Guard Ring And Engine Mounting Assembly - MULTIQUIP PRO46 Operation And Parts Manual

13
12
2
11
10
7
6
PAGE 66 — PRO46 SERIES WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/20/15)
GUARD RING AND ENGINE MOUNTING ASSY.
5
9
8
1
1 3
2
NOTES:
1
USE LOCTITE BLUE# 246 W/ ALL SCREWS
2
TORQUE TO 8 FT.-LBS. (10.8 N m)
3
TORQUE TO 14.5 FT.-LBS. (20 N m)
4 TORQUE TO 23 FT.-LBS. (31 N m)
STANCHION IS WELDED TO THE
5
GUARD RING.
3
4
1 4
5
