QUICK START - FEATURES
ITEM
MOUNTING BRACKET
BOTTOM FITTING
M4 SET SCREWS
M6 SET SCREW
NL4-COMPATIBLE
LOCKING
CCONNECTOR
DUAL BANANA JACK
INPUT CONNECTOR
BARRIER STRIP
INPUT TERMINALS
BARRIER STRIP THRU
TERMINALS
DUAL BANANA PLUG
THRU CONNECTOR
Note: The Bottom Fitting must be securely fastened to the Mounting Bracket. This fitting supports
the entire weight of all ENTASYS loudspeakers stacked together. This fitting must be removed from
any upper ENTASYS loudspeakers that are to be stacked on top of another ENTASYS loudspeaker.

Table 1: ENTASYS Features

(Refer to Figure 1 on opposite page)
1, attached to loudspeaker
1, attached to Mounting Bracket
8, to hold Mounting Bracket in place
1, to hold Bottom Fitting in place
4 pole NL4MP-type jack, wired in parallel with other input and thru
connectors. Accepts NL4FC-type connectors for signal input to
loudspeaker. Use terminals 1±. Terminals 2± are not connected.
Standard dual banana jack for input to loudspeaker.
Nuts on threaded posts to accept bare wire or lugs for input to
loudspeaker.
Nuts on threaded posts to accept bare wire or lugs for output to
another loudspeaker.
Standard dual banana jack for output to another loudspeaker.
Can be used with supplied banana jumper pin to connect to
ENTASYS loudspeakers when stacking them.
Community ENTASYS Installation/Operation Manual — Page 9
