Gearbox Assy - MULTIQUIP PRO46 Operation And Parts Manual

NO. PART NO.
1%$ 0753
2% 0131A
3% 12876
4%# 20466
5%$ 20395
7%# 20465
9% 1851
10% 20407
11% 21218
12 21046
13 21047
14% 20476
15% 21033
16% 0121 A
17% 1138
18%# 20475
19%# 20474
20% 1140
21% 20470
22% 1139
25%$ 20396
26% 12875
27% 10235
28% 20875
29%$ 0254
30 20407
31 20111
32 22292
33 20802
34 1150
35 20801
36 60091
37 60096
PRO46 SERIES WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/20/15) — PAGE 75
PART NAME
SEAL, OIL
SCREW, HHC 1/4-20 X 3/4"
FLANGE, INPUT SHAFT
BEARING, CUP, TIMKEN #M11910
O-RING, 2"
BEARING, CONE, TIMKEN #LM11949
GEAR, WORM "B" INPUT SHAFT
GEARBOX ASSY. BA/HP 2"
VENT, AIR
GASKET/SEAL KIT ............................................1................INCLUDES ITEMS W/$
BEARING KIT ....................................................1................INCLUDES ITEMS W/#
SCREW, HHC 1/4-28 X 3/8"
SIGHT GLASS, 3/4 M PIPE STEEL
FITTING, PLUG 3/8 MP SQ HEAD
RING, SNAP
BEARING, CUP TIMKEN #M86610
BEARING, CONE TIMKEN #M86647
GEAR, WORM, COMPOSITE
SHAFT, OUTPUT
KEY, WOODRUFF #810
O-RING
COVER, GEARBOX
WASHER, C/S EXT. SHKP
SCREW, FHSC 5/16-18 X 3/4"
SEAL, OIL
GEARBOX ASSY. ..............................................1................INCLUDES ITEMS W/%
OIL, MOBIL SYNTHETIC SHC634, 22 OZ. (650 ML) 2
SPACER, 0.5" X 0.402" X .25"L UNTREATED 2
RING, SNAP
YOKE ARM
PIN, YOKE
LOCTITE, BLUE #242
LOCTITE, WHITE #572

GEARBOX ASSY.

QTY. REMARKS
1
4
1
2
1
2
1
1
1
2
1
1
1
2
2
1
1
1
1
1
4
4
1
2
1
1
AR
AR
