• The automatic setting/unsetting event schedule can also be
programmed in maintenance mode.
•
It is not possible to use the same instant of time for two events. Use t+1
minute for the second event.
Factory default setting: All automatic events switched off.
6.44 Changing the service code.
The service code is used to switch into Service mode. To change the
service code, enter:
5 NC NC
where: NC new code (4 digits), the new code has to be entered twice.
Example: The code 1276 can be programmed by entering: 5 1276 1276
Factory default setting: 8080
6.45 Go to maintenance mode
292
By entering
while in Service Mode the system switches to
maintenance mode. In maintenance mode it is possible to program the
devices to be bypassed and to adjust the control panel internal clock (see
7.4).
6.46 Setting the internal clock
The control panel has a built in real-time clock which is used to time-stamp
all recorded events in the control panel memory. Adjust the clock after
installation by entering:
4 hh mm DD MM YY
where:
hh
is the time in hours (00 to 23)
mm
is the time in minutes (00 to 59)
DD
is the day (01 to 31)
MM
is the month (01 to 12)
YY
is the year (00 to 99)
Note: The internal clock can also be adjusted in maintenance mode.
Example: On 30 June 2012 at 17:15 enter: 4 17 15 30 06 12
After the control panel is powered up, the clock is set to 00 00 01 01 00.
6.47 Editing keypad text
The names of devices and programmable outputs as displayed on the
keypad unit can be edited as follows:
?
•
Pressing and holding the
mode and the name of the device enrolled to address 01 is then displayed
with a flashing cursor on the first text character.
•
Key functions:
and
text scrolling (see table)
1 and 7
character-selection (A,B,C,D.......8,9,0)
4 and 5
cursor control (left/right)
2
delete selected character
#
exit editing (& save changes)
List of editable text:
text
01: to 50: Devices
Names of devices in addresses 01 to 50
Control panel
Name of control panel (e.g. displayed if its cover
is opened)
Keypad
Name of hard-wired keypad
Communicator
Name of the communicator in the control panel
Master code
Name of the master code
01: to 50: Code
Names of user codes
ARC Code
Names of ARC code
Service code
Name of the service code
PGX and PGY
Names of programmable outputs
OASiS JA-82
The default text displayed in operating mode if
no other text needs to be displayed. If erased
then nothing will be displayed.
fig. 14 System texts
Notes:
• Only capital letters can be entered.
• The length of text is limited to the length of the display.
• The text is only stored in the keypad used for editing (different
keypads in the system can show different text if desired).
• Text is stored in the non-volatile memory of keypads, so power
disconnection will not erase any stored text.
JA-82K control panel installation manual
key (in service mode) enters text editing
description
• Convenient text editing is possible using a PC running OLink
software. (texts can be edited in the Text synchronization \ Comparison
window (F11))
• Besides device names, keypads also use so-called internal text such
as "service", "maintenance mode" etc, and this text can also be
edited via OLink software by selecting "Central" on the menu and
then "Text synchronization \ Comparison" or F11.
• After editing keypad text using OLink software, all keypads (including
wireless ones) must be connected to the digital bus to save the
changes to the keypad units by clicking on the OK button in the
software. (It is recommended to connect JA-80F wireless keypads to the
bus in order to save the text into them as well)
• The texts can also be uploaded directly into the JA-80F wireless keypad
from the Olink.
Factory default setting: in addresses 01 to 50 there is the text "Device".
Other default text: "Control panel", "Keypad", "Communicator", "Master code",
users 01 to 50 "Code","ARC Code", "Service code", "PGX", "PGY" and
"OASiS JA-80".
6.48 Recommended settings
Recommended settings for the following parameters according to TS 50131-7 and
EN 50131-3 are:
261
radio interference indication (see 6.6)
271
radio communications supervision (see 6.7)
300
setting (arming) without an access code disabled (see 6.12)
391
auto-bypass user approval (see 6.21)
6841
tamper alarm if unset (see 6.28)
6830
keypad displays status for 3 min. if any button pressed (see 6.27)
6920
not allowed to control the system via the service code (see 6.34)
6951
system only accessed by code and card (see 6.37)
6971
service mode only with service and user (master) code (see 6.39)
7
Operating the system
The OASiS system can be operated locally using a keypad or a keyfob and
it can also be operated remotely by mobile phone or the Internet (if equipped
with a suitable communicator).
7.1
The system keypad
Indoor keypads model JA-80F (wireless) or JA-80E (wired) can be used to
operate and program the system. Both keypad types provide the same
functionality. There also can be connected the JA-80H outdoor keypad via
the WJ-80 interface – see the manual for more info.
7.1.1
Keypad indicators:
ABC setting (arming) status of sections – if all sections are set then all
these indicators (A B & C) are lit.
Flashing
Constantly lit
Power. Constantly lit = mains and back-up battery ok.
Flashing = power supply problem, control panel powered either
by the mains or by back-up battery only.
7.1.2
LCD display
st
The 1
line displays the status: triggered detector, Service mode etc. In
standby mode, it shows the text "OASiS JA-80" (editable, see 6.47).
nd
The 2
line displays the name of a device (e.g. 01: Main Door etc.). The
text can be edited, see 6.47.
Displaying the status of detectors and programmable outputs: Details
on permanently triggered detectors (e.g. open windows) and the status of the
PGX and PGY outputs can be displayed by pressing the ? key.
7.1.3
Keypad display sleep-mode
In operating mode, the wireless keypad unit displays the system status for
20 seconds (if battery-powered) after the last interaction with a user, and then
goes into sleep mode. Pressing any key, triggering the keypad input or
opening the keypad's flip cover re-activates the display.
7.1.4
Keys
0–9
digital code entry
∗
function sequences
#
escape
ABC
hot key for setting the entire system (all sections A, B & C)
A
hot key for setting section A (e.g. partial setting of the
garage)
- 13 -
= alarm, with the simultaneous display of
alarm details on the LCD, e.g.:
Alarm
03: Kitchen
= fault – details are displayed by pressing
the "?" key
MKH51102
