OPERATION MANUAL
SERIES
MODEL HTXG6DF
HYDRAULIC RIDE-ON TROWEL
(PSI 2.4L DUAL FUEL)
Gas and Propane Engine
Revision #3 (08/30/19)
To find the latest revision of this publication or
associated parts manual, visit our website at:
www.multiquip.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
PN: 42543
