SPECIFICATIONS
Table 13: ENTASYS Loudspeaker Specifications*
ENTASYS
Frequency Response
Maximum Input
Recommended Amplifier
Sensitivity
(1 W / 1 m; 3.46 V)
Maximum SPL
(Single unit)
Nominal Impedance
Minimum Impedance
Nominal Dispersion
(1 kHz ‐ 16 kHz)
Crossover Frequencies
Recommended HP Filter
Drivers
MF/HF Driver Configuration
Input Connections
Enclosure
Grille
Finish
Supplied Accessories
Required Accessories:
Optional Accessories
Dimensions
H x W x D
Weight
Shipping Weight
* Community strives to improve its products on a continual basis. Specifications may therefore be subject to change without notice.
ENT‐FR
Full‐Range Three‐Way Column
200 Hz ‐ 20 kHz
600 W continuous
1500 W program
1200W to 1800W
Curved (12° V): 93 dB SPL
Straight (6° V): 95dB SPL
Curved (12° V): 120 dB SPL
Straight (6° V): 122 dB SPL
12 Ω
8.4 Ω
Horizontal: 120°
Vertical: 12°, 6° (user configurable)
LF to MF: 1 kHz
MF to HF: 7 kHz
200 Hz, 24 dB/octave
LF: Six 3.5" neodymium
MF: Eighteen 2.35"
HF: Forty‐two 1" ( six 7" long by 1" wide
patent‐pending planar‐coupled Compact
Ribbon Emulators)
Straight, Curved, or
Asymmetric Curved
Top: (1) Dual Banana Plug (male)
Bottom:
(1) NL4 locking connector
(1) Dual Banana Jack (female)
(2) Terminal Strip
Aluminum construction, molded nylon
end caps
Matching black or white metal curved grille
Black or White
(1) T‐Bar Mounting Bracket
(1) Input Wiring Cover
(2) Top Connector Cover
User configurable vertical coverage
adjustment spacers
Digital Signal Processor /
200 Hz High Pass Filter
Community offers several optional suspension brackets which attach to the
included Mounting Bracket (see Accessory Section of this manual for details)
44.5 x 5.5 x 7.36 inches
(1,129 x 140 x 187 mm)
40 lbs (18.1 kg)
48 lbs (21.8 kg)
Community ENTASYS Installation/Operation Manual — Page 51
ENT‐LF
Low Frequency Column
200 Hz ‐ 1.6 kHz
600 W continuous
1500 W program
1200W to 1800W
90 dB SPL
116 dB SPL
12 Ω
12.1 Ω
Using additional LF column(s) enhances
vertical directivity at lower frequencies
1.6 kHz Low Pass Filter
200 Hz, 24 dB/octave
LF: Six 3.5" drivers with optimized spacing,
allows extension of the narrow vertical
beamwidth into the lower frequencies
Straight
Top: (1) Dual Banana Plug (male)
Bottom:
(1) NL4 locking connector
(1) Dual Banana Jack (female)
(2) Terminal Strip
Aluminum construction, molded nylon
end caps
Matching black or white metal curved grille
Black or White
(1) T‐Bar Mounting Bracket
(1) Input Wiring Cover
(1) Top Connector Cover
Digital Signal Processor /
200 Hz High Pass Filter
44.5 x 5.5 x 7.36 inches
(1,129 x 140 x 187 mm)
25 lbs (11.3 kg)
32 lbs (14.5 kg)
