MULTIQUIP PRO46 Operation And Parts Manual page 27

NOTICE
Refer to Figure 29 for the pitch and winch cable
installation instructions.
PITCH CABLE INSTALLATION (FRESNO BLADE)
1. Uncoil the clevis end of the fresno blade pitch cable.
2. Check that the fresno pitch cable is attached to the
fresno blade pitch bracket on the upper handle as
shown by letter (A).
3. Check that the pitch cable is fed along the main tube
and secured with zip ties.
4. Route the clevis end of the pitch cable around the
engine and secure the pitch cable to the boom arm
with zip ties.
NOTICE
Check and make sure the pitch cable is clear of any
moving parts (free movement) on the trowel before
continuing. Re-route the pitch cable if necessary.
5. On the threaded end on the pitch cable remove the
5/16" outer nut and rubber cap as shown by letter (C).
6. Adjust the 5/16" inner nut for a 7/8" distance from the
threaded end on the pitch cable to the inner nut as
shown by letter (C).
7. Insert the exposed cable into the cable anchor slot.
8. Place outer nut and rubber cap back onto the threaded
end of the pitch cable. Hand tighten nut against the
cable anchor.
9. Once the threaded end of the pitch cable is secure in
the cable anchor, continue to route the pitch cable up
to the pitch plate located at the top of the boom arm
as shown by letter (D).
10. Align the clevis end of the pitch cable with the pitch
plate mounting holes as shown by letter (D).
PRO46 SERIES WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/20/15) — PAGE 27
ASSEMBLY AND INSTALLATION
11. Insert the 5/16-18 x 1" bolt through the clevis. Place a
5/16-18" lock nut onto the bolt.
12. Using a 1/2" wrench tighten the 5/16-18" lock nut.
WINCH CABLE INSTALLATION
1. Uncoil the clevis end of the winch cable.
2. Check that the winch cable is attached to the winch
bracket on the upper handle as shown by letter (B).
3. Check that the winch cable is fed along the main tube
and secured with zip ties.
4. Route the clevis end of the winch cable around the
engine up to the boom cable anchor.
NOTICE
Check and make sure the winch cable is clear of any
moving parts (free movement) on the trowel before
continuing. Re-route the pitch cable if necessary.
5. On the threaded end on the winch cable remove the
5/16" outer nut and rubber cap as shown by letter (C).
6. Adjust the 5/16" inner nut for a 7/8" distance from the
threaded end on the clutch cable to the inner nut as
shown by letter (C).
7. Insert the exposed cable into the cable anchor slot.
8. Place outer nut and rubber cap back onto the threaded
end of the winch cable. Hand tighten nut against the
cable anchor.
9. Once the threaded end is secured in the cable anchor,
continue to route the winch cable over the upper pulley
wheel, and over and under the lower pulley wheel as
shown by letter (E) and (F) respectively.
10. Repeat steps 10 through 12 (Pitch Cable Installation)
to secure the clevis end of the winch cable to the cable
anchor, letter (G).
