- Page 1 54" Meredith ® ™ A Kichler Décor ceiling fan Kichler ® Lighting 7711 East Pleasant Valley Road P.O. Box 318010 Cleveland, Ohio 44131-8010 Instruction Manual Customer Service 866.558.5706 8:30 AM to 5:00 PM EST, Monday - Friday...
-
Page 2: Safety Rules
1. SAFETY RULES 1. To reduce the risk of electric shock, insure 9. To avoid personal injury or damage to the electricity has been turned off at the circuit fan and other items, be cautious when breaker or fuse box before beginning. working around or cleaning the fan. -
Page 3: Tools And Materials Required
54"Meredith 2. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 3. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: Fan blades (5) Canopy & Ceiling mounting bracket Ball/downrod assembly Decorative scroll assembly Coupling cover... -
Page 4: Mounting Options
4. MOUNTING OPTIONS If there isn't an existing UL (cUL for Canadian Installation) listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Secure the outlet box directly to the building Outlet box structure. -
Page 5: Hanging The Fan
54"Meredith 5. HANGING THE FAN Hanger bracket REMEMBER to turn off the power before you begin. Ceiling canopy To properly install your ceiling fan, follow the steps below. Canopy Step 1. Remove the decorative canopy cover Fig. 5 bottom cover from the canopy by turning the cover counter clockwise. - Page 6 Step 8. Slip the coupling cover, decorative scroll assembly, canopy cover and canopy onto the downrod. Secure tighten the decorative scroll set screw. (Fig. 9) Downrod Thread the hanger ball onto the downrod, insert the cross pin through the downrod and Canopy tighten.
- Page 7 54"Meredith 6. INSTALLATION OF SAFETY SUPPORT (required for Canadian installation ONLY) A safety support cable is provided to help prevent the ceiling fan from falling. Step 1. Attach the provided wood screw and Hanger bracket washers to the ceiling joist next to the Safety cable mounting bracket but do not tighten.
-
Page 8: Finishing The Installation
Step 2. (Fig. 14) Motor to Receiver Electrical Connections: Connect the black wire from the Outlet box fan to black wire marked "TO MOTOR L". Connect the white wire from the fan to the White (neutral) Black (hot) white wire marked "TO MOTOR N" from the Green or bare receiver. -
Page 9: Attaching The Fan Blades
54"Meredith 9. ATTACHING THE FAN BLADES CAUTION: Remove the five rubber shipping blocks attached to the face of the motor. These blocks keep the motor from shifting during shipping and MUST be removed during installation. Step 1. Attach a blade to a blade bracket using the screws, flat washers and fiber washers provided. -
Page 10: Installing The Light Kit
11. INSTALLING THE LIGHT KIT TO SWITCH HOUSING Lock washer Remove and discard the center plug from the switch housing. Attach the light kit to the switch housing by feeding the light kit wires (black and white) through the hole in the Switch housing center of the switch housing and then screw Center... -
Page 11: Installing The Light Bulbs & Glass Shade
54"Meredith 13. INSTALLING THE LIGHT BULBS & GLASS SHADE 1. Install 3, 60W candelabra bulbs (included). 2. Remove the decorative nut, glass cap and metal nut from the light kit. Place glass shade over the light kit stem, secure with the metal nut (rubber side on the top), add the glass cap and decorative nut. - Page 12 15. OPERATING INSTRUCTIONS Restore power to ceiling fan and test for proper operation. , and buttons: These three buttons are used to set the fan speed as follows: = High speed = Medium speed = Low speed button: This button turns the fan off. C.
- Page 13 54"Meredith 16. INSTALLING THE COOLTOUCH CONTROL SYSTEM WALL PLATE Outlet box Switch NOTE: All wiring must be in accordance with the National Electrical Code and local electrical codes. Wall plate Electrical installation should be performed by a qualified licensed electrician. Select a location to install your CoolTouch™...
-
Page 14: Troubleshooting
18. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check all electrical connections to insure proper contact. CAUTION: Make sure the main power is OFF when checking any electrical connection. 3. Make sure the transmitter batteries are installed properly. Positive (+) side facing out.
