DEC DECstation 5000 Model 100 Series Hardware Operator's Manual

Hide thumbs Also See for DECstation 5000 Model 100 Series:
Table of Contents

Advertisement

EK-PM32C-OG-003
DECstation 5000
Model 100 Series
Hardware Operator's Guide
digital equipment corporation
maynard, massachusetts

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DECstation 5000 Model 100 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for DEC DECstation 5000 Model 100 Series

  • Page 1 EK-PM32C-OG-003 DECstation 5000 Model 100 Series Hardware Operator’s Guide digital equipment corporation maynard, massachusetts...
  • Page 2 Third printing, January 1992 The information in this document is subject to change without notice and should not be construed as a commitment by Digital Equipment Corporation. Digital Equipment Corporation assumes no responsibility for any errors that may appear in this document. The software described in this document is furnished under a license and may be used or copied only in accordance with the terms of such license.
  • Page 3: Table Of Contents

    1 Getting Started The Basic DECstation 5000 Model 100 Series Workstation .........
  • Page 4 The Mouse and Tablet ....... . 2–13 The Dial and Button Box ......2–14 Connecting the Keyboard and Mouse or Tablet to the System Unit .
  • Page 5 To Remove a CPU Module ......5–19 To Install a New CPU Module ..... . 5–22 To Test the CPU Module .
  • Page 6 8 External Storage Devices External Storage Devices That SCSI Connectors Can Use ..........8–2 Installing and Removing External Storage Devices .
  • Page 7 A Equipment Specifications DECstation 5000 Model 100 Series System Unit Equipment Specifications ........
  • Page 8 VRT16-DA and VRT16-D4 Monitor Equipment Specifications ........A–16 VRT19-DA and VRT19-D4 Monitor Equipment Specifications .
  • Page 9 Figures Typical DECstation 5000 Model 100 Series workstation ..1–2 Parts of a basic workstation ......
  • Page 10 Memory modules in memory slots 0 and 1 ....5–15 5-10 Removing a memory module ......5–16 5-11 Replacing the cover on the system unit .
  • Page 11 Attaching a system-unit-to-expansion-box cable to a SCSI connector on an expansion box ......8–9 Connecting expansion boxes in a chain ....8–10 Terminating the final expansion box .
  • Page 12 VR262 Monitor Description ......A–4 A–5 VR262 Monitor Operating Conditions ....VR262 Monitor Nonoperating Conditions .
  • Page 13 A-40 RZ23 SCSI Hard Disk Drive Description ....A–29 A-41 RZ23 SCSI Hard Disk Drive Operating Conditions ..A–29 A-42 RZ23 SCSI Hard Disk Drive Nonoperating Conditions .
  • Page 14 A-77 RRD42 Compact Disc Drive Operating Conditions ..A–51 A-78 RRD42 Compact Disc Drive Nonoperating Conditions ..A–51 A-79 RX23 Diskette Drive Description ......A–52 A-80 RX23 Diskette Drive Operating Conditions .
  • Page 15: Using This Guide

    Using This Guide This guide explains how to operate the hardware components of your DECstation 5000 Model 100 Series workstation. It discusses How to use the connectors and controls and interpret the indicator lights on your workstation hardware How to adjust your workstation hardware for your comfort...
  • Page 16: Conventions Used In This Guide

    Table 1. Conventions Used in This Guide Convention Monospace type Anything that appears on your monitor screen is set in monospace type like this. Boldface type Anything that you are asked to type is set in boldface type like this.
  • Page 17: Part I Basic Workstation Hardware

    Part I Basic Workstation Hardware...
  • Page 18: Getting Started

    Getting Started This chapter explains What parts make up the basic workstation What site requirements must be met so your hardware can operate efficiently and safely How to check the voltage requirements of the devices that make up your workstation Getting Started 1–1...
  • Page 19: The Basic Decstation 5000 Model 100 Series Workstation

    Nameplate WS33O137 Figure 1-1. Typical DECstation 5000 Model 100 Series workstation The only difference between the three models is the central processing unit (CPU) module. The CPU in the Model 120 workstation operates at a speed of 20 megahertz (MHz), the CPU in the Model 125 operates at a speed of 25 MHz, and the the CPU in the Model 133 operates at a speed of 33 MHz.
  • Page 20 In addition to the manual you are reading, you should have Any options you ordered. Any software you ordered. All the items shown in Figure 1-2, on page 1-4, with one exception. You should only have one type of video cable assembly: color, monochrome, or gray-scale.
  • Page 21 w o r k s t a t i o n l o o p b a c k c o n n e c t o r T h i c k W i r e E t h e r n e t S c r e w d r i v e r s S C S I t e r m i n a t o r A n t i s t a t i c w r i s t s t r a p...
  • Page 22: Workstation Site Requirements

    Workstation Site Requirements For your workstation to function efficiently, your work environment must meet the requirements listed here. Failure to meet these requirements can damage equipment. Caution: Temperature Keep the temperature around the workstation between 50°F and 104°F (10°C and 40°C). –...
  • Page 23: Power

    Power The fuse for your outlet must be at least 15 amperes. Be sure your electrical circuit is properly grounded. If possible, use a surge-protected power strip to connect the power cord to your workstation. Be sure the voltage for workstation devices matches that of your power source.
  • Page 24: Workstation Voltage Requirements

    Workstation Voltage Requirements The voltage for many devices, including most monitors, must match that of your power source. Your power source is either 110/120 or 220/240 volts. Where necessary, a yellow voltage label that covers the power connector on your device tells you the voltage requirements for that device.
  • Page 25: System Unit, Monitor, Keyboard, Mouse, And Tablet

    System Unit, Monitor, Keyboard, Mouse, and Tablet This chapter explains What connectors, controls, and indicator lights are present on the system unit and monitor and what they do How to connect the monitor, keyboard, and mouse or tablet to the system unit When to use the monitor power cord instead of the monitor- to-system-unit power cable How to connect the system unit power cord and the...
  • Page 26: The System Unit

    The System Unit The system unit sits flat on a level surface with the monitor on top of or next to it. Standing the system unit on its side blocks the cooling vents Caution: and can damage the unit. Connectors, Controls, and Indicator Lights on the System Unit Figure 2-1 shows the connectors and switches on the back of the system unit.
  • Page 27 Table 2-1. Connectors, Controls, and Indicator Lights on the System Unit Item Function TURBOchannel option slots The points at which optional TURBOchannel 0, 1, and 2 hardware can connect to the system unit. In Figure 2-1, on page 2-2, TURBOchannel slot 0 contains a video connector, the point at which a video cable connects the monitor to the system unit.
  • Page 28: Icons On The System Unit And Its Cables

    Icons on the System Unit and Its Cables Many of your workstation connectors and cables use icons to remind you of their functions. Figure 2-2 shows the icons used on your workstation. Communications Ethernet Reset button Keyboard Mouse SCSI WSE2O003 Figure 2-2.
  • Page 29: The Monitor

    The Monitor Make sure the monitor and system unit are turned off. Caution: Connecting or disconnecting your monitor while power is turned on can damage the monitor. To Connect the Monitor to the System Unit Select the appropriate video cable assembly for your workstation.
  • Page 30: Turning Off Your Monitor

    Place the monitor next to or on top of the system unit. Placing the monitor near an electromagnetic device, Caution: such as a printer or an electric pencil sharpener, or near magnetized objects, such as filing cabinets or steel beams in walls, can interfere with its performance.
  • Page 31 U n i t , M o n i t o r , K e y b o a r d , M o u s e , a n d T a b l e t 2 – 7 t o t h e r i g h t t o l o c k i t .
  • Page 32: Connecting A Video Cable Assembly To A Color Monitor

    Repeat this procedure with the green and blue signal cables. The green signal cable connects to the monitor connector labeled G, and the blue signal cable connects to the monitor connector labeled B. Monitor video connectors Signal cable connectors WS33O071 Figure 2-6.
  • Page 33: Connecting A Video Cable Assembly To A Vr262 19-Inch

    Gray-scale monitor Hold the 3-pin connector of the cable assembly so the widest part of the connector is on top. Firmly push the cable connector into the video option connector on the system unit. Tighten the screws on the 3-pin connector to lock the connector securely in place.
  • Page 34: Connecting A Video Cable Assembly To A Monochrome Monitor

    Monochrome monitor Press the threaded signal cable connector onto the system unit video connector to tighten it. Align the slots on the collar of the signal cable connector with the pins on the monitor video connector. Push the slotted signal connector onto the monitor video connector.
  • Page 35: The Keyboard

    The Keyboard The main part of the keyboard resembles a typewriter keyboard. In addition to the main keys, the keyboard has some special function keys, a special editing keypad, and a numeric/application keypad. The manuals for your software explain how to use the keys. Indicator lights Function keys Keyboard cable...
  • Page 36: To Adjust The Keyboard

    To Adjust the Keyboard You can tilt the keyboard or let it lie flat. To tilt it, press up on the hinged feet. Hinged feet WS33O105 Figure 2-10. Hinged feet on the keyboard 2–12 System Unit, Monitor, Keyboard, Mouse, and Tablet...
  • Page 37: The Mouse And Tablet

    The Mouse and Tablet The mouse and the tablet and puck or stylus are pointing devices to position the cursor on your monitor screen. You can use one or the other device, but not both at the same time. Your software manuals explain how to use the devices. WS33I106 Figure 2-11.
  • Page 38: The Dial And Button Box

    The Dial and Button Box You can use the optional dial and button box with your workstation. The dial and button box allow you to move data on the monitor screen. The documentation supplied with these options explains their installation and use. Communication device cable Power strip...
  • Page 39: Connecting The Keyboard And Mouse Or Tablet To The System Unit

    Connecting the Keyboard and Mouse or Tablet to the System Unit The keyboard and mouse or tablet are connected to a keyboard- mouse cable assembly that connects to the system unit. The keyboard-mouse cable assembly has a 15-pin connector at one end and a connector block with connectors for the keyboard and mouse or tablet at the other end.
  • Page 40 e , a n d T a b l e t k e y b o a r d - m o u s e c a b l e W S 3 3 O 0 3 0 c a b l e c o n n e c t o r K e y b o a r d - m o u s e K e y b o a r d - m o u s e c a b l e C o n n e c t o r b l o c k...
  • Page 41: To Position The Connector Block

    To Position the Connector Block Hold the connector block so the keyboard and mouse icons are on top. Tilt the monitor base forward slightly and slide the flap on the connector block under the base. Lower the monitor base onto the flap. Be sure that the whole flap is under the base.
  • Page 42: To Connect The Keyboard To The Connector Block

    To Connect the Keyboard to the Connector Block Hold the keyboard cable connector so the clip on the connector faces down. Push the cable connector into the connector block. The cable connector snaps into place. Keyboard icon Keyboard cable Keyboard connector Clip Connector block...
  • Page 43: To Connect The Mouse Or Tablet To The Connector Block

    To Connect the Mouse or Tablet to the Connector Block Carefully align the icon on the top of the mouse or tablet cable connector with the mouse icon on the connector block. Push the cable connector all the way into the connector block.
  • Page 44: Attaching A Scsi Terminator To The Base System Scsi Connector

    Attaching a SCSI Terminator to the Base System SCSI Connector A connector for a small computer system interface (SCSI) is built into the base system hardware, as shown in Figure 2-1, on page 2-2. When the connector is not connected to a SCSI device (a disk drive or other device that uses a SCSI interface), it must be terminated with a SCSI terminator.
  • Page 45: Attaching A Terminator To The System Scsi Connector

    Base system SCSI connector SCSI terminator Handle SCSI icon PM AG -C V~ 100 -12 0 A 3.0 V~ 220 -24 0 A 1.7 V~ 10 0-1 20 /22 0-2 A 7.9 /4. 2 Hz 50 -60 W 35 9 WS33O087 Figure 2-18.
  • Page 46: Supplying Power To The System Unit And Monitor

    Supplying Power to the System Unit and Monitor The system unit takes power from a power outlet, and the monitor, in turn, takes power from the system unit. The monitor connects to the system unit with a short cable. Sometimes the workstation is supplied with an extra power cord.
  • Page 47: To Connect The System Unit To A Power Outlet

    To Connect the System Unit to a Power Outlet Plug the connector on the power cord into the power connector on the back of the system unit. Plug the other end of the power cord into a power outlet. PM AG Power cord System unit connector...
  • Page 48: To Connect The Monitor To A Power Outlet

    To Connect the Monitor to a Power Outlet Connecting to the power outlet on the system unit Plug the connector on the monitor-to-system-unit power cable into the power connector on the back of the monitor. Plug the other end of the cable into the extra power outlet on the back of the system unit.
  • Page 49: Connecting The Monitor To A Power Outlet

    Connecting to an independent power outlet Plug the connector on the extra power cord into the power connector on the back of the monitor. Plug the other end of the power cord into a power outlet. Monitor power connector To power source WSE2I015 Figure 2-22.
  • Page 50: Ethernet Hardware For The Basic Workstation

    Ethernet Hardware for the Basic Workstation This chapter explains how to connect ThickWire Ethernet loopback connectors to all ThickWire Ethernet connectors on the system unit. Ethernet is a standard set of conventions or rules for network communications. A network is a group of computers and other communications devices that are linked together.
  • Page 51: Installing Thickwire Ethernet Loopback Connectors

    Installing ThickWire Ethernet Loopback Connectors A ThickWire Ethernet connector is built into the base system hardware, as shown in Figure 2-1, on page 2-2. If your workstation is equipped with the TURBOchannel options, you have additional ThickWire Ethernet connectors in the TURBOchannel option slots.
  • Page 52: Attaching A Thickwire Ethernet Loopback Connector

    Base system ThickWire Ethernet connector ThickWire Ethernet loopback connector V~1 00- 120 A 3.0 V~2 20- 240 A 1.7 V~ 100 -12 0/2 20- 240 A 7.9 /4.2 Hz 50- 60 W 359 WS33O115 Figure 3-1. Attaching a ThickWire Ethernet loopback connector Ethernet Hardware for the Basic Workstation 3–3...
  • Page 53: Moving The Workstation

    Moving the Workstation This chapter explains how to take your workstation apart and pack it for moving to another location. Moving the Workstation 4–1...
  • Page 54: Dismantling Your Workstation

    The end of the SCSI cable is heavy. It can damage the Caution: components in the system unit if you do not fasten it securely. Reinstalling Your Workstation To reinstall your workstation, follow the instructions in the DECstation 5000 Model 100 Series Hardware Installation Guide. 4–2 Moving the Workstation...
  • Page 55: Part Ii Optional Hardware

    Part II Optional Hardware...
  • Page 56: Internal Hardware Options

    Internal Hardware Options This chapter explains How to remove and replace the cover of the system unit How to use the antistatic wrist strap How to install and remove memory modules in the system unit How to install and remove CPU modules How to install and remove hard disk drives and removable media drives in the system unit Internal Hardware Options 5–1...
  • Page 57: Installing And Removing Memory

    Installing and Removing Memory DECstation 5000 Model 100 Series workstations use pairs of 2-megabyte or 8-megabyte memory modules. Your workstation can hold up to eight pairs of memory modules. The system unit comes with at least four 2-megabyte MS01-AA or MS01L-AA memory modules or two 8-megabyte MS01-CA memory modules in place.
  • Page 58: Removing The Cover From The System Unit

    Stand in front of the system unit, grasp each side of the cover with your hands, and pull the cover straight toward you about 2 inches (5.5 centimeters). Then pull up. PM AG -C V~ 10 0-1 20 A 3.0 V~ 22 0-2 40 A 1.7 V~ 10 0-1 20...
  • Page 59 e a n t i s t a t i c w r i s t s t r a p c a n r e s u l t i n o r h a n d l i n g i t e m s s t o r e d i n a n t i s t a t i c h e a n t i s t a t i c w r i s t s t r a p w h e n w o r k i n g o p p e r f o i l t o t h e m e t a l f r a m e t h a t m t h e c o p p e r f o i l a t t h e o p p o s i t e e n d...
  • Page 60: Inside The System Unit

    Unhook the power supply cable from the white loop on the inside of the front drive panel, as shown in Figure 5-3. Power supply cable clip WS33O101 Figure 5-3. Inside the system unit Internal Hardware Options 5–5...
  • Page 61: Removing The Front Drive Panel

    Loosen the two screws that hold the front drive panel in place. They are captive screws and cannot be removed. Unhook the power supply cable from the white loop on the end of the drive bracket on the front drive panel and loosen the two captive screws on the end of the bracket.
  • Page 62 Unhook the power supply cable from the white loop on the end of the drive bracket on the front drive panel and loosen the two captive screws on the end of the bracket. Pull up carefully on the end of the drive bracket. As you raise the end of the bracket, be sure not to damage any SCSI and power supply cables that pass through the cutout in the end of the bracket.
  • Page 63: Install Pairs Of Memory Modules

    Install pairs of memory modules Look at the numbers printed beside the memory slots inside the system unit. Find the empty slot with the lowest number. Notice that each memory slot has two connectors. You must install memory modules in pairs, one in each connector of a slot.
  • Page 64: Memory Module

    Hold the memory module so that the notched end faces right and the contacts face down. Do not touch the contacts on the memory modules. A Caution: static charge could damage the module. Memory chips Mounting holes (2) Contacts Notched end WS33O103 Figure 5-6.
  • Page 65: Inserting A Memory Module

    Tilt the top of the memory module toward the front of the system unit and insert the memory module into the empty connector. Make sure the mounting holes in the module line up with the mounting posts at the ends of the connector, as shown in Figure 5-7.
  • Page 66: Close The System Unit

    Repeat steps 1 to 5 to install another memory module in the other empty connector of the same slot. Repeat the installation for every pair of memory modules that you are installing. Be sure to install each pair of modules in the slot with the lowest number. Close the system unit Insert the tabs on the front drive panel into the cutouts on the system unit and tilt the panel halfway down into the...
  • Page 67 m t h e b a c k o f t h e u n i t . h e s y s t e m u n i t a b o u t 2 i n c h e s o f t h e s y s t e m u n i t , p o s i t i o n t h e c w r i s t s t r a p f r o m y o u r w r i s t a n d f r o m u n i t u n t i l t h e y a r e a t l e a s t fi...
  • Page 68: To Test Memory Modules

    Rest the cover on the system unit. Then slide it all the way to the back of the unit, as shown in Figure 5-11, on page 5-18. Press the cover-release screw on the back of the unit and tighten it. To Test Memory Modules Turn on the monitor.
  • Page 69: To Remove Memory Modules

    To Remove Memory Modules Follow these rules when you remove memory modules: Remove memory modules from one memory slot at a time, starting with the highest-numbered slot. Always remove memory modules from the highest-numbered slots first. Remove both memory modules from a slot. Do not leave a slot with one memory module in it.
  • Page 70: Remove The Memory Modules

    Remove the memory modules Locate the memory modules in the highest numbered memory slot. Memory slot numbers WS33O090 Figure 5-9. Memory modules in memory slots 0 and 1 Internal Hardware Options 5–15...
  • Page 71 Release, but do not remove, one of the two memory modules in the highest-numbered memory slot. Use your finger to press the spring clip on one end of the memory slot connector. Press the spring clip away from the mounting post on the connector. At the same time, press the memory module toward the front of the system unit.
  • Page 72: Close The System Unit

    Keep removing memory modules two at a time until you have removed all that you intend to. Always remove memory modules from the highest-numbered memory slots first. Close the system unit If you are replacing the existing memory modules with new ones, turn to the section ‘‘To Install Memory Modules’’, on page 5-2.
  • Page 73: Replacing The Cover On The System Unit

    Remove the antistatic wrist strap from the system unit and replace the cover on the system unit, as shown in Figure 5-11. PM AG -C V~ 10 0-1 20 A 3.0 V~ 22 0-2 40 A 1.7 V~ 10 0-1 20 /22 0-2 40 A 7.9 /4.
  • Page 74: Changing Cpu Modules

    Changing CPU Modules You may need a flat-blade screwdriver to install a new central processing unit (CPU module). To Remove a CPU Module Open the system unit. Follow the instructions that came with your worksystem software to shut down the software. Turn off the system unit by pressing the 0 on the on/off switch on the back of the unit.
  • Page 75 Find the CPU module inside the system unit, as shown in Figure 5-12, on page 5-21. With one hand, pull up carefully on a corner of the CPU module where there is a mounting post. With the other hand, use your fingernails to press the lock at the top of the mounting post into the post until you can pull the module free of the lock.
  • Page 76: Typical Cpu Module

    Lock CPU module connector Heat sinks CPU module Mounting posts WS33O082 Figure 5-12. Typical CPU module Internal Hardware Options 5–21...
  • Page 77: To Install A New Cpu Module

    To Install a New CPU Module Be sure to use the antistatic wrist strap when installing a new CPU module. Remove the new CPU module from the antistatic bag. Do not touch the pins in the module connector. A static Caution: charge could damage the CPU module components.
  • Page 78 Press the other end of the CPU module firmly into the CPU module slot in the system unit. Seat the CPU module on the mounting posts and connector. If you installed a different model CPU module than the old one, turn the system unit cover upside down and remove the nameplate medallion, as shown in Figure 5-14 on pge 5-24.
  • Page 79 s a g a i n , c a l l y o u r D i g i t a l C u s t o m e r y s t e m u n i t a n d i n s t a l l t h e C P U m o d u l e m o d u l e c o n n e c t o r s m a y n o t b e a l i g n e d p p e a r s o n t h e s c r e e n .
  • Page 80: Installing And Removing Drives In The System Unit

    Installing and Removing Drives in the System Unit You can install drives in three places in your workstation: In the base of the system unit In the front drive panel of the system unit In expansion boxes that can be connected to the system unit To install hard disk drives in the base of the system unit, turn to the section ‘‘To Install a Drive in the System Unit’’, on...
  • Page 81: Where To Install Drives In The System Unit

    System unit cover Locations for hard disk drives Bezel (for front drive panel) Base of system unit Bracket for removable media drive Front drive panel WS33O088 Figure 5-15. Where to install drives in the system unit To install drives in external storage boxes, see Chapter 8, ‘‘External Storage Devices’’.
  • Page 82: Understanding Scsi Id Numbers

    Understanding SCSI ID Numbers The workstation distinguishes each internal and external drive connected to a small computer system interface (SCSI) connector by the SCSI ID number (0 to 6) assigned to that drive. Each drive comes from the factory with a SCSI ID number already set.
  • Page 83: To Install A Drive In The System Unit

    To Install a Drive in the System Unit All internal hard disk drives are installed in the same way. Unpack the hard disk drives. Follow the instructions that came with your worksystem software to shut down the software. Type cnfg 3 and press Return. The workstation displays the configuration for the base system hardware and any previously installed SCSI drives.
  • Page 84 The difference in these two displays is that appears in the column of the second display. Write down any device codes that appear in the column of your display. In this example, we would write down tz1. Turn off the system unit by pressing the 0 on the on/off switch on the back of the unit.
  • Page 85 s k d r i v e W S 3 3 M 0 2 5 v i e w...
  • Page 86: Set The Scsi Id Number For The Hard Disk Drive

    Set the SCSI ID number for the hard disk drive Choose a SCSI ID number (0 to 6) for the drive. Choose a number that is different from any SCSI ID numbers noted in the column of the display. Read the device codes that you wrote down. In the example, .
  • Page 87 b r a c k e t . h e s y s t e m u n i t . H a n d l e i t c a r e f u l l y i f a f r o n t d r i v e p a n e l f r o m t h e s y s t e m l u p , a s s h o w n i n F i g u r e 5 - 4 , o n h e d r i v e b r a c k e t , e a s e t h e m t h r o u g h...
  • Page 88: Locations For Internal Hard Disk Drives

    Choose the location for the hard disk drive that you are installing. If you are installing one drive, it is usually convenient to install it next to the power supply. If you are installing two drives, install the one farthest from the power supply first. Power supply System module Hard disk drive...
  • Page 89: Power Supply Cable In The System Unit

    Find the connectors on the power supply and SCSI cables that correspond to the drive location that you chose. Figures 5-19 and 5-20, on pages 5-34 and 5-35, show the power supply and the SCSI cables and their connectors. Figures 5-21 and 5-22, on page 5-36 and page 5-37, show close-up views of the connectors.
  • Page 90: Scsi Cable In The System Unit

    Power supply Drive next to power supply Pull on this flap. Drive away from power supply Drive in drive bracket Terminator WS33O110 Figure 5-20. SCSI cable in the system unit Internal Hardware Options 5–35...
  • Page 91: Power Supply Cable Connector

    Plug the power supply cable connector into the power supply connector on your hard disk drive. The connectors are shaped so that they fit together only one way. Power supply cable connector WS33O012 Figure 5-21. Power supply cable connector 5–36 Internal Hardware Options...
  • Page 92: Scsi Connector

    Position the SCSI cable connector so the key is on top, as shown in Figure 5-22. Plug the cable connector into the SCSI connector on the hard disk drive. Pull on this flap. SCSI cable connector WS33O106 Figure 5-22. SCSI connector If you are installing two hard disk drives, unpack the second drive as described in Appendix D, and connect the appropriate power supply cable and SCSI cable to it.
  • Page 93 a t h t h e d r i v e . o c k i n g p o s t . M o v e t h e c a b l e s s o t h a t t e m u n i t .
  • Page 94: Close The System Unit

    The drive should rest flat in the system unit, and the locking post should stick up through the mounting hole on the drive mounting bracket. Press the sliding latch so that it snaps firmly onto the post. If you are installing two hard disk drives, insert the tabs on the second drive into the system unit cutouts and lock the drive onto the mounting post.
  • Page 95: To Test For A Drive In The Base Slot Of The System Unit

    V5.7e TCF0 ( 24 MB) (enet: 08-00-2b-0f-45-72) (SCSI = 7) --------------------------------------------------- SCSI DEV ===== ================== ========= ====== ======== RZ24 (C) DEC 0700 dcache ( 64 KB), icache ( 64 KB) mem( 0): a0000000:a03fffff 4 MB) mem( 1): a0400000:a07fffff 4 MB)
  • Page 96 If the drive is not listed at all, The cables to the drive might not be plugged in all the way. You might have set a SCSI ID number that was already set on another drive inside the system unit. Open the system unit and check for these two possibilities.
  • Page 97: System Unit

    Insert the tabs on the front drive panel into the cutouts on the system unit. Thread the loose ends of the power supply cable and SCSI cable through the large cutout in the bracket. If a drive is in the bracket, make sure the ends of the cables are correctly plugged into the connectors on the drive.
  • Page 98: Set The Scsi Id Number For Removable Media Drives

    V5.7e TCF0 ( 24 MB) (enet: 08-00-2b-0f-45-72) (SCSI = 7) --------------------------------------------------- SCSI DEV ===== ================== ========= ====== ======== RZ23 (C) DEC 0700 dcache ( 64 KB), icache ( 64 KB) mem( 0): a0000000:a03fffff 4 MB) mem( 1): a0400000:a07fffff 4 MB)
  • Page 99: Drive Panel

    Write down the new number on the same paper where you wrote the device codes. Use a pair of needle-nose pliers to set the SCSI ID number on the drive that you are installing. Set the new SCSI ID number that you chose by arranging the SCSI switches or jumpers to that number, as illustrated in Appendix D of this guide.
  • Page 100 I n t e r n a l H a r d w a r e O p t i o n s 5 – 4 5 n i t . v e s c r e w s t h a t h o l d t h e f r o n t d r i v e w s c a n n o t b e r e m o v e d .
  • Page 101: Close The System Unit

    Pull up carefully on the end of the drive bracket. If the power supply and SCSI cables are threaded through the cutout in the end of the drive bracket, ease them through the cutout as you pull up, as shown in Figure 5-4, on page 5-6.
  • Page 102 Still holding the drive bracket, carefully press the middle lengths of the power supply and SCSI cables down into the system unit, so that they won’t interfere with the drive bracket when you lower it further. If the system unit has internal, hard disk drives, carefully press the cables around the drives.
  • Page 103 a b l e i n t o t h e c o n n e c t o r o n t h e d r i v e . h e S C S I c a b l e a r o u n d t h e t e r m i n a t o r . o n n e c t o r o n t h e d r i v e i s o n t h e t o p a b l e s t r a i g h t i n t o t h e c o n n e c t o r .
  • Page 104 I n t e r n a l H a r d w a r e O p t i o n s 5 – 4 9 c w r i s t s t r a p f r o m y o u r w r i s t a n d f r o m 5 - 3 6 .
  • Page 105: Removing The Existing Bezel

    Turn the system unit cover upside down and remove the existing bezel from the cover by pressing the tabs that lock the bezel in place. Press the tabs toward the center of the bezel. Then push on the back of the bezel to remove it. Press the four tabs toward the System unit cover...
  • Page 106: Installing A New Bezel

    Find the bezel for the drive that you installed. Press the new bezel into the opening in the system unit cover from the front of the cover. System unit cover D E C s ta ti o n 5 0 0 0 /1 Bezel WS33M023...
  • Page 107: To Test For A Drive In The Front Drive Panel

    KN02-BA V5.7e TCF0 ( 24 MB) (enet: 08-00-2b-0f-45-72) (SCSI = 7) --------------------------------------------------- SCSI DEV ===== ================== ========= ====== ======== RZ55 (C) DEC 0700 RX23 (C) DEC 0700 dcache ( 64 KB), icache ( 64 KB) mem( 0): a0000000:a03fffff 4 MB)
  • Page 108: To Remove A Drive From The Front Drive Panel

    To Remove a Drive from the Front Drive Panel Removing a drive follows the same procedure as installing one. Use the detailed instructions for installing the drive to perform these steps: Shut down the software. Remove the cover from the system unit, as shown in Figure 5-1, on page 5-3.
  • Page 109: Optional Network Connections

    Optional Network Connections This chapter explains How to connect your workstation to ThickWire, ThinWire, and twisted-pair Ethernet cables How to find Ethernet station addresses for your workstation Optional Network Connections 6–1...
  • Page 110: Base System Thickwire Ethernet Connector

    All DECstation 5000 Model 100 Series workstations have a ThickWire Ethernet connector on the base system unit. You can install additional ThickWire Ethernet modules in TURBOchannel option slots 0, 1, and 2. The TURBOchannel Options Operator’s Guide explains how to do this.
  • Page 111: Connecting The Workstation To A Thickwire Ethernet Network

    Connecting the Workstation to a ThickWire Ethernet Network Find a ThickWire Ethernet cable in the networking kit that came with your workstation. WSE2I034 Figure 6-2. ThickWire Ethernet cable If necessary, follow the instructions that came with your worksystem software to shut down the software. Turn off the system unit by pressing the 0 on the on/off switch on the back of the unit.
  • Page 112: Removing A Loopback Connector From A Thickwire Ethernet Connector

    The ThickWire Ethernet connector that you are going to use on the system unit should have a loopback connector attached. Remove the loopback connector. System unit ThickWire Ethernet connector ThickWire Ethernet loopback connector V~ 10 0-1 20 A 3.0 V~ 22 0-2 40 A 1.7 V~ 10 0- 12 0/2 20...
  • Page 113 Choose the end of the Ethernet cable that has no sliding lock. Hold it so that the widest part of the connector faces Push the connector all the way into the ThickWire Ethernet connector on the system unit. Use your finger or a simple tool, such as a flat-blade screwdriver, to slide the connector lock on the system unit.
  • Page 114: Connecting The Workstation To A Thinwire Ethernet Network

    Connecting the Workstation to a ThinWire Ethernet Network To connect a ThinWire Ethernet cable to the workstation, you need a ThickWire-to-ThinWire adapter called a DESTA, a ThinWire Ethernet T-connector, a ThinWire Ethernet terminator, and a DESTA-to-ThickWire cable. These are optional items that you must order separately. You need the terminator only if your workstation connects at the end of the ThinWire Ethernet cable.
  • Page 115 Push the cable connector all the way into the DESTA connector. Use your finger or a simple tool, such as a flat-blade screwdriver, to slide the connector lock on the system unit. Hold the ThinWire Ethernet T-connector and DESTA, as shown in Figure 6-5, on page 6-8.
  • Page 116 h i n W i r e E t h e r n e t T - c o n n e c t o r W S 3 3 O 0 9 6 T - c o n n e c t o r T e r m i n a t o r...
  • Page 117 Connect the terminator and a ThinWire Ethernet network cable, or connect two ThinWire Ethernet network cables. If you are connecting the terminator, You can connect the terminator to either end of the T-connector. Align the slots inside the terminator cap with the pins on the end of the T-connector, push the terminator onto the T-connector, and twist the terminator to the right to lock it.
  • Page 118: Connecting The Workstation To An Unshielded Twisted-Pair

    Connecting the Workstation to an Unshielded Twisted-Pair Ethernet Network To connect an unshielded twisted-pair Ethernet cable to the workstation, you need a ThickWire-to-twisted-pair adapter and a twisted-pair-adapter-to-ThickWire cable. These are optional items that you must order separately. Unpack the ThickWire-to-twisted-pair adapter and the twisted-pair-adapter-to-ThickWire cable.
  • Page 119: A Thickwire-To-Twisted-Pair Adapter And Twisted-Pair-Adapter-To-Thickwire Cable

    Twisted-pair-to-ThickWire cable To ThickWire Ethernet connector To the base system on the ThickWire-to-twisted-pair ThickWire Ethernet adapter connector ThickWire Twisted-pair Front view Back view Ethernet modular connector connector ThickWire-to-twisted-pair adapter Clip WS33O118 Figure 6-6. A ThickWire-to-twisted-pair adapter and twisted-pair- adapter-to-ThickWire cable Optional Network Connections 6–11...
  • Page 120 Follow the instructions that came with your worksystem software to shut down the software. Turn off the system unit by pressing the 0 on the on/off switch on the back of the unit. The ThickWire Ethernet connector that you are going to use on the system unit should have a loopback connector attached.
  • Page 121: Finding Your Ethernet Station Addresses

    Finding Your Ethernet Station Addresses Every Ethernet connector has a built-in controller. That controller has a unique ID number called an Ethernet station address. Find the station addresses of your workstation and tell your system manager what they are. He or she will complete the Ethernet installation by entering your name and station addresses in the database of network users.
  • Page 122: External Communications Options

    External Communications Options This chapter explains How to connect a communication device directly to the system unit How to use a communications connector adapter External Communications Options 7–1...
  • Page 123: Communications Connectors On The System Unit

    External Communications Options Communications devices that can be used with your DECstation 5000 Model 100 Series workstation include printers, plotters, modems, and console terminals. The devices connect to the communications connectors on the system unit. PM AG -C V~ 10 0-1 20 A 3.0...
  • Page 124: Communications Device Connectors And An Adapter

    The devices have two types of connectors : A 25-pin connector, which can be attached directly to the communications connectors on the system unit A modular connector, which requires a communications connector adapter before it can be connected to the system unit Communication Modular...
  • Page 125: Installing A Device With A 25-Pin Connector

    Installing a Device with a 25-Pin Connector You can connect 25-pin communication connectors directly to the system unit. Follow the instructions that came with your device to perform these tasks: Be sure the device is turned off. Set up the device and attach the cable and power cord that came with it.
  • Page 126: Connecting A Communications Device With A 25-Pin Connector

    d i g i t a l PM AG -C V~1 00- 120 A 3.0 V~2 20- 240 A 1.7 PM AD -A V~ 100 -12 0/2 20 A 7.9 /4.2 Hz 50- 60 W 359 System unit communications connector 25-pin connector WS33I008 Figure 7-3.
  • Page 127: External Storage Devices

    External Storage Devices This chapter describes external storage devices that can attach to a SCSI connector. The description includes The type and number of devices you can connect How to connect external storage devices How to check storage devices after they are installed External Storage Devices 8–1...
  • Page 128: External Storage Devices That Scsi Connectors Can Use

    External Storage Devices That SCSI Connectors Can Use Each SCSI connector can support up to seven storage devices. The devices can be any of the following: Any drive installed in a BA42 expansion box A TK50Z tape drive A TLZ04 digital audio tape drive An RRD40 optical compact disc drive Any internal drives that attach to the SCSI connector The external drives are contained in expansion boxes that...
  • Page 129: Installing And Removing External Storage Devices

    Installing and Removing External Storage Devices To Install External Storage Devices Connect external storage devices to form a chain, including as many as seven devices in each chain. Each device must have a separate SCSI ID number so the workstation can identify the device.
  • Page 130: Set Up Your Storage Expansion Boxes

    Set up your storage expansion boxes Place the external drives for each chain as near as possible to the SCSI connector to which you will attach the chains. For each expansion box, locate these cables and termina- tors: One system-unit-to-expansion-box cable that has a different connector at each end One expansion box terminator One power cord for each expansion box you are using...
  • Page 131: Set The Scsi Switches For Each Device

    Do not use more than 236 inches (6 meters) of cable, including the cable inside the expansion boxes and system unit, to connect a chain of drives. If the chain has more than 236 inches of cable, some of the data stored on the drives may be lost. Table 8-1 lists the length of the cables that you are using.
  • Page 132 W S 3 3 I 0 0 7 p e d r i v e e x p a n s i o n b o x...
  • Page 133: Connect Expansion Boxes To The System Unit

    Table 8-2. SCSI ID Switch Settings Hard Disk Drives in a SCSI BA42 Expansion Box or TK50Z Tape Drive or ID Number RRD40 Compact Disc Drive TLZ04 Tape Drive Up Up Down Down Down Up Up Down Up Down Up Down Up Down Down Down Up Up Down Up Up...
  • Page 134 w e e n t h e h a n d l e a n d t h e b a c k o f K 5 0 Z t a p e d r i v e , s l i d e t h e c a b l e n n e c t o r s o t h e D I G I T A L l o g o f a c e s u p .
  • Page 135: Attaching A System-Unit-To-Expansion-Box Cable To A Scsi

    Push the cable connector into the expansion box connector as far as it will go. Press the two wire brackets firmly against the sides of the cable connector until they click into the grooves on the connector. RRD40 optical compact disc drive TK50Z tape drive Wire brackets Groove...
  • Page 136: Connecting Expansion Boxes In A Chain

    Connect any additional expansion boxes. Plug one end of an 18-inch box-to-box expansion cable into the unused SCSI connector on the back of the expansion box on the end of the chain. Plug the other end of the cable into a SCSI connector on the new box in the chain.
  • Page 137: Terminating The Final Expansion Box

    On the last box in the chain, connect an expansion box terminator to the unused SCSI connector. Wire brackets Expansion box connector Terminator RRD40 optical compact disc drive expansion box TLZ04 tape drive expansion box TK50Z tape drive expansion box BA42 storage expansion box To SCSI connector on system unit...
  • Page 138: Connecting Power Cords

    Plug the end of a power cord into the power connector on each expansion box as shown in Figure 8-8. Plug the other end of each cord into a power outlet. Turn on each expansion box and then the system unit. Power cord WSE2I052 Figure 8-8.
  • Page 139: To Test External Storage Devices

    TCF0 (scsi = 7) --------------------------------------------------- SCSI DEV ===== ================== ========= ====== ======== RRD40 (C) DEC 0700 CD-ROM This sample display shows two external devices in the base slot. The device codes in the column show that the devices are a hard disk drive (...
  • Page 140: To Remove A Drive Expansion Box

    To Remove a Drive Expansion Box The following steps show you how to remove a drive expansion box. For detailed information about any of these steps, see the explanation of that step earlier in this chapter. Shut down the software. Turn off all system hardware.
  • Page 141: Part Iii Testing And Troubleshooting

    Part III Testing and Troubleshooting...
  • Page 143: Starting And Testing Workstation Hardware

    Starting and Testing Workstation Hardware This chapter explains How to turn your workstation on and off How the power-up and system self-tests operate How to set your keyboard language How to check the configuration of your workstation Starting and Testing Workstation Hardware 9–1...
  • Page 144: Turning On Your Workstation

    Turning On Your Workstation Before turning on your workstation, Check to be sure that the power cord is plugged into an electrical outlet. If your workstation is on a power strip, be sure the power strip is plugged into a power outlet and turned on. Every component of your workstation has a power indicator light that glows when you switch on the power.
  • Page 145: Turn On External Devices

    Turn On External Devices Turn on each expansion box. Most boxes have rocker switches. Some have push switches. Turn on your communications device, if you have one. On/off switches WSE2O019 Figure 9-1. Expansion box on/off switches Starting and Testing Workstation Hardware 9–3...
  • Page 146: Turn On The Monitor

    Turn On the Monitor Most monitor on/off switches are rocker switches marked 1 for on and 0 for off. Press the 1 to turn on the power. Some monitors have a push switch instead of a rocker switch. Press the switch in to turn on the power. Press this type Press the I on Press and release this...
  • Page 147: Turn On The System Unit

    Turn On the System Unit The system unit on/off switch is on the back of the system unit. Turn on the system unit by pressing the 1 on the on/off switch. PM AG V~ 10 0- 12 0 A V~ 22 0- 24 0 A V~ 10 0- 12 0/ 22...
  • Page 148: If Your System Unit Fails To Turn On

    If your workstation language has been set, the system unit displays text like the following (unless a serial-line console is in use): KNO2-BA V5.7e >> If the workstation language has not been set, the system unit displays the following language menu first: 1) Dansk 9) Français (Suisse Romande) 2) Deutsch...
  • Page 149: Testing Your Workstation

    Testing Your Workstation Run the System Self-Test Type test and press Return to run the system self-test. As the system performs the subtests that make up the self-test, it briefly displays the name of each subtest on the screen. The tests can take 15 minutes or more to run. When all tests have been completed successfully, the system unit displays the console prompt ( >>...
  • Page 150: Stopping The Workstation Without Turning It Off

    Stopping the Workstation Without Turning It Off If ULTRIX is your worksystem software, you can shut it down by typing shutdown -h now at the ULTRIX prompt and pressing Return. If you are unable to return to console mode using this shutdown command, you can stop your workstation and all worksystem software by pressing the halt button on the back of the system unit.
  • Page 151: Turning Off The Workstation

    Turning Off the Workstation If your worksystem software has been installed, follow the instructions that came with that software to shut down the software. Turn off the power. If your workstation takes power from a power strip, turn off the power strip. If your workstation is not on a power strip, Turn off any communications device by following its instructions.
  • Page 152: Troubleshooting

    Troubleshooting This chapter explains What kind of information your Customer Support Center needs when you ask for help How to be sure all components of your workstation are functioning How to use the system self-tests to diagnose common problems new users often have How to diagnose and solve other problems Troubleshooting 10–1...
  • Page 153: Where To Look For Troubleshooting Information

    Where to Look for Troubleshooting Information If some part of your workstation fails to turn on, look in the section ‘‘Is It On?’’, on page 10-4. If the workstation turns on, but a component doesn’t function properly, look in the section ‘‘Is It Connected?’’, starting on page 10-6.
  • Page 154: Contacting Your Customer Support Center

    Contacting Your Customer Support Center If you follow the recommendations in this chapter and your system problem is still not fixed, call your Customer Support Center. The service representative at the center will ask you these questions: What kind of workstation do you have? What is its serial number? How much memory does it have? What kind of monitor is connected to it?
  • Page 155: Is It On

    Is It On? The diagnostic indicator lights are eight small lights on the back of the system unit. They show whether the basic components of the workstation are turned on and ready for use. If the workstation does not turn on and no error message appears on the monitor, the pattern of the indicator lights indicates which portion of the power-up self-test failed.
  • Page 156: Interpreting Diagnostic Indicator Lights

    Table 10-1. Interpreting Diagnostic Indicator Lights Lights Meaning   If the workstation does not turn on, a device or module is not connected properly or is broken. If the workstation turns on, all components of the workstation have been initialized, and the workstation is ready for use.   Workstation hardware initialization could not begin.
  • Page 157: Is It Connected

    Is It Connected? Many problems that you are likely to have when you first start using your workstation can be solved easily. Table 10-2 lists some problems that occur with new users and some problems that occur after new hardware has been installed. The table gives some solutions.
  • Page 158 Table 10-2 (Cont.). Solutions to Common Problems Problem Solution The screen display is distorted or unstable. Shut down your worksystem software, if necessary, and turn off the system unit and monitor. Make sure the video cable connectors are correctly attached to the monitor and system unit. Check Appendix A to be sure that your monitor is the right one for the graphics module that you are using.
  • Page 159 Table 10-2 (Cont.). Solutions to Common Problems Problem Solution The DIGITAL logo is red instead of blue on Shut down your worksystem software and turn off the the login screen on system unit and monitor. your color monitor. Remove the video cable connector from the video connector on the system unit.
  • Page 160 Table 10-2 (Cont.). Solutions to Common Problems Problem Solution You cannot connect to your networks, Shut down your worksystem software and turn off the and you know the system unit. worksystem and network software are Make sure the Ethernet connectors on the system unit functioning.
  • Page 161 Table 10-2 (Cont.). Solutions to Common Problems Problem Solution The cursor on the screen fails to follow Shut down your worksystem software and turn off the the movement of system unit. your pointing device (mouse, puck, or Make sure the cable for the device is connected securely stylus).
  • Page 162 Table 10-2 (Cont.). Solutions to Common Problems Problem Solution If you have more than one external storage device, Make sure that all the devices are turned on, and that the power outlets they are plugged into have power. Type cnfg and the number of the slot in which the device is connected.
  • Page 163 Table 10-2 (Cont.). Solutions to Common Problems Problem Solution A red light blinks rapidly on the front Push the load/unload button four times. of your TK50Z tape drive. Turn the tape drive off and then on once. Nothing happens when you try to use Make sure the printer is turned on.
  • Page 164 Table 10-2 (Cont.). Solutions to Common Problems Problem Solution Nothing happens when you try to use Make sure the device is turned on. a communications device. Shut down your worksystem software, if necessary, and turn off the device and the system unit. Make sure the device power cord is connected to an active power source.
  • Page 165: Is It Working

    Is It Working? Self-tests are programs that check your workstation hardware to be sure that it is functioning properly. Self-tests have numerous subtests that examine specific workstation components. When a subtest discovers a problem, it displays a coded message, called an error message, on the screen.
  • Page 166: How To Interpret Self-Test Messages

    How to Interpret Self-Test Messages Self-tests display error messages when they discover problems in the hardware. If the slot number is 0, 1, or 2, the problem is in the TURBOchannel option slot that has the same number. If the slot number is 3, the problem is in the base system hardware.
  • Page 167: Self-Test Error Messages For The Base System Slot

    Table 10-3. Self-Test Error Messages for the Base System Slot cache/data The RAM cache in the CPU module is faulty. Copy the entire message cache/fill and call your system manager or Customer Support Center. cache/isol cache/reload cache/seg The math coprocessor in the CPU module is faulty. Copy the entire message and call your system manager or Customer Support Center.
  • Page 168 Table 10-3 (Cont.). Self-Test Error Messages for the Base System Slot The message indicates that a memory module does not read and write values correctly. If this type of message appears, copy the entire message and call your system manager or Customer Support Center. mem/float10 A part of the memory module failed to read and write a one and zero pattern.
  • Page 169 Table 10-3 (Cont.). Self-Test Error Messages for the Base System Slot ni/cllsn The Ethernet controller in the base system slot is faulty. Copy the ni/common entire message and call your system manager or Customer Support ni/crc Center. ni/ctrs ni/dma1 ni/dma2 ni/int ni/int-lb ni/m-cst...
  • Page 170 Table 10-3 (Cont.). Self-Test Error Messages for the Base System Slot scc/io The controller for one of the communications connectors, the connector itself, or a cable attached to the connector is faulty. Make sure that the cables to all your communications devices are plugged in. Then turn the system unit off and on.
  • Page 171: Using The Console Commands

    Using the Console Commands This chapter tells you how to Select console and operating modes Use the console commands Set environment variables Using the Console Commands 11–1...
  • Page 172: Console And Operating Modes

    Console and Operating Modes Your workstation functions in two modes: console mode and operating mode. Console mode lets you use the setup and testing software that is built into the workstation. Operating mode lets you use your worksystem software. This manual explains how to use the workstation in console mode.
  • Page 173: Console Prompts

    Turn off the power to the system unit and turn it back on again. Turning off the power or pressing the halt button with Caution: your workstation and any worksystem software running may result in the loss or corruption of data. Console prompts When you use console mode, the workstation displays one of these two prompts on the system console screen:...
  • Page 174 To choose operating mode, boot (start) the operating system in either of these ways: Type boot at the console prompt and press Return, or Set the worksystem software to boot the operating system automatically. For either of these procedures to work, you must set the boot environment variable for your workstation and set the haltaction environment variable to b.
  • Page 175: Typing Console Commands

    Typing Console Commands You can use the console commands when the system monitor displays the prompt . Follow these rules: >> R> Type uppercase and lowercase letters exactly as they appear in this manual. The system recognizes uppercase and lowercase letters as different input. Press Return after typing a command.
  • Page 176: Conventions Used In This Chapter

    Conventions Used in This Chapter Letters in boldface type like this should be typed exactly as they appear. Words in italic type like this OR LIKE THIS are options and arguments for the commands. You have to replace them with the appropriate information. For example, the script command has a scriptname argument.
  • Page 177: Console Commands

    Console Commands This section explains all of the console commands, but you will probably use only a few of them. The rest are for system managers, service representatives, and other technical specialists. Table 11-1 lists the console commands. Table 11-1. Console Commands Command Function Displays a list of console commands and formats...
  • Page 178 This list shows the console commands as they appear in the help menu on the screen. To display the help menu, type a question mark (?) and press Return. boot [[-z #] [-n] #/path [ARG...]] cat SCRPT cnfg [#] d [-bhw] [-S #] RNG val e [-bhwcdoux] [-S #] RNG erl [-c] go [ADR]...
  • Page 179: Description Of The Console Commands

    Description of the Console Commands To use a console command, type the command as shown, add appropriate options and arguments, and press Return. For clarity, the console prompt ( ) precedes the format >> descriptions. >>? [ command ] The ?, or help, command displays the list of console commands, as shown on page 11-8.
  • Page 180: Cat

    The following example of the boot command uses the options and arguments set in the boot environment variable: boot The following command boots from a tape drive (tz5) in base slot 3; tz5 is the SCSI code of the drive: boot 3/tz5 The following command boots from the network that is connected to your workstation at option slot 2:...
  • Page 181: Cnfg

    V5.7e TCF0 ( 24 MB) (enet: 08-00-2b-0f-45-72) (SCSI = 7) --------------------------------------------------- SCSI DEV ===== ================== ========= ====== ======== RZ55 (C) DEC 0700 RRD40 (C) DEC 0700 CD-ROM dcache ( 64 KB), icache ( 64 KB) mem( 0): a0000000:a03fffff 4 MB)
  • Page 182 KN02-BA V5.7e TCF0 ( 24 MB) (enet: 08-00-2b-0f-45-72) (SCSI = 7) --------------------------------------------------- SCSI DEV ===== ================== ========= ====== ======== RZ55 (C) DEC 0700 RX23 (C) DEC 0700 dcache ( 64 KB), icache ( 64 KB) mem( 0): a0000000:a03fffff 4 MB)
  • Page 183 Device descriptor. This is a general description of the device. There are three device descriptors: for direct access drives, such as hard disk and floppy drives; sequential access drives, such as tape drives; and CD-ROM for optical compact disc drives. Memory slot number.
  • Page 184: Module Codes

    Table 11-2. Module Codes Code Description Monochrome frame buffer. Color frame buffer. 2D graphics accelerator. Low 3D graphics accelerator. Installed in two adjacent DA: PXG slots, but shown as being installed in the lower- numbered slot. Mid 3D graphics accelerator. Installed in two adjacent EA: PXG slots, but shown as being installed in the lower- numbered slot.
  • Page 185: Scsi Device Codes And Descriptors

    Table 11-3 shows the device codes and device descriptors of SCSI devices. Table 11-3. SCSI Device Codes and Descriptors Device Device Code Descriptor Type of Drive Floppy disk and diskette CD-ROM Optical compact disc Hard disk Tape >>d [ OPTIONS ] RANGE value Options can be Word (default) Halfword...
  • Page 186 Multiple address ranges separated by commas (range,range). Note that no space follows the comma in an address range. The -S option causes a value to be stored repeatedly in memory. The value is stored count times at each address in the address range.
  • Page 187: Erl

    Multiple address ranges separated by commas (range,range). Note that no intervening space follows the comma in an address range. You can choose how to display the memory data with the format options -x, -o, -u, -d, and -c. You can use more than one option, in which case the data is displayed in every format that you choose.
  • Page 188: Passwd

    >>ls [ # ] The ls command displays a list of the files in a module ROM. If you do not specify a slot number (#), the command lists the files for all modules. passwd >>passwd [ OPTIONS ] Options can be Set a new console password.
  • Page 189: Printenv

    At this prompt, you can only boot your worksystem software or enter your console password. Boot your worksystem software. Type boot and press Return. This is the only boot command that you can use. It has no options or arguments. It uses the values that you set in the boot environment variable (see ‘‘Environment Variables’’, on page 11-22).
  • Page 190: Script

    script >>script scriptname The script command allows you to write a short, temporary script, or small program, at the system console. After you write the script, you can run it with the sh command, or you can type the name scriptname of the script alone. To write a script, type script and a name for the script.
  • Page 191: Unsetenv

    The -e option directs the shell to exit when an error occurs. Normally, the shell ignores errors. The -b option executes the script specified by scriptname instead of creating a subshell. The -v option causes the script to be echoed to the console when it is executed.
  • Page 192: Environment Variables

    Environment Variables Environment variables store system parameters and scripts and pass information to the operating system. Some environment variables stay in memory, but others are lost when you turn off the power. Table 11-4 summarizes the console commands for setting environment variables.
  • Page 193 Table 11-5 (Cont.). Environment Variables Set by the User haltaction Specifies what happens when you press the halt button or turn on the power: Boots the worksystem software, as specified by the boot environment variable. Halts the worksystem software and displays the console prompt.
  • Page 194: Part Iv

    Part IV Appendixes...
  • Page 195: A Equipment Specifications

    Equipment Specifications This appendix lists the physical specifications, operating conditions, and nonoperating conditions for the following items: DECstation 5000 Model 100 Series system unit VR262 monitor VR297 monitor VR299 monitor VR319-CA and VR319-C4 monitor VR319-DA and VR319-D4 monitor VRT16 monitor...
  • Page 196 RZ57 hard disk drive TK50Z tape drive TZ30 tape drive TZK10 QIC tape drive TLZ04 cassette tape drive RRD40 optical compact disc drive RRD42 optical compact disc drive RX23 diskette drive RX33 diskette drive A–2 Equipment Specifications...
  • Page 197: Decstation 5000 Model 100 Series System Unit Equipment Specifications

    DECstation 5000 Model 100 Series System Unit Equipment Specifications Table A-1. System Unit Description Weight 12.70 to 22.70 kg (28.00 to 50.00 lb) Height 10.16 cm (4.00 in) Width 51.03 cm (20.09 in) Depth 43.48 cm (17.12 in) Input voltage Auto adjust 100–120 or 220–240 Vac...
  • Page 198: Vr262 Monitor Equipment Specifications

    VR262 Monitor Equipment Specifications Table A-4. VR262 Monitor Description Weight 19.05 kg (42.00 lb) Height 39.37 cm (15.50 in) Width 45.47 cm (17.90 in) Depth 39.12 cm (15.40 in) External controls, switches, and Brightness indicators Contrast Power switch Power indicator Cathode-ray tube (CRT) 483 mm (19 in) diagonal Monochrome...
  • Page 199: Vr262 Monitor Operating Conditions

    Table A-4 (Cont.). VR262 Monitor Description – Frequency 60 Hz – Front porch 0 horizontal lines – Lines displayed – Sync pulse 3 horizontal lines – Vertical period 16.67 ms Power – Power supply type Transistor, switch mode ac to dc converter –...
  • Page 200: Vr297 Monitor Equipment Specifications

    VR297 Monitor Equipment Specifications Table A-7. VR297 Monitor Description Weight 29.03 kg (64.00 lb) Height 40.64 cm (16.00 in) Width 40.64 cm (16.00 in) Depth 45.07 cm (17.75 in) External controls, switches, and Contrast indicators Power switch Power indicator V-STAT, H-STAT, V-CENT Tilt range 5°...
  • Page 201: Vr297 Monitor Operating Conditions

    Table A-7 (Cont.). VR297 Monitor Description – Blanking interval 37 lines – Frequency 60 Hz – Front porch 0 lines – Sync pulse 3 lines – Vertical period 16.67 ms Video rate – Pixel frequency 69.189 MHz – Pixel period 14.45 ns nominal Power –...
  • Page 202: Vr299 Monitor Equipment Specifications

    VR299 Monitor Equipment Specifications Table A-10. VR299 Monitor Description Weight 31.75 kg (70.00 lbs) Height 46.99 cm (18.50 in) Width 50.55 cm (19.90 in) Depth 52.58 cm (20.70 in) External controls, switches, and Brightness indicators Contrast Degauss Power switch Power indicator Voltage selector switch Swivel range 120°...
  • Page 203: Vr299 Monitor Operating Conditions

    Table A-10 (Cont.). VR299 Monitor Description – Sync pulse 1,850 ns Vertical rate timing – Active video time 16.0 ms – Blanking interval 37 horizontal lines – Frequency 60 Hz – Front porch 0 horizontal lines – Sync pulse 3 horizontal lines –...
  • Page 204: Vr319-Ca And Vr319-C4 Monitor Equipment Specifications

    VR319-CA and VR319-C4 Monitor Equipment Specifications Table A-13. VR319-CA and VR319-C4 Monitor Description Weight 22.68 kg (50.00 lb) Height 45.72 cm (18.00 in) Width 49.55 cm (19.50 in) Depth 40.13 cm (15.80 in) External controls, switches, and Brightness indicators Contrast Degauss Power switch Power indicator...
  • Page 205: Vr319-Ca And Vr319-C4 Monitor Operating Conditions

    Table A-13 (Cont.). VR319-CA and VR319-C4 Monitor Description – Front porch 0.2670 ns – Horizontal period 14.1519 – Pixels displayed 10.6806 – Sync pulse 1.3351 ns Vertical rate timing – Active video time 14.4915 – Back porch 0.467011 ns – Blanking interval 0.551922 –...
  • Page 206: Vr319-Ca And Vr319-C4 Monitor Nonoperating Conditions

    Table A-15. VR319-CA and VR319-C4 Monitor Nonoperating Conditions Temperature range 40°C to 66°C ( 40°F to 151°F) Relative humidity 10% to 95% noncondensing Maximum wet-bulb temperature 46°C (115°F) packaged Altitude 4,900 m (16,000 ft) maximum A–12 Equipment Specifications...
  • Page 207: Vr319-Da And Vr319-D4 Monitor Equipment Specifications

    VR319-DA and VR319-D4 Monitor Equipment Specifications Table A-16. VR319-DA and VR319-D4 Monitor Description Weight 22.68 kg (50.00 lb) Height 45.72 cm (18.00 in) Width 49.55 cm (19.50 in) Depth 40.13 cm (15.80 in) External controls, switches, and Brightness indicators Contrast Degauss Power switch Power indicator...
  • Page 208: Vr319-Da And Vr319-D4 Monitor Operating Conditions

    Table A-16 (Cont.). VR319-DA and VR319-D4 Monitor Description – Front porch 0.2446 ns – Horizontal period 12.9579 – Pixels displayed 9.7853 – Sync pulse 1.2232 ns Vertical rate timing – Active video time 13.2767 – Back porch 0.427864 ns – Blanking interval 0.505658 –...
  • Page 209: Vr319-Da And Vr319-D4 Monitor Nonoperating Conditions

    Table A-18. VR319-DA and VR319-D4 Monitor Nonoperating Conditions Temperature range 40°C to 66°C ( 40°F to 151°F) Relative humidity 10% to 95% noncondensing Maximum wet-bulb temperature 46°C (115°F) packaged Altitude 4,900 m (16,000 ft) maximum Equipment Specifications A–15...
  • Page 210: Vrt16-Da And Vrt16-D4 Monitor Equipment Specifications

    VRT16-DA and VRT16-D4 Monitor Equipment Specifications Table A-19. VRT16-DA and VRT16-D4 Monitor Description Weight 25.00 kg (56.00 lb) Height 40.90 cm (16.10 in) Width 40.60 cm (16.00 in) Depth 45.30 cm (17.80 in) External controls, switches, and Brightness indicators Contrast Power switch Power indicator V-CENT, H-STAT, V-STAT...
  • Page 211: Vrt16-Da And Vrt16-D4 Monitor Operating Conditions

    Table A-19 (Cont.). VRT16-DA and VRT16-D4 Monitor Description – Sync pulse 1,335.1 ns Vertical rate timing – Active video 14.4915 ms – Blanking interval 39 horizontal lines – Frequency 66.4743 Hz – Front porch 3 horizontal lines – Sync pulse 3 horizontal lines –...
  • Page 212: Vrt19-Da And Vrt19-D4 Monitor Equipment Specifications

    VRT19-DA and VRT19-D4 Monitor Equipment Specifications Table A-22. VRT19-DA and VRT19-D4 Monitor Description Weight 34.02 kg (75.00 lb) Height 47.55 cm (18.72 in) Width 49.94 cm (19.66 in) Depth 46.96 cm (18.49 in) External controls, switches, and Brightness indicators Contrast Power switch Power indicator V-CENT, H-STAT, V-STAT...
  • Page 213: Vrt19-Da And Vrt19-D4 Monitor Operating Conditions

    Table A-22 (Cont.). VRT19-DA and VRT19-D4 Monitor Description – Sync pulse 1,335.1 ns Vertical rate timing – Active video 14.4915 ms – Blanking interval 39 horizontal lines – Frequency 66.4743 Hz – Front porch 3 horizontal lines – Sync pulse 3 horizontal lines –...
  • Page 214: Lk201 Keyboard Equipment Specifications

    LK201 Keyboard Equipment Specifications Table A-25. LK201 Keyboard Description Weight 2.04 kg (4.50 lb) Height 5.08 cm (2.00 in) Width 53.34 cm (21.00 in) Depth 17.15 cm (6.75 in) Number of keys Number of indicators 4 status LEDs Language variations Software selectable (keycaps required) Cable 1.8 m (6 ft) uncoiled length...
  • Page 215: Lk201 Keyboard Nonoperating Conditions

    Table A-27. LK201 Keyboard Nonoperating Conditions Temperature range 40°C to 66°C ( 40°F to 151°F) Relative humidity 10% to 95%, noncondensing Maximum wet-bulb temperature 46°C (115°F), packaged Altitude 4,900 m (16,000 ft) maximum Equipment Specifications A–21...
  • Page 216: Lk401-Aa Keyboard Equipment Specifications

    LK401-AA Keyboard Equipment Specifications Table A-28. LK401-AA Keyboard Description Weight 1.16 kg (2.56 lb) Height 4.76 cm (1.88 in) Width 47.80 cm (19.00 in) Depth 19.20 cm (7.56 in) Number of keys Number of indicators 2 status LEDs Language variations Software selectable (keycaps required) Cable 1.8 m (6 ft) uncoiled length...
  • Page 217: Lk401-Aa Keyboard Nonoperating Conditions

    Table A-30. LK401-AA Keyboard Nonoperating Conditions Temperature range 40°C to 66°C ( 40°F to 151°F) Relative humidity 10% to 95%, noncondensing Maximum wet-bulb temperature 52°C (126°F), packaged Altitude 4,900 m (16,000 ft) maximum Equipment Specifications A–23...
  • Page 218: Vsxxx-Ga Mouse Equipment Specifications

    VSXXX-GA Mouse Equipment Specifications Table A-31. VSXXX-GA Mouse Description Weight 97 g (3.4 oz) without cable Height 32.5 mm (1.28 in) Diameter 60.9 mm (2.4 in) Buttons Cable length 1.5 m (5 ft) shielded, 5 conductors and terminals in a 7-pin micro-DIN-type connector (male) Accuracy 3% 0 to 25 cm (0 to 10 in) per second in any direction...
  • Page 219: Vsxxx-Ga Mouse Nonoperating Conditions

    Table A-33. VSXXX-GA Mouse Nonoperating Conditions Temperature range 40°C to 66°C ( 40°F to 151°F) Relative humidity 5% to 95% noncondensing Maximum wet-bulb temperature 46°C (115°F) packaged Altitude 7,600 m (25,000 ft) maximum Equipment Specifications A–25...
  • Page 220: Vsxxx-Ab Tablet Equipment Specifications

    VSXXX-AB Tablet Equipment Specifications Table A-34. VSXXX-AB Tablet Description Weight 3.18 kg (7.00 lb) Height 20.32 cm (8.00 in) Width 40.64 cm (16.00 in) Depth 41.15 cm (16.20 in) Puck 4 buttons Stylus 2 buttons Cable length 1.5 m (5 ft), terminated in a 7-pin micro-DIN- type connector Output connector (power and data) 7-pin micro-DIN (pronged)
  • Page 221: Vsxxx-Ab Tablet Operating Conditions

    Table A-35. VSXXX-AB Tablet Operating Conditions Temperature range 10°C to 40°C (50°F to 104°F) Relative humidity 20% to 80% noncondensing Maximum wet bulb temperature 28°C (82°F) Minimum dew point temperature 2°C (36°F) Altitude 2400 m (8000 ft) maximum Reduce maximum temperature by 1.8°C for each 1,000 meter (1.0°F for each 1,000 ft) increase in altitude.
  • Page 222: Ba42 Storage Expansion Box Equipment Specifications

    BA42 Storage Expansion Box Equipment Specifications Table A-37. BA42 Storage Expansion Box Description Weight 17.24 kg (38.00 lb) maximum Height 10.16 cm (4.00 in) Width 46.02 cm (18.12 in) Depth 40.64 cm (16.00 in) Input voltage Automatically adjusting ac input 120–240 Vac Frequency range 47 to 63 Hz...
  • Page 223: Rz23 Scsi Hard Disk Drive Equipment Specifications

    RZ23 SCSI Hard Disk Drive Equipment Specifications Table A-40. RZ23 SCSI Hard Disk Drive Description Internal drive – Weight 0.83 kg (1.82 lb) – Height 42.16 cm (1.66 in) – Width 10.16 cm (4.00 in) – Depth 14.61 cm (5.75 in) Capacity –...
  • Page 224: Rz23 Scsi Hard Disk Drive Nonoperating Conditions

    Table A-42. RZ23 SCSI Hard Disk Drive Nonoperating Conditions Temperature range 40°C to 66°C ( 40°F to 151°F) Temperature change rate 20°C (36°F) per hour, maximum Relative humidity 8% to 95% packaged Maximum wet-bulb temperature 46°C (115°F) packaged Altitude 300 m to 12,200 m ( 1,000 ft to 40,000 ft) A–30 Equipment Specifications...
  • Page 225: Rz23L Scsi Hard Disk Drive Equipment Specifications

    RZ23L SCSI Hard Disk Drive Equipment Specifications Table A-43. RZ23L SCSI Hard Disk Drive Description Internal drive Weight 0.54 kg (1.20 lb) Height 2.54 cm (1.00 in) Width 10.16 cm (4.00 in) Depth 14.61 cm (5.75 in) Capacity – Bytes per drive 121.65 MB –...
  • Page 226: Rz23L Scsi Hard Disk Drive Nonoperating Conditions

    Table A-45. RZ23L SCSI Hard Disk Drive Nonoperating Conditions Temperature range 40°C to 66°C ( 40°F to 151°F) Temperature change rate 20°C (36°F per hour, maximum) Relative humidity 8% to 95% packaged, noncondensing Maximum wet-bulb temperature 46°C (115°F) packaged Altitude 300 to 12,200 m ( 1,000 to 40,000 ft) A–32 Equipment Specifications...
  • Page 227: Rz24 Scsi Hard Disk Drive Equipment Specifications

    RZ24 SCSI Hard Disk Drive Equipment Specifications Table A-46. RZ24 SCSI Hard Disk Drive Description Internal drive – Weight 0.77 kg (1.70 lb) – Height 4.14 cm (1.63 in) – Width 10.16 cm (4.00 in) – Depth 14.61 cm (5.75 in) Capacity –...
  • Page 228: Rz24 Scsi Hard Disk Drive Nonoperating Conditions

    Table A-48. RZ24 SCSI Hard Disk Drive Nonoperating Conditions Temperature range 40°C to 66°C ( 40°F to 151°F) Temperature change rate 20°C (36°F per hour, maximum) Relative humidity 8% to 95% packaged, noncondensing Maximum wet-bulb temperature 46°C (115°F) packaged Altitude 300 m to 12,200 m ( 1,000 ft to 40,000 ft) A–34 Equipment Specifications...
  • Page 229: Rz25 Scsi Hard Disk Drive Equipment Specifications

    RZ25 SCSI Hard Disk Drive Equipment Specifications Table A-49. RZ25 SCSI Hard Disk Drive Description Internal drive – Weight 0.82 kg (1.8 lb) – Height 4.14 cm (1.63 in) – Width 10.16 cm (4.00 in) – Depth 14.61 cm (5.75 in) Capacity –...
  • Page 230: Rz25 Scsi Hard Disk Drive Nonoperating Conditions

    Table A-51. RZ25 SCSI Hard Disk Drive Nonoperating Conditions Temperature range 40°C to 66°C ( 40°F to 151°F) Temperature change rate 20°C (36°F) per hour, maximum Relative humidity 8% to 95% packaged, noncondensing Maximum wet-bulb temperature 46°C (115°F) packaged Altitude 300 m to 12,200 m ( 1,000 ft to 40,000 ft) A–36 Equipment Specifications...
  • Page 231: Rz55 Scsi Hard Disk Drive Equipment Specifications

    RZ55 SCSI Hard Disk Drive Equipment Specifications Table A-52. RZ55 SCSI Hard Disk Drive Description Expansion box – Weight 13.15 kg (29.00 lb) – Height 13.97 cm (5.50 in) – Width 32.39 cm (12.75 in) – Depth 28.55 cm (11.25 in) Internal drive –...
  • Page 232: Rz55 Scsi Hard Disk Drive Operating Conditions

    Table A-53. RZ55 SCSI Hard Disk Drive Operating Conditions Temperature range 10°C to 55°C (50°F to 131°F) Temperature change rate 11°C (20°F) per hour, maximum Relative humidity 20% to 80% noncondensing Maximum wet-bulb temperature 25.6°C (78°F) Minimum dew-point temperature 2°C (36°F) Altitude 300 to 4600 m ( 1000 ft to 15,000 ft)
  • Page 233: Rz56 Scsi Hard Disk Drive Equipment Specifications

    RZ56 SCSI Hard Disk Drive Equipment Specifications Table A-55. RZ56 SCSI Hard Disk Drive Description Internal drive Weight 3.81 kg (8.40 lb) Height 8.26 cm (3.25 in) Width 14.61 cm (5.75 in) Depth 20.32 cm (8.00 in) Capacity – Bytes per drive 655.17 MB –...
  • Page 234: Rz56 Scsi Hard Disk Drive Nonoperating Conditions

    Table A-57. RZ56 SCSI Hard Disk Drive Nonoperating Conditions Temperature range 40°C to 66°C ( 40°F to 151°F) Temperature change rate 20°C (36°F) per hour, maximum Relative humidity 8% to 95% packaged Maximum wet-bulb temperature 46°C (115°F) packaged Altitude 300 to 12,200 m ( 1000 to 40,000 ft) A–40 Equipment Specifications...
  • Page 235: Rz57 Scsi Hard Disk Drive Equipment Specifications

    RZ57 SCSI Hard Disk Drive Equipment Specifications Table A-58. RZ57 SCSI Hard Disk Drive Description Internal drive – Weight 3.81 kg (8.40 lb) – Height 8.26 cm (3.25 in) – Width 14.61 cm (5.75 in) – Depth 20.32 cm (8.00 in) Capacity –...
  • Page 236: Rz57 Scsi Hard Disk Drive Nonoperating Conditions

    Table A-60. RZ57 SCSI Hard Disk Drive Nonoperating Conditions Temperature range 40°C to 66°C ( 40°F to 151°F) Temperature change rate 20°C (36°F) per hour, maximum Relative humidity 8% to 95%, packaged Maximum wet-bulb temperature 46°C (115°F), packaged Altitude 300 to 12,200 m ( 1000 to 40,000 ft) A–42 Equipment Specifications...
  • Page 237: Tk50Z Tape Drive Equipment Specifications

    TK50Z Tape Drive Equipment Specifications Table A-61. TK50Z Tape Drive Description Expansion box – Weight 12.70 kg (28.00 lb) – Height 13.97 cm (5.50 in) – Width 32.39 cm (12.75 in) – Depth 28.58 cm (11.25 in) Bit density 6,667 bits per in Cartridge capacity 95 MB approximate Frequency...
  • Page 238: Tk50Z Tape Drive Nonoperating Conditions

    Table A-63. TK50Z Tape Drive Nonoperating Conditions Temperature range 30°C to 66°C ( 22°F to 151°F) Temperature change rate 20°C (36°F) per hour, maximum Relative humidity 10% to 95% noncondensing Maximum wet-bulb temperature 46°C (115°F) packaged Altitude 9,140 m (30,000 ft) maximum A–44 Equipment Specifications...
  • Page 239: Tz30 Tape Drive Equipment Specifications

    TZ30 Tape Drive Equipment Specifications Table A-64. TZ30 Tape Drive Description Internal drive – Weight 1.50 kg (3.31 lb) – Height 4.14 cm (1.63 in) – Width 14.48 cm (5.70 in) – Depth 21.59 cm (8.50 in) Bit density 2624 bits per cm (6667 bits per in) Cartridge capacity 95 Mbytes, formatted (approximate) Media...
  • Page 240: Tz30 Tape Drive Nonoperating Conditions

    Table A-66. TZ30 Tape Drive Nonoperating Conditions Temperature range 40°C to 66°C ( 40°F to 151°F) Temperature change rate 20°C (36°F) per hour, maximum Relative humidity 10% to 95% Maximum wet-bulb temperature 2°C (36°F) Altitude 9100 m (30,000 ft) maximum A–46 Equipment Specifications...
  • Page 241: Tzk10 Qic Tape Drive Equipment Specifications

    TZK10 QIC Tape Drive Equipment Specifications Table A-67. TZK10 QIC Tape Drive Description Internal drive – Weight 1.09 kg (2.40 lb) – Height 4.39 cm (1.73 in) – Width 14.61 cm (5.75 in) – Depth 20.83 cm (8.20 in) Cartridge capacity 320 MB (approximate) with DC6320 525 MB (approximate) with DC6525 Data density...
  • Page 242: Tzk10 Qic Tape Drive Nonoperating Conditions

    Table A-69. TZK10 QIC Tape Drive Nonoperating Conditions Temperature range 30°C to 60°( 22°F to 151°F) Temperature change rate 20°C (36°F) per hour, maximum Relative humidity 10% to 95% Maximum wet-bulb temperature 46°C (115°F) Altitude 12,200 m (40,000 ft) maximum A–48 Equipment Specifications...
  • Page 243: Tlz04 Cassette Tape Drive Equipment Specifications

    TLZ04 Cassette Tape Drive Equipment Specifications Table A-70. TLZ04 Cassette Tape Drive Description Expansion box – Weight 7.7 kg (17.00 lb) – Height 11.50 cm (4.50 in) – Width 35.00 cm (14.00 in) – Depth 30.00 cm (12.00 in) Cassette capacity 1.2 gigabyte Drive interface SCSI...
  • Page 244: Rrd40 Compact Disc Drive Equipment Specifications

    RRD40 Compact Disc Drive Equipment Specifications Table A-73. RRD40 Compact Disc Drive Description (Tabletop) Weight 3.99 kg (8.80 lb) Height 7.62 cm (3.00 in) Width 23.19 cm (9.13 in) Depth 27.94 cm (11.00 in) Access time Maximum 1,000 ms, including latency Average 500 ms Average latency 155 ms at outer track...
  • Page 245: Rrd42 Compact Disc Drive Equipment Specifications

    RRD42 Compact Disc Drive Equipment Specifications Table A-76. RRD42 Compact Disc Drive Description RRD42-AA – Weight 1.3 kg (2.8 lb) – Height 4.15 cm (1.63 in) – Width 14.60 cm (5.75 in) – Depth 20.81 cm (8.2 in) Capacity 600 MB Seek time 450 ms average (typical) 700 ms maximum (typical)
  • Page 246: Rx23 Diskette Drive Equipment Specifications

    RX23 Diskette Drive Equipment Specifications Table A-79. RX23 Diskette Drive Description Internal drive – Weight 0.48 kg (1.06 lb) – Height 3.00 cm (1.18 in) – Width 10.16 cm (4.00 in) – Depth 15.01 cm (5.91 in) Number of tracks Number of heads Step rate 3 ms per track...
  • Page 247: Rx23 Diskette Drive Operating Conditions

    Table A-80. RX23 Diskette Drive Operating Conditions Temperature range 5°C to 50°C (40°F to 122°F) Temperature change rate 11°C (20°F) per hour, maximum Relative humidity 8% to 80%, noncondensing Maximum wet-bulb temperature 29°C (80°F) Minimum dew-point temperature 2°C (36°F) Altitude 300 to 3060 m ( 1,000 ft to 10,000 ft) Reduce maximum temperature by 1.8°C for each 1,000 meter (1.0°F for each 1,000 ft) increase in...
  • Page 248: Rx33 Diskette Drive Equipment Specifications

    RX33 Diskette Drive Equipment Specifications Table A-82. RX33 Diskette Drive Description Internal drive – Weight 1.10 kg (2.43 lb) – Height 4.32 cm (1.70 in) – Width 14.61 cm (5.75 in) – Depth 20.32 cm (8.00 in) Number of tracks Number of heads Track density 96 tracks per inch...
  • Page 249: Rx33 Diskette Drive Operating Conditions

    Table A-83. RX33 Diskette Drive Operating Conditions Temperature range 10°C to 46°C (50°F to 115°F) Temperature change rate 11°C (20°F) per hour, maximum Relative humidity 20% to 80% noncondensing Maximum wet-bulb temperature 45°C (113°F) Minimum dew-point temperature 2°C (36°F) Altitude 2400 m (8000 ft) maximum Reduce maximum temperature by 1.8°C for each 1,000 meter (1.0°F for each 1,000 ft) increase in altitude.
  • Page 250: Part Numbers

    Part Numbers This appendix lists the order numbers and part numbers for the components of the DECstation 5000 Model 100 Series workstations. Part Numbers B–1...
  • Page 251: Basic Components

    Table B-1. Basic Components Item Order Number VR262, 19-inch monochrome monitor, 120 volts VR262-AA VR262, 19-inch monochrome monitor, 240 volts VR262-A3 VR297, 16-inch color monitor, 120 volts VR297-DA VR297, 16-inch color monitor, 240 volts, Northern VR297-D3 Hemisphere VR297, 16-inch color monitor, 240 volts, Southern VR297-D4 Hemisphere VR299, 19-inch color monitor, 120 volts...
  • Page 252: Cords, Cables, And Connectors

    Table B-1 (Cont.). Basic Components Item Order Number - RZ56 hard disk drive PCB 29-27889-01 RZ57 hard disk drive, 1.2 Gbytes RZ57-E - RZ57 hard disk drive HDA and frame assembly 29-28158-01 - RZ57 hard disk drive PCB 29-28159-01 RRD40 optical compact disc drive, 600 Mbytes RRD40-FA TK50Z tape drive, 95 Mbytes, 120 volts TK50Z-GA...
  • Page 253: Software Documentation

    Table B-3. Software Documentation Item Order Number ULTRIX Media and Doc-TK50 QA-VV1AA-H5 ULTRIX Guide to the Error Logger AE-ME95B-TE Technical Summary for RISC Processors AA-MM35A-TE Documentation Overview for RISC Processors AA-MM05A-TE Table B-4. Hardware Documentation Item Order Number DECstation 5000 Model 100 User Documentation EK-PM32A-DK DECstation 5000 Model 100 Hardware Installation EK-PM32B-IN...
  • Page 254 Table B-4 (Cont.). Hardware Documentation Item Order Number Installing and Using the LJ250/252 Companion EK-LJ250-DK Color Printer TK50Z Tape Drive Subsystem Owner’s Manual EK-LEP05-OM TK50Z User’s Guide EK-OTK50-UG TK50Z Technical Manual EK-OTK50-TM Part Numbers B–5...
  • Page 255: Scsi Cable Connector

    Connector Pin Assignments This appendix lists pin assignments for the following connectors: SCSI cable connectors Keyboard and mouse or tablet Communications ThickWire Ethernet Power supply Modem loopback Ethernet loopback It also provides a Summary of loopback connectors Connector Pin Assignments C–1...
  • Page 256: Scsi Cable Connector

    Table C-1. SCSI Cable Connector Pin Assignments Signal Signal RSVD TERMPWR RSVD PARITY DATA<7> DATA<6> DATA<5> DATA<4> DATA<3> DATA<2> DATA<1> DATA<0> C–2 Connector Pin Assignments...
  • Page 257: Keyboard And Mouse Or Tablet Connectors Pin Assignments

    Table C-2. Keyboard and Mouse or Tablet Connector Pin Assignments Source Signal Description Ground KEY.TX Keyboard transmitted data Keyboard KEY.RX Keyboard received data +12V Keyboard/tablet power Ground Mouse/Tablet MSE.RX Mouse received data MSE.TX Mouse transmitted data Ground Ground Mouse power –12V Mouse power Ground...
  • Page 258 Table C-3. Communications Connectors Pin Assignments Source Signal CCITT Description Signal ground KNO2 Modem transmit- ted data Modem/printer Modem received data KNO2 Request to send Modem/printer Clear to send Modem/printer Data set ready Signal ground Modem/printer Carrier detector Unconnected Unconnected Unconnected Unconnected Unconnected...
  • Page 259: Thickwire Ethernet Connector Pin Assignments

    Table C-4. ThickWire Ethernet Connector Pin Assignments Source Signal Description Shield XCVR ACOL+ Collision presence KNO2 ATX+ Transmission Ground XCVR ARX+ Reception XCVR Power return CTL+ Control output Ground XCVR ACOL– Collision presence KNO2 ATX– Transmission Ground XCVR ARX– Reception KNO2 +12V Power...
  • Page 260: Modem Loopback Connector Pin Assignments

    Table C-6. Modem Loopback Connector Pin Assignments From Pin No. Signal Pin No. Signal P4-2 P4-3 P4-4 RTS2 P4-5 CTS2 P4-6 DSR2 P4-20 DTR2 P4-12 SPDMI2 P4-23 DSRS2 P4-18 LLPBK2 P4-8 P4-18 LLPBK2 P4-22 P4-18 LLPBK2 P4-25 TMI2 Table C-7. Ethernet Loopback Connector Pin Assignments From Pin No.
  • Page 261 Setting SCSI ID Switches If two or more drives have been given the same SCSI ID numbers, you must reset the SCSI ID numbers on these drives, so that each drive will have its own unique SCSI ID number. Depending on the type of drive you are installing, different methods may be required to set the SCSI ID switches that set the SCSI ID numbers.
  • Page 262 f o r a n R Z 2 3 L h a r d d i s k d r i v e P o w e r s u p p l y c o n n e c t o r S C S I c o n n e c t o r S C S I I D 6...
  • Page 263 S e t t i n g S C S I I D S w i t c h e s D – 3 f o r a n R Z 2 4 h a r d d i s k d r i v e W S 3 3 O 0 4 6 P o w e r s u p p l y c o n n e c t o r S C S I c o n n e c t o r...
  • Page 264: Rz25 Hard Disk Drive Front Jumper Settings

    SCSI ID 3 SCSI ID 0 SCSI ID 4 SCSI ID 1 SCSI ID 5 SCSI ID 2 SCSI ID 6 Front SCSI ID pins WSTCU048 Figure D-3. RZ25 hard disk drive front jumper settings D–4 Setting SCSI ID Switches...
  • Page 265: Rz25 Hard Disk Drive Side Jumper Settings

    SCSI ID 3 SCSI ID 0 SCSI ID 4 SCSI ID 1 SCSI ID 5 SCSI ID 2 SCSI ID 6 RZ25 drive Side SCSI ID pins WSTCU047 Figure D-4. RZ25 hard disk drive side jumper settings The RZ25 has front and side jumpers. Pin 4 on the front jumpers must always be in place.
  • Page 266 o r R X 2 3 a n d R X 3 3 fl o p p y d i s k d r i v e s W S 3 3 O 0 6 5...
  • Page 267 S e t t i n g S C S I I D S w i t c h e s D – 7 f o r a n R R D 4 2 o p t i c a l c o m p a c t d i s c d r i v e W S 3 3 O 0 5 6 S C S I c o n n e c t o r P o w e r s u p p l y c o n n e c t o r...
  • Page 268: Jumper Settings For A Tzk10 Qic Tape Drive

    SCSI ID 0 SCSI ID 4 SCSI ID 1 SCSI ID 5 SCSI ID 2 SCSI ID 6 SCSI ID 3 SCSI ID pins SCSI connector Power supply connector WS33O048 Figure D-7. Jumper settings for a TZK10 QIC tape drive D–8 Setting SCSI ID Switches...
