Installation and Operation Guide
Operation
Enter the programming mode
Exit the programming mode
Maximum number of digits to be dialed.
Less than XX: 3-second timeout, before dialing
starts.
Exactly XX digits dialed: Number dialed directly.
More than XX digits dialed: Number will be cut
off after reaching XX.
Reverse polarity. The CGW-D can be
programmed to send a "reverse polarity"
command to the PBX, when a "call answer" is
detected. This parameter is useful if call
accounting software is active.
Output volume control
End dialing digit definition
Hook Flash time in msec with option to set
040-980 in 20 msec steps.
Pulse drop (Loop disconnect) duration.
The length of the loop current disconnection to
indicate to the FXS direction about the
conversation end.
Conversation timeout. The telephone
conversation will be automatically terminated
after this timeout.
First digit dialing timeout. During this time
interval the gateway waits for the first dialed
digit.
Inter digit timeout. Maximum available time
interval between dialed digits
3-18
Command
*900 +XXXX
where:
XXXX=Password
*900
*300 + XX
where:
XX = 01-32 (digits)
*320 + X
where:
X = 0 – 2 (3 in 4_14 Partner)
0 = No reverse polarity
1 = Reverse polarity only on outgoing
calls
2 = Reverse polarity for incoming and
outgoing calls
*330 + X where:
X = 1-9 (9 is highest)
*334 + X
where X – DTMF digit 0-9,*,#
*370 + XXX
*380 + XX
where:
XX = number of 1/10sec
XX = 01-19
*390 + XX
where:
XX = time out in [minutes]01-99
00 = unlimited
*391 + XX,
where XX – time in seconds 03-60
*392 + X
where: XX – time in seconds 2-9
Default
1234
10 towards PBX.
(Tip: set the
default to
country's max.
telephone
number length).
2
5
None
300 ms
08 = 800 msec
00 (unlimited)
10
3
