Installation and Operation Guide
Item
Max. number of
digits to be dialed
First digit timeout
Inter digit timeout
Hook flash time
End Dialing Digit
Allow end dialing
digit
End Dialing Digit
3-8
Figure 3-14. Add Prefix Window
Figure 3-15. Edit Prefix Window
Function
Specifies the maximum number of digits
comprising a number.
Specifies the timeout value in seconds for dialing
the first digit of the number.
Specifies the timeout value in seconds for dialing
the all number digits except the first digit.
Specifies the required time (in milliseconds) to put
a call on hold to enable its routing to the
destination number.
This checkbox enables the end dialing digit
feature – a DTMF symbol used to indicate the end
of destination number dialing.
This combo-box enables to define a digit/symbol
as an end dialing digit.
Default Range/
Option
10
10
3
300
Deselected
Disabled 0..9, *, #
