6. Connect the other end of the RJ-45 network cable to the ERM (see
Figure 4).
ERM
NETWORK
To LAN port
7. Verify that the ERM is connected to the network. Open the ERM
Web page and select
Setup
8. Change the status of the TH-Module from "Disable" to "Auto" on
the Device Name line. Verify that the TH-Module LED
(Power/Status) is flashing.
9. Set the status of alarm 1 and/or alarm 2 to "Normal Close" and
select "Door Contact."
10. Select
EATON Powerware
TH-Module-1 TH-Module-2
TH-Module
Figure 4. ERM and TH-Module
Monitoring
. The setup screen displays (see Figure 5).
to confirm the security detector setup.
Set Value
® Security Detector User's Guide
SECURITY DETECTOR
1 2
RESET
12 VDC
To Power Outlet
, then or
TH-Module-1 Setup
S
164201679 Rev 1
TH-Module-2
5
