Chapter 2: Jumpers and Connectors
VGA Connector
Connector type: 2x8 16-pin header
Connector location: VGACONN1
2
16
1
15
Pin
Definition
1
DACROA_B
3
DACBOA_B
5
GND
7
GND
9
VGA_VCC
11
NC
13
AHSYNCO_B
15
DDC_CLKO_B
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
DACGOA_B
4
NC
6
GND
8
GND
10
GND
12
AVSYNCO_B
14
AVSYNCO_B
16
NC
I2C Debug Header
Connector type: 1x4 4-pin header
Connector location: CN6
4
1
Pin
Definition
1
SMB_IPMB_STBY_C_DATA
3
SMB_IPMB_STBY_C_CLK
18
Pin
Definition
2
GND
4
P5V_AUX
NSA 7130 User Manual
