Trowel Specifications/Dimensions - MULTIQUIP PRO46 Operation And Parts Manual

A–Height (Lifting Bale) –in (mm.)
B–Height (Handle) – in (mm.) Standard 41.1 (1,044.2) Rotor – RPM (Dry Concrete)
C–Width (Ring Diameter) – in (mm.)
D–Length – in (mm.)
Number of Blades
PAGE 12 — PRO46 SERIES WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/20/15)

TROWEL SPECIFICATIONS/DIMENSIONS

C
B A
Figure 1. Dimensions
Table 1. Trowel Specifications
34.5 (876.2)
46.0 (1,168.4) Gear Box Oil Capacity – oz. (ml.)
75.2 (1,910.1) Shipping Weight – lbs (kg.)
Rotor 4
Fresno 1
D
Path Width – in (mm.) 46 (1,168)
60-130
26 (769)
350 (158.7)
