- Page 1 E SERIES ENTASYS 200 VERSATILE TWO-WAY COLUMN POINT SOURCE SYSTEMS Application Guide Part 1: System Information C50 Loudspeaker Comparison in HOW with 2.5 sec. Eyring RT60 ENT-FRx2 SLS920 ENT220...
-
Page 2: Quick Product Overview
The two larger models, the ENT212 and ENT220, are designed for use in medium choices in the E SERIES family of to medium-large spaces. Highly effective when used as the main system, they column loudspeakers. Column... -
Page 3: Mechanical Installation
However, equalization filters for system optimization and room compensation plus high pass filters are still needed. For this task, Community‘s dSPEC Networked DSP Integrated loop Loudspeaker Controller is the perfect partner to an ENTASYS 200 installation. -
Page 4: Entasys 200 Facts
200 Hz crossover so that both sources sum acoustically and also to avoid the subwoofer from sounding directional near crossover. To make this possible, Community offers compact subwoofers in the I SERIES and V SERIES lines. The most applicable models are IS6-112, IS6-212, IS8-112, IS8-212, VLF208, VLF208LV, V2-210S, and the V2-212S. For high output systems, consider one of the previous models for mid-bass (80 Hz to 200 Hz) plus large I SERIES or V SERIES subwoofers to operate below 80 Hz. -
Page 5: System Requirements
SYSTEM REQUIREMENTS amplifiers, connections, environment, and filters SELECTING AMPLIFIER SIZE ENT203 ENT206 ENT212 ENT220 Continuous Ratings (in watts) 75W cont. 150W cont. 325W cont. 500W cont. Program Ratings (in watts) 190W PGM 375W PGM 800W PGM 1250W PGM Note: When multiple ENTASYS 200 column loudspeakers are to be powered by a single amplifier channel, amplifier output ratings should be scaled upward appropriately. -
Page 6: Which E Series System
WHICH E SERIES SYSTEM? coverage and other considerations WHEN TO USE ENTASYS FR COMMUNITY'S A line source/line array system is exceptionally well-suited for use in TAG TEAM reverberant spaces because of its high degree of pattern control of where it is imperative that sound must be directed to the audience areas only, We are here to help you! and not bounce off other strongly reflective room surfaces. - Page 7 WHICH E SERIES SYSTEM? comparisons ENTASYS FR/LF ENTASYS 200 • Maximum power density for size - • Two-way column format at a higher output levels lower price point • Greater degree of beam focusing • Mounting brackets included (especially good for reverberant •...
- Page 8 ©2014 Community Professional Loudspeakers v:8OCT2014 Community Professional Loudspeakers 333 East Fifth Street, Chester, PA 19013-4511 USA Phone (610) 876-3400 • Fax (610) 874-0190 communitypro.com...
