5. Installation and operation

5.1 Installing and connecting the printer

Install the printer as described in Section 1.4 – Location of the printer.
• Make sure that your PC and the printer are both switched off.
• Connect the printer cable to your PC and to the printer.
The type of power terminal depends on the country version of the printer.
Ensure that the power cable connector is suitable for your location.
• Connect the power cable to the printer's power socket. Connect the
power plug to a grounded socket.
• For the moment, leave the printer switched off.

5.2 Inserting print (ink) cartridges

IMPORTANT!
See Section 9.4 for important notes on cartridge maintenance.
The printer requires three "HP51645A style" print cartridges.
Rena ink cartridges are available in Black (C6131A), Versatile Black
(C8842), Fast Dry (C6195), Red (C6168A), Green (C6169A) and Blue
(C6169A) Blue (C6170A), and Yellow (C6173A) Ink.
Rena ink cartridges can be purchased through your local, authorized
Rena Dealer.
Observe the notes on "Handling the print cartridges" as well as the
directions given by the cartridge manufacturer.
• If the printer unit is located on the rear side panel, unscrew its two
lower knurled screws and push the unit into mid-position.
• Fully release all restraining levers.
• Take the first cartridge from its packaging and remove the protective
tab.
