2.4

Connectors and LEDs

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table which shows all connectors and LEDs on the hardware.
Connector/LED
CN1
CN2
CN5
CN6
CN7
CN9
CN10
CN11~CN12
CN2001
SATA1
CF1
USB1
SODIMM1
LED3
Board and Pin Assignments
Description
Front Panel Connector
Power Input Terminal Block
SATA Power Connector
Full-size PCI-Express Mini Card and mSATA Connector
VGA Connector
SIM Card Slot
Ethernet Port 1 and 2
COM1~COM4 Connectors
SMBus Connector
SATA Connector
TM
CompactFlash Socket
USB 2.0 Port 0 and 1
DDR3L SO-DIMM Socket
LED Indicator
SBC87842 Single Board Computer
9
