Engine And Clutch Assembly - MULTIQUIP PRO46 Operation And Parts Manual

1 3
1 5
43
2
1
44
PAGE 76 — PRO46 SERIES WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/20/15)
2
1 4
52
50
5
41 45
36
1
ENGINE AND CLUTCH ASSY.
49
54
19
32
46
1
4
25
1 4
NOTES:
USE LOCTITE BLUE# 246.
1
( FOR CLUTCH AND PULLEY: TO ALL SET SCREWS)
2
TORQUE TO 8 FT.-LBS. (10.8 N m)
3
TORQUE TO 17 FT.-LBS. (23 N m)
4
TORQUE TO 14.5 FT.-LBS. (19.6 N m)
5
TORQUE TO 26 FT.-LBS. (35 N m)
6
CORRECT SPRING HOOK MOUNTING.
37
