Installation distance to walls and ceiling

Combustible roof
550
Combustible wall
Fire-retardant wall of
brick or concrete
*To prevent discolouration of painted fire walls, we recommend the same side distance as to combustible walls.
Place the stove on the hearth plate and check
that the installation distances are not less than
those that are given in the figures below. The
minimum distance in front of the stove opening
to combustible parts of the building or interior
Air inlet Ø64
Permitted area for
combustible material
900
decoration must be at least 1 m.
When top connecting a steel flue, please
refer to the particular manufacturer's
installation instructions. Observe the
safety distance to combustible material
that the steel flue requires.
430
167
Hole in foot plate Ø120
120
400
300
100
Combustible wall
415
690
700
Fire-retardant wall of
brick or concrete
50*
325*
INSTALLATION DISTANCES
C34T
