel Earth Ground Connections
Backup Power Calculations In the event of an AC power loss, the VISTA-100 control (and PS24 Power Supply module, if used) must be supported by a back-up, rechargeable, lead acid (gel cell type) battery. When used without a PS24, a 12VDC, 12AH min/34.4AH max battery must be connected to the VISTA-100 control.
Page 100: Connecting The Backup Battery
Connecting the Backup Battery to the Control If not using the PS24, connect the battery (or batteries) to the VISTA-100 as shown in Figure 24 . If using the PS24, connect the backup batteries to the PS24 using the cables supplied with the PS24 as shown in the PS24's instructions.
Page 101: Total Control Panel Load Worksheets
TOTAL CONTROL PANEL LOAD WORKSHEETS To calculate the total current for the Aux. power 1, Aux power 2, bell 1 & bell 2 outputs and polling loop current, multiply the each device's standby and/or alarm current by the number of units used. Enter devices used on AUX.
Page 102 15mA* (inactive) (active) *5140DLM actually draws 55mA when active. However, since VISTA-100 PCB current includes built-in main dialer current, and since main dialer is inactive when 5140DLM is active, 5140DLM imposes only 15mA added current on power supply. TOTAL CONTROL PANEL LOAD...
Page 103: False Alarm Reduction Features
In addition, the following dialer reports will be sent to the central station if programmed: • Exit Error by User (not sent if using ADEMCO High Speed format) • Exit Error by Zone (Sent as regular alarm if using ADEMCO High Speed format) • Bypass reports...
Page 104: Cross-Zoning
When the panel is armed, the normal exit delay begins. After the user exits, and the door closes, the exit delay time is reset to 60 seconds. If, within this 60 second period, the entry door is re-opened, the panel will restart the exit delay sequence again using the programmed exit delay time.
Page 105: Zone Type Definitions
• Zone number designations • Zone Type Definitions The VISTA-100 supports up to 86 zones of hard-wire, polling loop and/or wireless protection, distributed among up to 8 partitions. The following table lists the zone numbers and the types of sensors that can be used with each in this system:...
Page 106 Type 05: Trouble by Day/Alarm by Night. Type 16: Fire With Verification This zone type will give an instant alarm if faulted when This zone type is used when smoke alarm verification is armed in the Away, Stay, Instant or Maximum (night) desired on hardwire and polling loop zones containing modes.
Page 107: Zone Index/Zone Type Defaults
Section 20: ZONE INDEX/ZONE TYPE DEFAULTS Zone Index The VISTA-100 has 87 protection zones , as well as supervisory zones for relays, ECP devices (devices which communicate through the keypad terminals), and system troubles. These zones are designated as follows:...
Page 108: Data Field Descriptions
Section 21: DATA FIELD DESCRIPTIONS The following is a description of all data fields provided by this control. If you have followed earlier instructions during the installation of the various devices, many of these fields will already have been programmed. If you need more information about actual programming procedures, see Section 4: THE MECHANICS OF PROGRAMMING.
Page 109 KEYSWITCH ASSIGNMENT Enter the partition number 1-8 in which the keyswitch is being used. Enter 9 if keyswitch is to be used to silence fire bells in the event of a fire alarm. Otherwise, enter 0. Requires the use of zone 7 wired loop (zone 7 no longer available as protection zone when used for keyswitch operation).
Page 110 MULTIPLE ALARMS (partition-specific) Determines whether or not more than one alarm can be sounded in a given zone during an armed period. Note that multiple alarm soundings will not occur more frequently than allowed by the programmed alarm sounder duration. This selection applies to local sounding and has no impact on the number of communication messages transmitted.
Page 111 If selecting touch-tone, make sure the subscriber has requested and is paying for touch-tone service. Note that whether or not touch-tone dialing for call placement is permitted, communication by the use of DTMF signaling (Ademco High Speed) will still take place. See field 1*33 for Touch-Tone w/Rotary backup.
Page 112 DOWNLOAD PHONE NO. | | | | | | | | | | | | | | | | | This field is applicable only if downloading will be utilized. Enter the downloading phone number, up to 17 digits, 0-9; enter #11 for *, #12 for #, and #13 for a 2 sec.
Page 113 This field selects the reporting format for use on the primary telephone number. Enter the appropriate number for the primary format as follows: 0=Low Speed; 1=Contact ID; 2=Ademco High Speed; 3=Ademco Express LOW SPEED FORMAT (PRIMARY) Enter the appropriate value: 0=Ademco Low Speed; 1=Sescoa/Radionics...
Page 114 SESCOA/RADIONICS SELECT Enter 0 if Radionics format is to be used with hexadecimal 0-9, B-F reporting. Enter 1 if SESCOA format is to be used with only numeric reporting (0-9). Note that selection applies to both primary and secondary phone numbers. DUAL REPORTING This field allows all reports to be sent to both primary and secondary phone numbers.
Page 115 ENABLE DIALER REPORTS FOR PANICS & DURESS (partition-specific) 95 96 99 Duress Enter 1 for each panic/duress for which reporting is desired. ENTRY WARNING (partition-specific) Enter 0 for 3 short beeps, or 1 for slow beeps that continue for the entire entry delay period.
Page 116 1*22 CROSS ZONING PAIR ONE Enter the first pair of zones which must both be faulted within a five minute period to cause an alarm. Enter 00,00 to disable. Must be 00,00 for UL Burglary Installations. 1*23 CROSS ZONING PAIR TWO Enter the second pair of zones which must both be faulted within a five minute period to cause an alarm.
Page 117 1*32 RECEIVER TYPE Enter 1 if using 4281 series receivers. Enter 2 if using 5881 series receivers. Important: the 4281 microprocessor must have part number N5334Vx, where x is any number. 1*33 TOUCH-TONE W/ROTARY BACKUP [0] Enter 1 to enable Rotary back-up dialing if communicator is not successful on dialing using touch-tone DTMF on first attempt.
Page 118 1*47 CHIME ON BELL 1 (partition-specific) Enter 1 for chime annunciation using the external alarm sounder. If not desired, enter 0. 1*48 WIRELESS KEYPAD ASSIGNMENT Enter the partition in which RF keypad is used, 1-8. Enter 0 if no RF keypad is used. 1*49 SUPPRESS TX SUPERVISION SOUND Enter 1 to disable trouble sounding for transmitter check-in failure.
Page 119 1*70 EVENT LOG TYPES Alm Chck Byps O/C Systm Test Enter 1 for each type of event for which event logging is desired. Otherwise enter 0. 1*71 12/24 HOUR TIME STAMP FORMAT Select the type of time stamping desired: 0=standard 12 hour; 1= 24 hour format. 1*72 EVENT LOG PRINTER ON-LINE Enter 1 to have the printer print events as they occur...
Page 120 Fields 2*05 – 2*08 must be set to "0" for UL installations. 2*05 AUTO-ARM DELAY (partition-specific) [15] Enter the time between the end of the arming window and the start of auto arm warning time in values of 01-14 times 4 minutes. Enter 00 if no delay is desired.
Page 121 2*18 ENABLE GOTO FOR THIS PARTITION (partition-specific) Enter 1 if this partition is to be accessed from another partition's keypad using the GOTO command. Otherwise enter 0. 2*19 USE PARTITION DESCRIPTORS Enter 1 if partition descriptors will be programmed. If enabled, the normal keypad display will include a partition number and four-digit descriptor).
Page 122 3*15 ALARM BELL SOUND [0,0] Enter 0 for pulsing, 1 for Steady output on Bell Outputs 1 and 2. If pulsing is selected, field *08 applies. 3*16 DELAY FOR ZONE TYPES 17 & 18 [0,0] Enter 01-15 times 2 seconds if a delay is desired for Waterflow and Fire Supervisory zones.
Page 123 3*58 BELL 2 & AUX. RELAY AC POWER [0,0] LOSS ALARM Enter 1 to sound the external alarm sounders connected to Bell Output 2 and the aux. relay after AC power has been out for 4 hours. Otherwise enter 0 (no alarm). 3*59 ENABLE BELL 2 &...
Page 124: Menu Mode Programming
Section 22: #93 MENU MODE PROGRAMMING This section provides the following information: • #93 Menu Mode main menu options • Zone Programming • Serial Number Programming • Report Code Programming • Alpha Programming • Device Programming • Relay Programming • Relay Voice Descriptors •...
Page 125: Zone Programming
For defining output relay functions. This prompt is RELAY PROG? fully explained in the 4204 RELAY MODULE section. 0=No 1=Yes For entering voice descriptors for relays to be used RLY VOICE DESCR? with the 4285 VIP Module This prompt is fully 0=No 1=Yes explained in the RELAY OUTPUTS section.
Page 126 Each zone in a system must be assigned a zone 020 ZONE TYPE type, which defines the way in which the system ZONE DISABLED 00 responds to faults in that zone. Refer to Section 17: ZONE TYPE DEFINITIONS for detailed definitions of each zone type.
Page 127 Enter the input device type as follows: 0 = not used; 020 INPUT TYPE 1=hardwired; 3=supervised RF transmitter (RF type); RF TRANS. RF: 4=unsupervised RF transmitter (UR type); 5=RF button type transmitter (BR type); 6=serial number Note that input types 4 polling loop device (SL type);...
Page 128: Learning Serial Numbers
Learning Serial Numbers Usually, serial numbers are learned during zone programming. If not, use #93 menu mode to learn serial numbers (for example, if all other programming was done via downloading). 1. Enter data field programming mode: installer code + 8 0 0 0. 2.
Page 129: Report Code Programming
All report codes are entered using #93 menu mode programming, either through Report Code Programming, or through the Zone Programming mode while entering other zone information. In the Vista-100, reports are divided into six categories. These categories represent the main menu options found in the Report Code Programming mode.
Page 130: Restore/Supervisory Codes
To enter report codes, do the following: Enter Program mode [Installer Code] + 8 0 0 0. Then press #93. Enter (N) to the main menu options until the Report Code Programming option is displayed. Press 1(Y) to enter to Report Code Programming REPORT CODE PROG mode.
Page 131: System Group 1 Codes
Enter the first digit of the bypass restore report code BYPASS RESTORE (double-digit entry) and press . The second digit GRP 001-016 will be the ID (second) digit of the alarm report code for each zone (if programmed). Press continue. Enter one zone for each group of 16 zones.
Page 132: System Group 3 Codes
Enter the rest of the codes in the same manner. Other codes in System Group #2 are: Time Set, Log Reset Log 50%, 90% Full Event Log Overflow Exit Error by Zone Exit Error by User Recent Close Once you have entered these report codes, the system will prompt: If you have completely finished entering report...
Page 133: Programming Alpha Descriptors
Enter the rest of the codes in the same manner. Other codes in System Group #2 are: Walk Test End Off-Normal Once you have entered these report codes, the system will prompt: If you have completely finished entering report QUIT REPORT MENU codes, press 1 (Y) to quit Report Code Programming 1 = YES 0 = NO mode.
Page 134 Zone Descriptors 1. Select ZONE DESCRIPTOR mode. The keypad keys perform the following functions: [3] Scrolls both alphabet and actual words in ascending alphabetical order. [1] Scrolls both alphabet and actual words in descending alphabetical order. [2] Adds or removes an "s" or " 's " to a vocabulary word. [6] Switches between alphabet and actual word list;...
Page 135 Custom Words • Up to 20 installer-defined words can be added to the built-in vocabulary. Each of the 20 "words" can actually consist of several words, but bear in mind that a maximum of 10 characters can be used for each word string. 1.
Page 136 Custom Message Display (Installer's Message) Normally, when the system is in the disarmed state, the following display is present on the keypad. ****DISARMED**** READY TO ARM Part or all of the above message can be modified to create a custom installer message for each partition.
Page 137: Alpha Descriptor Vocabulary
ALPHA DESCRIPTOR VOCABULARY (For Entering Alpha Descriptors. To select a word, press [#] followed by the word's 3-digit number.) NOTE: This vocabulary is not to be used for relay voice descriptors. See the RELAY VOICE DESCRIPTORS section when programming relay voice descriptors. 000 (Word Space) •...
Page 138: Device Programming
Device Programming This menu is used to program keypads, receivers and relay modules. From Data Field Programming mode, press #93 to display "ZONE PROG?". Press 0 repeatedly to display "DEVICE PROG?". Press 1 to enter DEVICE PROGRAMMING mode. DEVICE PROG? 1=YES 0=NO The device address identifies the device to the DEVICE ADDRESS...
Page 139: Relay Voice Descriptors
If device type 1 (Alpha Keypad) is entered, this SOUND OPTION prompt will appear. Keypads can be individually programmed to suppress arm/disarm beeps, entry/exit beeps and chime mode beeps. This helps prevent unwanted sounds from disturbing users in other areas of the premises. Enter a number 00-03 for the keypad sounding suppression options desired for the keypad as follows:...
Page 140 Enter the 2-digit relay number (01-16) for the relay ENTER RELAY NO. desired, or enter 00 to quit relay voice descriptor 00=QUIT programming mode. Press From the relay voice descriptor vocabulary list, enter the 3-digit index number for the first word of the relay 01 ENTER DESC d1 descriptor phrase.
Page 141: Custom Word Substitutes For Vip Module Annunciation
Custom Word Substitutes for VIP Module Annunciation A substitute word can be programmed for each of the 20 custom words used in your alpha zone descriptions. This substitute word will be announced by the VIP module in place of the custom word that is displayed on the alpha keypad. For example, an alarm display of "John's Bedroom"...
Page 142: Scheduling Options
Section 23: SCHEDULING OPTIONS This section provides the following information: • Main features of scheduling • Time Window Definitions • Open/Close Schedule Definitions • Programming in the #80 Scheduling menu mode for: Time Windows Open/Close Schedules Holiday Schedules Time Driven Events Access Schedules •...
Page 143 Extend Closing • A user can manually extend the arm (closing) time window Window by 1 or 2 hours. This is done by entering a keypad command (user code + #82), which then prompts the user to enter the desired extension time of 1 or 2 hours (refer to the SYSTEM OPERATION section of the Installation Instructions).
Page 144: Time Windows Definitions
Time Windows Definitions Time Windows • Scheduled events are based on time windows, which are simply periods of time during which an event may take place. Time windows are defined by a start time and stop time. The system supports up to 20 Time Windows. The windows are shared by the 8 partitions, and the windows are used for open/close schedules as well as for time driven event control.
Page 145: Open/Close Schedule
Open/Close Schedule Definitions General • The Open/Close scheduling is controlled by one of three individual schedules. Each schedule consists of one time window for openings and one time window for closings. There are three types of schedules available: Daily, Holiday, and Temporary. Daily Schedule •...
Page 146: Programming With #80 Scheduling Menu Mode
Programming with #80 Scheduling Menu Mode The #80 Scheduling Menu Mode is used to program most of the scheduling and timed event options. To enter this mode, the system must first be in normal operating mode (all partitions disarmed). Enter [Installer Code] + # + 80. The following can be programmed while in this mode: •...
Page 147: Basic Scheduling Menu Structure
Basic Scheduling Menu Structure To program schedules, enter Scheduling program mode: [Installer Code] + # + 80. There are 5 sets of scheduling menus as shown below. Entering "1" at a displayed main menu prompt will select that menu set. Prompts for programming that scheduling feature will then appear.
Page 148: Time Windows Definitions Worksheet
Time Windows Definitions Worksheet The system provides 20 time windows that are defined with start and stop times. These windows are used for various open/close and access schedules, as well as for output controls, and are the basis of the scheduling system. These windows are shared among all 8 partitions.
Page 149: Programming Time Windows
Programming Time Windows Enter Scheduling Mode by entering the installer code + # + 80. The keypad will display the Time Window programming prompt. This mode cannot be entered if any partition is armed. Enter 1 at this main menu prompt to program time Time Window ? windows.
Page 150: Programming Open/Close Schedules
Programming Open/Close Schedules Each partition can be assigned one daily open/close schedule, plus a holiday open/close schedule. Temporary schedules are programmed separately, using the #81 Temporary Schedule Menu Mode. To program additional open/close schedules, see the Time Driven Events section. After entering Scheduling Menu Mode, press 0 until the O/C Schedules prompt appears.
Page 151: Holiday Definitions & Schedule Worksheet
Holiday Definitions & Schedule Worksheet The system provides up to 16 holidays that can be assigned for the system. Each holiday can be assigned to any combination of partitions. List the desired holidays on the following worksheet. Check the partitions for which these holidays apply.
Page 152: Time-Driven Event Worksheet
Time-Driven Event Worksheet These are the schedules used to activate outputs, bypass zones, etc. based on a time schedule. There are 20 of these events that may be programmed for the system, with each event governed by the previously defined time windows. The actions that can be programmed to automatically activate at set times are relay commands, arm/disarm and zone bypassing commands, and open/close access conditions.
Page 153 Action Code Action Specifier Auto bypass - Zone list Zone list # Auto unbypass - Zone list Zone list # Open/Close Windows Activation time 3 (During) is the only valid choice for these commands. Action Code Action Specifier Enable Opening Window by partition Partition(s) Enable Closing Window by partition Partition(s)
Page 154: Time-Driven Event Programming
Time-Driven Event Programming The following schedules can be used to activate outputs, bypass zones, arm/disarm the system, etc. based on a time schedule. Up to 20 events can be programmed for the system. Time windows must first be defined in order to be used to trigger events.
Page 155 Actions 30-31 01 ZONE LIST ? 30=Auto bypass - Zone list Enter the zone list number which 31=Auto unbypass - Zone list ENTER 1-8 contains the zones to be bypassed or unbypassed. Press to accept entry. The Time Window ? prompt appears. Action 42 Enter the group number to which 42=Enable Access Window for Access...
Page 156: Limitation Of Access By Time Worksheet
Limitation of Access by Time Worksheet Limitation of Access is a means by which a user's access code is limited to working during a certain period of time. The system provides 8 Access Schedules, each of which consists of two time windows for each day of the week and two time windows for holidays (typically one for an opening time window and the second for a closing time window).
Page 157: #81 Temporary Schedule Menu Mode
Enter the first time window number for holidays for which Hol A1 Window 1 ? 00:00 00:00 00 this access schedule applies. As the number is keyed in, the actual time that has been stored for the window will be displayed. Press * to continue. Enter the second time window number for holidays for Hol A1 Window 2 ? 00:00 00:00 00...
Page 158: Programming Temporary Schedules
Stop Time HH:MM Arm Window Start Time HH:MM Stop Time HH:MM 8 Disarm Window Start Time HH:MM Stop Time HH:MM Arm Window Start Time HH:MM Stop Time HH:MM Programming Temporary Schedules Enter [User Code] + # + 81 to enter this mode. Note that only users with authority level of manager or higher can program temporary schedules.
Page 159: #83 User Scheduling Menu Mode
This is the prompt that actually activates the Days ? MTWTFSS temporary schedule, and allows the temporary Hit 0-7 x x schedule to be customized to a particular week's needs. To select the days which are to be activated, enter 1-7 (Monday = 1). An "X" will appear under that day, indicating the schedule for that day is active.
Page 160 Enter the OFF time in 00:01 - 11:59 format. 06 OFF TIME ? 11:45 PM When the display shows the desired time, press the * key to move to the AM/PM field. In this field, any of the keys 0-9 may be used to toggle the AM/PM indication. Enter 00:00 to skip.
Page 161: System Communication
Ademco 685 receiver using software level 4.4 or higher. Must be level 4.7 or higher to fully support all new VISTA-100 report codes. 685 software levels below 4.4 cannot support Contact ID reporting. If you need to update your 685 receiver, contact your distributor.
Page 162 This is the “expanded” digit. 4+2 Format Comprised of a 4-digit subscriber number and 2-digit report code. Ademco Contact ID Comprised of a 4-digit subscriber number, 1-digit event qualifier Reporting Format ("new" or "restore"), 3-digit event code, 2-digit Partition No., and 3- digit zone number, user number, or system status number.
Page 163 Ademco Contact ID Reporting takes the following format: CCCC QEEE GG ZZZ where: CCCC = Customer (subscriber) ID Q = Event qualifier, where: E = new event , and R = restore EEE = Event code (3 hexadecimal digits) GG = Partition Number (system messages show “00”) ZZZ = Zone/contact ID number reporting the alarm, or user number for open/close reports.
Page 164: Loading Communication Defaults
LIMITATIONS 1. When using Ademco high speed, remember there are only 15 channels available, plus a duress channel. If more than 15 zones are being used, they will have to share channels. 2. With Ademco High Speed reporting, channels 9-15 cannot report troubles or bypasses.
Page 165 TABLE OF CONTACT ID EVENT CODES Code Definition Code Definition Fire Alarm O/C By User Smoke Alarm* Power-Up Armed/Auto-Arm Water Flow Alarm Cancel by User Duress Remote Arm/Disarm (Download) Silent Panic Quick Arm Audible Panic Keyswitch O/C Perimeter Burglary Call back Requested Interior Burglary Armed STAY 24 Hour Burglary...
Page 166: Communication Defaults For Low Speed Format
Bypass Trbl Opn/Cls Low Bat No checksum Primary Secondary SESCOA/RADIONICS SEL. Radionics COMMUNICATION DEFAULTS for ADEMCO HIGH SPEED FORMAT (*94*82) PRIMARY FORMAT DUAL REPORTING Ademco High Speed LOW SPEED FORMAT (Prim) STANDARD/EXPANDED REPORT FOR PRIMARY SECONDARY FORMAT Ademco High Speed...
Page 167 COMMUNICATION DEFAULTS FOR ZONES (cont'd) ZONE # LOW SPEED EXPRESS HIGH SPEED CONTACT ID – 157 – www.PDF-Zoo.com firealarmresources.com...
Page 168 COMMUNICATION DEFAULTS FOR ZONES (cont'd) ZONE # LOW SPEED EXPRESS HIGH SPEED CONTACT ID – 158 – www.PDF-Zoo.com firealarmresources.com...
Page 169 COMMUNICATION DEFAULTS FOR ZONES (cont'd) ZONE # LOW SPEED EXPRESS HIGH SPEED CONTACT ID ALARM RST. 09 TROUBLE TRBLE. RST BYPASS BYPASS RST. DURESS To program report codes, see Report Code Programming in Section 22: #93 MENU MODE PROGRAMMING. – 159 – www.PDF-Zoo.com firealarmresources.com...
Page 170: Downloading Primer
Downloading allows the operator to remotely access, program, and control the security system over normal telephone lines. Anything that can be done directly from the keypad can be done remotely, using ADEMCO's VLINK ® downloading software. To communicate with the control panel, the following is required: 1.
Page 171: On-Line Control Functions
1. The computer calls up the Control panel. (The phone number for each customer is entered into the customer's account file on the computer). 2. The Control panel "answers" at the pre-programmed ring count and executes a handshake with the computer. 3.
Page 172: Access Security
Access Security Accessing the Control from a remote location is protected against compromise by the use of 4 levels of protection: 1. Security Code Handshake: The subscriber's account number as well as an 8-digit ID number (known only to the office) must be matched between the Control and computer.
Page 173: Connecting A 4100Sm Module For Direct Wire Downloading
Connecting a 4100SM Module for Direct Wire Downloading The Control can be downloaded without using a modem or telephone line by using VLink ® Software and a 4100SM Serial Module. The direct wire downloading connection is to be temporary, and is not part of the permanent installation.
Page 174: Setting The Real-Time Clock
Section 26: SETTING THE REAL-TIME CLOCK This section provides the following information: • General information about the real-time clock • Setting the time and date General Information This system provides a real-time clock, which must be set in order for the system's event log to keep track of events by time and date.
Page 175: User Access Codes
Section 27: USER ACCESS CODES This section provides the following information: • General information about user access codes • Definition of user authority levels • How to add a user access code • How to change a user access code •...
Page 176 Level 1: Master Codes • Can perform all normal system functions • Can be used to assign up to 126 lower level codes, which can be used by other users of the system. • Cannot assign anybody a level of 0 or 1. •...
Page 177: Multiple Partition Access Examples
5 in all partitions, and that the code be kept secret. Authority level 5 cannot disarm the system unless armed by that user. Ademco Contact ID format is capable of reporting Users 001-128 uniquely. If any other report format is used, only user numbers #001 - #015 can uniquely report to the central station.
Page 178: To Add A Master, Manager Or Operator Code
Multiple Partition Access Examples Each user is programmed for a primary (home) partition. A user can also be given access to operate one or more partitions. In addition, within each partition, each user may be programmed to have different levels of authority.
Page 179 If access schedules have been programmed, this Access Group? prompt appears. Enter the user's access group Enter 0-8 number (1-8) if this user should have limited access to the system. Enter 0 if no access group should be assigned. If a 5800 series button transmitter has been enabled RF Button ? for arming/disarming functions, and is not assigned 0=NO , 1=YES...
Page 180: To Change A Master, Manager Or Operator Code
To CHANGE a Master, Manager or Operator Code Enter Installer code* + [8] + User number (002-128) + new user's code. * Or Master or Manager code, but must be code with higher level of authority than the code being changed. (i.e. Master code can change a Manager or Operator level code, but cannot change another Master code;...
Page 181: Keypad Functions
Section 28: KEYPAD FUNCTIONS This section provides the following information: • General information about keypad usage • Basic keypad functions • Global arming • Access control • Delaying closing time • Executing the "Go To" command • Viewing: A user's capabilities Zone descriptors Downloaded messages Built-in user's guide...
Page 182: Global Arming
User #002 must be programmed into the system in order for the Quick Arm feature to work. SUMMARY OF ARMING MODES Mode Features For Each Arming Mode Exit Entry Perimeter Interior Delay Delay Armed Armed AWAY STAY INSTANT MAXIMUM Global Arming If enabled for the user, the keypad will display the following: If NO, the keypad prompts for arming each partition ARM ALL...
Page 183: Access Control
Access Control If programmed, one relay may be used for access control in each partition. The relay is programmed in data field 1*76. To activate this relay, the user enters his user code + 0 . The relay will pulse for 2 seconds. Delaying Closing Time If Open/Close schedules are used, end users can manually delay closing time by extending the closing window by 1 or 2 hours.
Page 184: Viewing Zone Descriptors
Viewing Zone Descriptors The Alpha Keypads can display all programmed descriptors, which is useful to the installer when checking entries, and can be helpful to the user when there is a need to identify zones. To display descriptors, the system must be disarmed and ready to arm.
Page 185: Manual Relay Activation Mode (#70 Mode)
existing sequence displayed Enter up to 16 keystrokes. A speed key sequence can include different commands. Press the "D" key to separate different commands. For example, you may want to perform the following sequence. Desired function Keystrokes GOTO partition 2 Enter *2 Bypass zones 10 &...
Page 186 nn DEVICE IS OFF Voice: "voice descriptor DEVICE nn ON/OFF. TO HIT THE "*" KEY EXIT ENTER 00 NOW" From a keypad, press to continue. The ENTER DEVICE NO. prompt will appear. From a telephone keypad, enter 00 to exit, or enter the next relay number to be programmed.
Page 187: Testing The System
Turning the system over to the user Battery Test When AC power is present, the VISTA-100 will run a brief battery test every 60 seconds to determine if there is a battery connected, and will run an extended battery test every 24 hours to check on the battery’s condition. If the VISTA-100 finds that the battery voltage is low (less than approx.
Page 188 When this test is first activated, the system will display: Enter (Y) to have the fire bells associated with each USE BELL DING? point sound for 3 seconds when a point is faulted. 0 = NO 1 = YES Enter (N) if only keypad sounders are desired. The next prompt will be displayed.
Page 189: Burglary Walk Test
Burglary Walk Test (code + TEST [5]) This test causes the system to sound keypad beeps in response to faults on burglary and non-fire related 24 hour zones for the purpose of allowing proper zone operation to be checked without triggering alarms. Note that the system will not trigger alarms for burglary and non-fire related 24 hour zones but will trigger fire alarms while this test is active.
Page 190: Trouble Conditions
Trouble Conditions Supervisory Messages • A display of “SUPV” accompanied by a zone number (001-087) and an alpha descriptor (if programmed) indicates that a fire supervisory condition exists on that zone. This means that the operation of the fire alarm system may be compromised. Check or Trouble Messages •...
Page 191: Fire System Off-Normal Report
• "RCVR SET UP ERROR" at the keypad Indicates that the system has more wireless zones programmed than the wireless receiver can support. If this is not corrected, none of the zones in the system will be protected. If additional wireless zones are desired, use an appropriate receiver.
Page 192: Turning The System Over To The User
• Note the proper model number of this product, and the version level (if known) along with any documentation that came with the product. • Note your ADEMCO customer number and/or company name. Having this information handy will make it easier for us to serve you quickly and effectively.
Page 193: Regulatory Agency Statements
974 to enable main dialer supervision. The VISTA-100 will activate the trouble trigger when it detects a main dialer supervision fault. 5. When the back-up dialer is used, install it on the VISTA-100's PCB shield. Enable it (field (3*30) and connect it to a separate telephone line.
Page 194 UL365 POLICE STATION CONNECTED BURGLAR ALARM Follow the instructions for UL609 local instructions. For Grade A Service: • You may use the VISTA-100 dialer alone, or the 7720 Long Range Radio alone. • When using the dialer, program it to send burglary alarm, low battery and communicator test reports.
Page 195 "FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT" This equipment has been tested to FCC requirements and has been found acceptable for use. The FCC requires the following statement for your information: This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception.
Page 196 CANADIAN DEPARTMENT OF COMMUNICATIONS (DOC) STATEMENT NOTICE The Canadian Department of Communications label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. The Department does not guarantee the equipment will operate to the user's satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company.
Page 197 Insert DIP Switch Table (Board A) – 187 – www.PDF-Zoo.com firealarmresources.com...
Page 198 Insert DIP Switch Table (Board B) – 188 – www.PDF-Zoo.com firealarmresources.com...
Page 199 Insert DIP Switch Table (Board C) – 189 – www.PDF-Zoo.com firealarmresources.com...
Page 200: Summary Of System Commands
SUMMARY OF SYSTEM COMMANDS Event Logging Commands Event Log Display = Code+[#] + 60 (Installer or Master Only) Event Log Print = Code + [#] +61 (Installer or Master Only) Clear Event Log = Code + # + 62 (Installer or Master Only) Wireless System House Id Sniffer Mode=Code + [#] + 2 (Installer Only) Commands...
Page 201: Specifications
Good line when tip to ring voltage greater than approx. 25V (13V when blue jumper cut) or when handset current greater than approx. 10mA. Bad line when both voltage and current below these levels. Formats: Ademco Low Speed, Ademco 4+2 Express, Ademco High Speed, Ademco Contact ID, Sescoa and Radionics Agency Listings: Burglary:...
Page 202 Access Schedules, 146 Installer's Message, 126 Ademco 4+2 Express, 191 Dial Tone Detection, 103 Intelligent Test Report, 100 Ademco Contact Id, 152, 191 Dial Tone Pause, 102 Interior W/Delay, 96 Ademco Contact Id Reporting, 167 Digital Communicator, 191 Interior, Follower, 95...
Page 203 RF Transmitter Check-In Interval, Time-Driven Event Programming,, Pabx Access Code, 101 RF Tx Low Battery Annun, 51 Time-Driven Event Worksheet, 142 Panic Keys, 96 RF Tx Low Battery Report Enable, 51 Timers, 149 Part 68, 185 RF Tx Low Battery Report Enable, Transmitter Input Types, 48 Partition Descriptors, 125 Transmitter Supervision, 45...
Page 204 WARNING! THE LIMITATIONS OF THIS ALARM SYSTEM While this System is an advanced wireless security system, it does not offer guaranteed protection against burglary, fire or other emergency. Any alarm system, whether commercial or residential, is sub ject to compromise or failure to warn for a variety of rea sons.
Page 205 24 months from the date stamp control on the product or, for products not having an Ademco date stamp, for 12 months from date of original purchase unless the installation instructions or catalog sets forth a shorter period, in which case the shorter period shall apply.
Page 206 NOTES – 196 – www.PDF-Zoo.com firealarmresources.com...
Page 207 Ratings: 10 - 14VDC, 1.7A max. - Zones 1, 2, 8: 100 ohms max - 2mA max for smoke det. (up to 16 detectors 2k EOLR is Ademco model 610-7 See note 1, see instructions Polling Loop - Other zones: 300 ohms max of the type specified in the instructions for compatible devices.
Page 208 ALARM DEVICE MANUFACTURING CORPORATION A DIVISION OF PITTWAY CORPORATION 165 Eileen Way, Syosset, New York 11791 © Copyright 1996 PITTWAY CORPORATION N6019-2 6/96 www.PDF-Zoo.com firealarmresources.com...
