Intek M-490 Plus Owner's Manual page 6

Controls and operation
LCD Display
B C
A
R
Q
P
O N
A. AM Icon
The AM icon is lighted when radio receives and transmits in AM mode (amplitude
modulation).
B. FM Icon
The FM icon is lighted when radio receives and transmits in FM mode (frequency
modulation).
C. SCAN Icon
The SCAN icon is lighted when the SCAN function (automatic search of busy
channels) is enabled.
D. TRUCK Icon
The TRUCK icon is lighted when the special programmable TRUCK memory channel
(for truck drivers) has been selected.
E. EMG Icon
The EMG icon is lighted when one of the special pre-programmed emergency
channels has been selected.
F. ESP Icon
The ESP icon is lighted when the ESP (Electronic Speech Processor) function has
been enabled. The ESP is an RX & TX electronic modulation processor.
D E F
G
H
I
L
M
- 4 -
Diagram
- 37 -
