  • Page 1 A Kichler Décor Ceiling Fan ® ™ Includes our new CoolTouch Control System Looks permanent, but goes wherever you go! U.S. Patent Pending Kichler Lighting ® 7711 East Pleasant Valley Road P.O. Box 318010 Instruction Manual Cleveland, Ohio 44131-8010 Customer Service 866.558.5706...
  • Page 2 1. SAFETY RULES 1. To reduce the risk of electric shock, insure 10. Do not use water or detergents when electricity has been turned off at the circuit cleaning the fan or fan blades. A dry dust breaker or fuse box before beginning. cloth or lightly dampened cloth will be suitable for most cleaning.

  • Page 3: Table Of Contents

    Lucia 2. TOOLS AND MATERIALS REQUIRED Philips screw driver Slot screw driver 11 mm wrench Step ladder Wire cutters 3. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: Ceiling Mounting Bracket (1) Canopy (1)
  • Page 4 4. MOUNTING OPTIONS If there isn't an existing UL ( cUL for Canadian Installation) listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Outlet box Secure the outlet box directly to the building structure.

  • Page 5: Ceiling Mounting Bracket

    Lucia 5. HANGING THE FAN Shipping Block REMEMBER to turn off the power. Follow the steps below to hang your fan properly: Remove the fan motor and housing assembly from the protective plastic bag and take the lower Styrofoam packing out of the carton. Place the Fig.

  • Page 6: Canopy Cover

    Step 6. Carefully pass the upper glass bowl Mounting Plate over the downrod and let it rest on top of the motor housing. Align the slot on the mounting Manual Nut plate with the screw stem on the motor hous- ing.
  • Page 7 Lucia 6. INSTALLATION OF SAFETY SUPPORT Flat Screw Support Brace Wood Screw ( For Canadian Installation ONLY ) Spring Washer Outlet Box A safety support cable is provided to help Ceiling prevent the ceiling fan from falling, please install it as follows.
  • Page 8 Step 3. Receiver to Supply Wires Electrical Connections: (Fig. 17) Connect the black (load) wire from the ceiling Outlet box outlet box to the black wire marked "AC in L" on the receiver.Connect the white (neutral) wire White(neutral) from the ceiling outlet box to the white wire Black(hot) marked "AC in N"...

  • Page 9: Fan Blades

    Lucia 9. ASSEMBLYING AND ATTACHING Screw THE FAN BLADES Metal Washer Fiber Washer Blade Step 1. Attach the blade to the blade bracket using the screws, washers and fiber washers provided. Refer to Fig. 19 as needed. Start each screw into bracket. Repeat for the three (3) remaining screws.

  • Page 10: Light Fixture Assembly

    11. INSTALLING THE SWITCH HOUSING NOTE: Before continuing, make sure the power is disconnected by turning off the circuit breaker of removing the fuse at the circuit box. Step 1. Remove 1 of the 3 screws on the edge of the mounting plate and loosen the other 2 screws, do not remove.

  • Page 11: Inner Glass Bowl

    190 watts and then Fig. 25 turning the power back on. Your New Kichler Ceiling Fan is now ready to use. Remember to RESTORE all power. 14. INSTALLING THE BATTERY Remove the battery compartment cover on the back of the CoolTouch™...
  • Page 12 It's a good idea to remove these batteries if your fan is not used for extend periods of time, (months). 15. OPERATING INSTRUCTIONS Restore power to ceiling fan and test for proper operation. , and buttons: These three buttons are used to set the fan speed as follows: = low speed = medium speed...

  • Page 13: Screws

    Lucia 16. INSTALLING THE COOLTOUCH™ CONTROL SYSTEM WALL PLATE Select a location to install your CoolTouch™ Control System Transmitter. You can replace an existing wall switch or, install the transmitter on ANY flat surface. Option 1: Install the control system using an existing wall switch outlet box.
  • Page 14 18.TROUBLE SHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check all electrical connections to insure proper contact. CAUTION: Make sure the main power is OFF when checking any electrical connection. 3. Make sure the batteries are installed properly. Positive (+) side facing out. 4.
