Chapter 2: Jumpers and Connectors
BMC Strap
Connector type: 1x2 2-pin header, 2.54mm
Connector location: JP10
1
2
Pin
Function
NC*
Enable BMC
1-2
Disable BMC
NC: default
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
Console UART Controller Strap
Connector type: 1x2 2-pin header, 2.54mm
Connector location: JP11
1
2
Pin
Function
NC*
System UART Controller
BMC Debug UART
1-2
Controller
NC: default
11
NSA 7130 User Manual
