GENERAL INFORMATION
MECHANICAL BOOM
The mechanical boom is mounted in front of the trowel
unit and supports the fresno brush, fresno blade, and plated
weight(s). The boom raises and lowers the brush and blade
via the hand crank winch, and has 180° range of lateral
motion which is adjustable based on operator's preference
and troweling surface.
TRAINING
For proper training, please use the "TRAINING CHECKLIST"
form located in the front of this manual. This checklist will
provide an outline for an experienced operator to provide
training to a new operator.
