5) RESET DEFAULT
Press "ENTER" to reset all settings as default, and select "YES" to confirm or "NO" to cancel.
6) CLEAR HDD
Select the HDD you want to clear. Press "ENTER", and select "YES" to confirm to clear HDD or "NO" to cancel.
7) UPGRADE
Before using the USB flash drive, please use your PC to format the USB flash drive as FAT32 format first. Then,
save the upgrade file in a compatible USB flash drive, and insert it into the USB port at the front panel. Press
"ENTER", and select "YES" to confirm upgrade or "NO" to cancel.
Note: To use this function, you need to have the upgrade file saved in a compatible USB flash drive, and
insert it into the USB port at the front or rear panel.
Note: Do not disconnect the power of your DVR while the upgrade process is in progress, or the DVR
functions may not work normally or be unable to use.
8) R.E.T.R. (MIN) (Selected models only)
Select the timeout after which the R.E.T.R. function will be activated (03 / 05 / 10 / 30).
‧ R.E.T.R. On
Press the R.E.T.R. key on the IR remote controller to enable the timeout function. Key in the password, and the
R.E.T.R. delay icon "
the R.E.T.R. on icon "
‧ R.E.T.R. Off
Press any key (except "POWER") and enter the password to turn off the RETR function.
9) AUTO KEYLOCK (SEC)
Set the time-out in second after which the key lock function is activated (NEVER / 30 / 60 / 120).
10) LANGUAGE (Support multi-language)
Select the language of the OSD.
11) VIDEO FORMAT
Here shows the information of the DVR video format (NTSC / PAL).
12) VERSION
Here shows the firmware version information.

5.7. NETWORK

In this menu list, you can set up the network.
Move to "NETWORK", and press "ENTER" to enter the submenu. The submenu items are described below.

5.7.1. STATIC

1) NETWORK TYPE
Select the network type as STATIC and set all the information needed in the DVR.
2) NETWORK INFORMATION (IP / GATEWAY / NETMASK)
Key in all the network information obtained from your ISP (Internet Service Provider).
3) DNS (PRIMARY DNS / SECONDARY DNS)
Key in the IP address of the domain name server obtained from your ISP (Internet Service Provider).
" (in green background) will be shown on the screen. When the RETR function is activated,
" (in red background) will be shown on the screen.
18
ADVANCED OPERATION
