3.2.2 Window Tabs

The operation window comprises the following tabs:
Dialing Parameters tab (see Paragraph 3.2.2.1).
System Parameters tab (see Paragraph 3.2.1.2).
Tones Parameters tab (see Paragraph 0).
Call Back/Call Through tab (see Paragraph 0).
Dialing Parameters tab opens by default when the application is activated.

3.2.2.1 Dialing Parameters Tab

The Dialing Parameters tab (Figure 3-13) contains the options for dialing parameters configuration.
Item
List of Permitted
Cellular Gateway
Prefixes
ADD
EDIT
DELETE
Figure 3-13. Dialing Parameters Tab
Function
This field is designated to contain the permitted
frequencies entered by the user ("white list").
Opens Add Prefix window (Figure 3-14).
Opens Edit Prefix window (Figure 3-15).
Deletes the selected prefixes from the list.
CGW-D
Default Range/Op
tion
Empty Max. 30 X
8 digits
Displays
selected
prefix
3-7
