4.3 Overview of the printer

1 Printer cable terminal
2 Power cable terminal
3 ON/OFF switch
4 Control panel with display
5 Outer contact bracket
6 Inner contact bracket
7 Guide bar
8 Separator
9 Knurled screw for separator
10 Print unit
11 Knurled screws for print-unit cradle
12 Height adjuster for print unit
13 Not included
14 Stop lever for ink cartridges
15 Ink cartridge (HP51645A, C8842A, C6168A, C6169A, C6170A)
