Defining the VM-114H2C

Figure 1 and
#
1 IR Remote Control Sensor
2 IR LED
3 REMOTE IR 3.5mm Mini Jack Connect to a remote IR sensor
4
EDID Buttons
5
6 OUTPUT 1~4 LEDS
7 POWER LED
8 INPUT SELECTOR Button
9 IN1 HDMI LED
10 IN2 CAT5 LED
1 Also lights or flashes during EDID setup (see
6
Defining the VM-114H2C
Table 1 define the front panel of the VM-114H2C.

Figure 1: VM-114H2C Front Panel

Table 1: VM-114H2C Front Panel Features

Feature
Sensor for the remote control IR transmitter
Lights yellow when receiving signals from the IR remote control
transmitter
READ Button Press (when one of he input LEDs is flashing to indicate a selected input)
to read he selected EDID (see
SELECT Press repeatedly to cycle through the inputs to select an input from which
Button to read he EDID. The relevant LED flashes (see
The relevant LED lights green when an acceptor is connected to the
output
Lights green when he unit receives power
Press to select an input. The relevant IN 1 HDMI/IN 2 CAT5 LED lights
Lights green when HDMI input 1 is selected
Input
LEDs
Lights green when he TP CAT 5 input 2 is selected
Section
1
5 2)
Function
Section 5.2)
Section
