ACCESSORIES
4. Slide the "T" Mounting Bracket into the ENTASYS enclosure(s). Securely tighten each of the eight M4 Set
Screws in each ENTASYS enclosure to attach the "T" Mounting Bracket to the enclosure(s).
5. Insert the Rubber Plug into the Dual Banana Plug Thru Connector recess.
6. Attach the Fly Bracket to the upper most studs on the "T" Mounting Bracket using the M6 nuts, lock washers,
and flat washers provided. Hand tighten the nuts, then securely tighten the two nuts at the top of the Fly
Bracket first. This will compress the Rubber Plug if there is any interference and properly seat the Fly
Bracket. Now tighten the two nuts at the bottom of the Fly Bracket.
7. Bolt both halves of the Pull Back Bracket to the lower most studs on the "T" Mounting Bracket using the M6
nuts, lock washers, and flat washers. Securely tighten all four of the nuts.
The ENTASYS array should now be ready to be suspended. Use safe rigging practices when attaching
all other rigging hardware to the Fly Kit brackets and to the suspension points of the building or other suspension
means.
WARNING: A single ENTASYS Fly Kit assembly must not be used to suspend more than five (5)
ENTASYS loudspeakers. Attempting to do so will exceed the Working Load Limit of the bracket and
could result in the failure of the bracket and potentially result in severe injury and/or loss of life.
