fig. continues
R
Reaction
8
PG
The value of the s parameter determines which
output control
PG output is controlled: s= 1= PGX, s=2=PGY or
s=3=PGX & PGY. To use this function the PG
output involved has to be programmed to the
ON/OFF or pulse functions.
If the reaction is triggered by:
a code (card) – the PG output changes its state
(ON,OFF,ON,OFF......) or a pulsed switching
event is generated after a valid code or card is
used. If a code or card is programmed this way, it
cannot be used for setting (arming) control. One or
more (up to 50) different codes can be
programmed to operate PG outputs, if desired.
a keyfob – one button in a pair is used to switch a
PG output ON, the second one to switch it off or
each of them generates a pulsed switching event.
If a keyfob is programmed this way, it cannot be
used for setting (arming) control. Each PG output
can have as many associated keyfobs as desired.
a detector – the PG output copies the status of
the detector or it generates a pulsed switching
event when the detector is triggered. Only one
detector should be programmed to a PG output
ON/OFF reaction and should not be combined with
keyfob or keypad control as the detector repeats
its status every 9 minutes and it would override the
signal from the keypad or keyfob.
9
Set/unset
Toggles the system status
SET,UNSET,SET,UNSET etc
Guidance on assignment to sections:
Assigning keyfobs with natural reactions
to sections
Unsplit
s
button
system
set
(or
)
1
unset
(or
)
set
(or
)
2
unset
(or
)
set
(or
)
3
unset
(or
)
fig. 12 Buttons to section
•
If partial setting is programmed then detectors can be assigned to
sections: A (s=1), B (s=2) a C (s=3). The three possible setting (arming)
options are as follows:
A (using the A key on the keypad, e.g. setting (arming) the garage in the
afternoon),
AB (using the B key on the keypad, e.g. setting (arming) the garage and the
ground floor during the night)
ABC (using the ABC key on the keypad, e.g. to set the entire system when
leaving the house).
•
In a split system, detectors can be assigned to sections: A (s=1), B (s=2)
a C (s=3). Sections A and B can be set independently and section C is a
common section which only sets when A and B are set.
•
Partially setting and splitting a system only have an effect on intruder
detectors with instant, delayed or next-delayed reactions. Detectors with
fire, tamper, panic, and 24-hour reactions are continuously ready to trigger
an alarm no matter which section they are assigned to or whether their
section is set or not.
•
If the selected reaction is PG output control then the s parameter
defines which PG output is controlled: s=1 PGX, s=2 PGY, s=3 PGX and
PGY.
Guidance on programming reactions:
•
The reaction selected in a detector by its internal DIP switches is only
obeyed by the control panel if the reaction programmed in the detector's
address is a natural one (r=1).
•
Keyfobs always enroll a pair of buttons (
natural reaction of such a pair of buttons is shown in the above table. If
any other reaction is selected for a keyfob, this reaction will only apply to
the first button of the pair, i.e.
+
. The
(
) button has no effect (can still be used for controlling
UC/AC receivers).
Factory default setting: All addresses from 01 to 50 have a natural reaction
(r=1) and are assigned to section C (s=3).
JA-82K control panel installation manual
Notes
Partial
Split
setting
system
set A
set A
set AB
unset A
set A
set B
set AB
unset B
set ABC
set ABC
unset ABC
unset ABC
+
) or (
+
or
, or to double buttons
6.41 Code/card reactions and section assignment
The following sequence programs the features of access codes or cards:
62 nn r s
where:
nn
r
s
Guidance on assigning codes or cards to sections:
•
In partial setting (arming) mode assigning codes or cards to sections
has no effect (except for the PG output control reaction). If anything in the
system is set and a card/code is used, the system will then be unset, and
if all sections are unset then the whole system will be set by a card/code.
Partial setting keys A and B on the keypad can be programmed to be
followed by a valid access code if required (see 6.12).
•
For a split system, a code assigned to section:
A controls section A
B controls section B
C controls sections A, B and C.
•
If the system is not split then the assignment of codes/cards to sections
has no effect, but the s parameter must be entered in the programming
section. Enter s=3 if splitting is not desired.
Guidance on code/card reactions:
•
If a code/card has a natural reaction, i.e. r=1, then its reaction is set,
unset, set etc. (the same as reaction r=9).
•
A code/card can also have an alarm reaction similar to detectors.
•
A code/card set to a Next Delay reaction allows you to set the system
anytime, but unsetting is only possible after an alarm. This feature is
designed for security services staff.
Factory default setting: all codes/cards from 01 to 50 have a natural
reaction (set/unset) and are assigned to section C.
6.42 Enrollment by keying in production codes
This sequence allows the enrollment of devices by keying in their
production codes:
60 nn xx..x
where:
nn
xx...x
Notes:
• If the address nn is already occupied, the current device will be
erased, and the new device will then be enrolled instead.
• If a device with production code xx...x has already been enrolled to
another address in the past, and if the device is now enrolled to a
new address, then it will be moved to the new address, releasing the
old address.
• If you enter nn = 01 to 4 (...14), the device will enroll instead of the
corresponding hard-wired input in the control panel (the terminal will
be disabled).
•
If eight zeros are entered as a production code, the device already
assigned to the address nn will be erased
6.43 Automatic setting / unsetting schedule
This can be used to program an automatic sequence of daily
setting/unsetting events. Up to 10 daily events can be programmed. Events
will occur every day of the week:
64 n a hh mm
where:
n
a
hh
mm
Erase the automatic schedule setting by: 64 n 0
). The
a
0
+
or
1
2
3
4
5
6
* the same event in an unsplit system
- 12 -
is the user position from 01 to 50
is the reaction index from 0 to 9 – see Chyba! Nenalezen
zdroj odkazů.
is the section 1 = A, 2 = B, 3 = C (only has an effect in a
split system – except for the PG output control reaction –
see 6.26).
is the address of the device from 01 to 50
is the production code of the device (the last eight digits of
the bar code, see the label on the PCB inside the device)
is the event number from 0 to 9
is the type of event from 0 to 6 (see the following table)
hours (time of event)
minutes (time of event)
unsplit system
No event
Set all (ABC)
Unset all (ABC) *
Set A**
Set AB**
Unset all (ABC) *
Unset all (ABC) *
fig. 13 Actions
split system
No event
Set all (ABC)
Unset all (ABC)
Set A
Set B
Unset A
Unset B
MKH51102
